Install the Adapter

1. Shut down the computer, unplug its power cord, and
remove the chassis cover.
2. If your order does not include the Boot ROM option, go
ahead to Step 3. If your order includes the Boot ROM
option, then install the Boot ROM Chip by plugging the
chip into the Boot ROM Socket on the DFE-530TX card.
The notched end of the Boot ROM Chip must be aligned
with the notched end of the Boot ROM Socket (opposite
alignment will cause destruction of the Boot ROM
Chip).
3. Firmly insert the contact edge of the DFE-530TX card
into any available PCI Bus expansion slot.
4. Install the bracