Sharp UP-3300 Programming Manual

Pos terminal
Hide thumbs Also See for UP-3300:

Advertisement

Quick Links

See also: Service Manual , Instruction Manual
CHAPTER 1. PROGRAM RESET and SRV mode . . . . . . . . . . . . . . . . . . . . . . .1
Chapter 2. Master Reset (All Memory Clear) . . . . . . . . . . . . . . . . . . . . . .2
Chapter 3. Reading Of Srv Mode Program . . . . . . . . . . . . . . . . . . . .5
Chapter 4. Srv Mode Programming ("2 Setting") . . . . . . . . . . . . . .10
* For setting in USER PROGRAMMING mode, refer to the Reference Manual
which is Provided with each UP3300.
SHARP CORPORATION
PROGRAMMING MANUAL
POS TERMINAL
MODEL
(For "U" and "A" version)
CONTENTS
CODE: 00ZUP3300UPME
UP-3300
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.

Advertisement

loading

Related Manuals for Sharp UP-3300

Summary of Contents for Sharp UP-3300

  • Page 1 PROGRAMMING MANUAL CODE: 00ZUP3300UPME POS TERMINAL UP-3300 MODEL (For "U" and "A" version) CONTENTS CHAPTER 1. PROGRAM RESET and SRV mode ..... . .1 CHAPTER 2.

  • Page 2: Chapter 1. Program Reset And Srv Mode

    CHAPTER1. PROGRAM RESET and as shown below. SRV mode DISPLAY: [SRV mode screen] In the UP-3300, the following reset switch (location No: S1) is used to switch to the service (SRV) mode and to reset. MRS Switch MRS Switch PROGRAM RESET Used to return the machine back to its operation state after a lock up has occured.

  • Page 3: Chapter 2. Master Reset (All Memory Clear)

    8) MASTER RESET-1 is started. CHAPTER 2. MASTER RESET DISPLAY: (All Memory Clear) There are three possible methods to perform a master reset. MASTER RESET 1. MRS-1 (Master resetting 1): Clear the 9) After completion of the master reset, the buzzer sounds three entire memory and resumes initial times and the following SRV mode display is shown.
  • Page 4 6) The master reset menu window is displayed as shown below. 10) After completion of the master reset, the buzzer sounds three times and the following SRV mode display is shown. DISPLAY: DISPLAY: [SRV mode screen] Please select MASTER RESET MASTER RESET 1 MASTER RESET 2 Touch the [MASTER RESET 2] key.
  • Page 5 6) The master reset menu window is displayed as shown below. 9) Set the fixed keys in the table below (Start from the [HOME] key, The key are displayed sequentially) DISPLAY: DISPLAY: Please select ENTER HOME MASTER RESET MASTER RESET 1 MASTER RESET 2 KEY NAME HOME...
  • Page 6 Sample of program reports CHAPTER 3. READING OF SRV PROGRAM 1. [1 SYSTEM PRESET] DISPLAY: The setting contents of the SRV mode can be checked with the display or printer. DISPLAY: SRV mode screen PRINTER: Select "1 READING" and press the ENTER key. DISPLAY: READING item selection screen Report title JOB# / Data...
  • Page 7 2. [2 DEVICE ASSIGN] 3. [3 FREE KEY LAYOUT] DISPLAY: DISPLAY: FREE KEY LAYOUT item selection screen PRINTER: Select the desired item, press the ENTER key. DISPLAY: OUTPUT read destination select screen Report title Device name / Notassigned Device name / Terminal No. / Channel No.
  • Page 8 PRINTER: Report title Key No. / Key text / Key position code Not assigned Keyboard name: SHARP UP3300 POS MAIN2 MAIN3 SUB2 SUB3 CONDIMENT/MENU CONDIMENT/MENU2 CONDIMENT/MENU3 QUANTITY DISCOUNT SUB ENTRY FUNC.MENU4 FUNC.MENU5 FUNC.MENU6 FUNC.MENU7 PAYMENT DRIVE THROUGH – 7 –...
  • Page 9 4. [4 FILE] DISPLAY: PRINTER: Report title File table No. / No. of records/ No. of used records File table No. / No. of records / No. of blocks / No. of used records File table No. / No. of index records - No.
  • Page 10 5. [5 SSP] DISPLAY: SSP item selection screen Select the desired item, press the ENTER key. DISPLAY: OUTPUT read destination select screen File memory start address Empty memory start address Memory end address The setting content is displayed and printed DISPLAY: PRINTER: Report title...

  • Page 11: Chapter 4. Srv Mode Programming ("2 Setting")

    1. [1 DEVICE ASSIGN] CHAPTER 4. SRV MODE PROGRAMMING DISPLAY: Setting item select screen ("2 SETTING") DISPLAY: SRV mode screen Select "2 SETTING" and press the ENTER key. Select "1 DEVICE ASSIGN" and press the ENTER key. DISPLAY: SETTING item selection screen DISPLAY: DEVICE ASSIGN select screen Select the desired item, press the ENTER key.

  • Page 12: Select Item

    Re-routing programming is only valid for printer. 0 ∼ 7 CHANNEL# Channel No. No RS232 channel is assigned. 1 ∼ 7: RS232 channel is assigned. Set channel #7 for SHARP UP-T80BP. PRINTER NAME Connected printer name EPSON TM-T85 SHARP ER-03/04RP EPSON TM-300 EPSON TM-T80...
  • Page 13 [JOB#901] : MRS=0002 2. [2 SYSTEM PRESET] 901-A: Not used (Fixed at “0”) DISPLAY: Setting item select screen 901-B: 1. Tax system 1. Tax system 901-B Auto tax 1-4 & manual tax CANADIAN TAX (Type to Type 10) CANADIAN TAX (Type 11) 901-C: 1.Rounding system 1.Rounding system...
  • Page 14 [JOB#904] : MRS=0000 [JOB#906] : MRS=0031 904-A: 1. Printing of date 906-A: 1. Printing of Dept. and PLU code 2. Entry which makes the PLU stock counter negative 1.Printing of date 904-A 1. Printing of Dept. 2. Entry which makes the PLU 906-A and PLU code stock counter negative...
  • Page 15 908-B: GT print on X report [JOB#910] : MRS=0024 1. GT1 (NET) 2. GT2 (+) 3. GT3 (–) 908-B 910-A: 1. Drawer open at server sign ON/OFF Skip 1. Drawer open at server sign ON/OFF 910-A Skip Print Skip Skip Print Print Note: For stay down server# entry system.
  • Page 16 912-C: 1. After transaction receipt 913-C: 1. Lock error buzzer keeps sounding 2. Copy receipt function 2. Buffered keyboard 3. Footer print control (SRV JOB 912-D=2) 1. Lock error buzzer 2. Buffered keyboard 913-C keeps sounding 1. After 2. Copy 3.
  • Page 17 914-D: 1.Manual TAX 916-C: 1.Negative merchandise subtotal 2.Check/Cashing 2.Subtotal entry before tender 3.Non-add code entry 3.Subtotal entry before direct non-tendering finalization 1.Manual TAX 2.Check/Cashing 3.Non-add 1.Negative 2.Subtotal entry 3.Subtotal entry code 914-D merchandise before tender before direct 916-C entry subtotal non-tendering finalization Enable...
  • Page 18 917-B: 1. Printing of Taxable 2 subtotal on X/Z report [JOB#918] : MRS=2233 2. Printing of Gross Tax 2 and Refund Tax 2 totals on X/Z 918-A: 1. Printing of text for associated PLU in COMBO MEAL. report 2. Direct non-tendering finalization after previous tender en- 3.
  • Page 19 920-C: 1.Broadcast communication (in-line) [JOB#919] : MRS=5000 2.PGM-mode programming at the satellite 919-A: 1. GLU/PBLU system 1. Broadcast 2. PGM-mode programming 2. GLU/PBLU code entry at reorder (When #919:B-1 is 0 “ 920-C communication at the satellite Auto generation ”) Disable 1.
  • Page 20 [JOB#923] : MRS=0010 : INLINE PROGRAMMING [JOB#926] : MRS=0000 AREA 926-A: 1. Printing “LAST VOID DATA” on KP. 923-A,B: 1. The record number for REQUEST of T-LOG POLLING 2. Printing “PAST VOID DATA” on KP. (x100) 1. Printing “LAST VOID 2.
  • Page 21 928-D: 1. Compulsory bill print system 3. [3 Z REPORT COUNTER] 1. Compulsory bill print system 928-D DISPLAY: Setting item select screen According to each media’s preset (The bill printing at service and final in GLU system acts on PGM2 preset. Compulsory every entry Compulsory for PB entry [JOB#929] : MRS=0100...
  • Page 22 4. [4 GT] 5. [5 MODE SECRET#] DISPLAY: Setting item select screen DISPLAY: Setting item select screen Select "4 GT" and press the ENTER key. Select "5 MODE SECRET #" and press the ENTER key. DISPLAY: Z REPORT COUNTER screen DISPLAY: MODE SECRET# screen Select the GT to be changed and enter the value The content of displayed GT are as listed in the table...
  • Page 23 [FREE KEY LAYOUT] – [1 SETTING] 6. [6 FREE KEY LAYOUT] DISPLAY: Setting item select screen DISPLAY: Setting item select screen Select "1 SETTING" and press the ENTER key. Select "6 FREE KEY LAYOUT" and press the ENTER key. DISPLAY: Keyboard select screen Select the Key and press the place to where you want to set the key.
  • Page 24 [FREE KEY LAYOUT] – [2 COPY] [FREE KEY LAYOUT] – [3 INIT. KEY MODE] DISPLAY: Setting item select screen DISPLAY: Setting item select screen Select "3 INIT. KEY MODE" and press the ENTER key. Select "2 COPY" and press the ENTER key. KEY LAYOUT is initialized.
  • Page 25 This description may not apply to all and is based upon programming. Keyboard Name Default TEXT Contents HOME SHARP UP3300 POS This Key Board is the HOME Key board. (This appears by pushing the HOME key on any keyboard.) MAIN2 MAIN2 This Key Board is used by function keyboard.
  • Page 26 FUNCTION KEY LIST PGM#2629(MRS) PGM#2629(MRS) FUNCTION NOTE KEY TEXT KEY COLR HOME HOME BLUE Fixed Key CANCEL CANCEL YELLOW Fixed Key CLEAR CLEAR YELLOW Fixed Key MODE MODE BLUE Fixed Key ↑ CURSOR UP GRAY Fixed Key ↓ CURSOR DOWN GRAY Fixed Key ←...
  • Page 27 PGM#2629(MRS) PGM#2629(MRS) FUNCTION NOTE KEY TEXT KEY COLR CHARGE TIP CH TIP YELLOW CASH TIP CA TIP YELLOW TIP PAID TIP PD YELLOW LAST VOID VOID INDIRECT VOID I.VOID SUB-TOTAL VOID ST VD REFUND RFND RETURN RETURN LIGHT RED LIGHT RED LIGHT RED LIGHT RED LIGHT RED...
  • Page 28 PGM#2629(MRS) PGM#2629(MRS) FUNCTION NOTE KEY TEXT KEY COLR CHARGE1 CYAN CHARGE2 CYAN CHARGE3 CYAN CHARGE4 CYAN CHARGE5 CYAN CHARGE6 CYAN CHARGE7 CYAN CHARGE8 CYAN CHARGE FOR EMPLOYEE SALES EMP CH YELLOW CURRENCY CONVERSION1 CONV1 BLUE CURRENCY CONVERSION2 CONV2 BLUE CURRENCY CONVERSION3 CONV3 BLUE CURRENCY CONVERSION4...
  • Page 29 PGM#2629(MRS) PGM#2629(MRS) FUNCTION NOTE KEY TEXT KEY COLR FUNCTION MENU7 FUNC7 LIGHT CYAN PAYMENT MENU PAYMENT MENU LIGHT GREEN DRIVE THRU MENU D-THRU LIGHT BLUE NEXT $ NEXT $ MAGENTA MENU1 MENU01 BLUE MENU2 MENU02 LIGHT BLUE MENU3 MENU03 LIGHT BLUE MENU4 MENU04 LIGHT BLUE...
  • Page 30 7. [7 DISPLAY LAYOUT] 8. [8 INIT. KEY LAYOUT] DISPLAY: Setting item select screen DISPLAY: Setting item select screen Select "7 DISPLAY LAYOUT" and press the ENTER key. Select "8 INIT. KEY LAYOUT" and press the ENTER key. Select "7 DISPLAY LAYOUT" and press the ENTER key. The setting content is discribed below.
  • Page 31 9. [9 FILE] DISPLAY: Setting item select screen DISPLAY: File group Type 0 input screen DISPLAY TEXT SELECT ITEM NOTE CREATE Select and press the LIST RECORD Key. ERASE Select the CREATE /ERASE to be changed and enter the number of records. DISPLAY: File group Type 1 input screen Select "9 FILE"...
  • Page 32 FILE TABLE -1 File table No. GROUP NO. FILE NAME TYPE (Create/Erase) Dept 01,02,03,06 Dept Text (8) Dept Text (16) Dept Display Text Dept Mark Down 16,17,19,26,31,36,41,46, 186 PLU Price 1 17,26,31,36,41,46, 186 PLU Price 1 to 5 18,51,56,61,66,71, 187 PLU Text 1 (8) PLU Text 1 (16) PLU Display Text 1...
  • Page 33 FILE TABLE -2 Table Record Block Label Data File Name Size Size Dept. preset price text (8) text (16) Display text (16) Daily Term Save Daily Consoli. Receive Daily (markdown) Term (markdown) Save Daily (markdown) Consoli. (markdown) Receive (markdown) ***** preset ***** price1...
  • Page 34 Table Record Block Label Data File Name Size Size ***** Save Daily (price1-5) (16) ***** Consoli. (price1-5) (16) ***** Receive (price1-5) (16) ***** REFUND Daily (price1-5) (16) ***** Term (price1-5) (16) ***** Save Daily (price1-5) (16) ***** Consoli. (price1-5) (16) ***** Receive (price1-5) (16)
  • Page 35 Table Record Block Label Data File Name Size Size Receive (118) Service Time Label Daily (127) Save Daily (127) Consoli. (127) Receive (127) Daily Net Label Total (132) Daily Net Consoli. Label (132) Consoli. (132) Daily Net Receive Label (132) Receive (132) *****...
  • Page 36 DISPLAY: The following display is shown. 10. [10 SUPERVISR ON/OFF] DISPLAY: Setting item select screen Select the item. 12. [12 SSP] DISPLAY: Setting item select screen Select "10 SUPERVISR" and press the ENTER key. DISPLAY: Supervisor ON/OFF screen Select "12 SSP" and press the ENTER key. SELECT DISPLAY TEXT NOTE...
  • Page 37 13. [13 IR DATA SEND] 14. [14 IR DATA RECEIVE] DISPLAY: Setting item select screen DISPLAY: Setting item select screen Select "13 IR DATA SEND" and press the ENTER key. Select "14 IR DATA RECEIVE" and press the ENTER key. DISPLAY: IR DATA SEND screen DISPLAY: IR DATA RECEIVE screen Select the item and press the ENTER key.

  • Page 38: Chapter 5. Srv Mode Programming ("3 Irc Setting")

    Select the item to be changed and press the ENTER key. CHAPTER 5. SRV MODE The setting content is described below. PROGRAMMING DISPLAY ("3 IRC SETTING") CONTENTS SELECT ITEM MRS NOTE TEXT 000 ∼ 254 TERMINAL Terminal DISPLAY: SRV mode screen GLU system CENTRALIZED Select and press SYSTEM...
  • Page 39 COPYRIGHT 1998 BY SHARP CORPORATION All rights reserved. Printed in Japan. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
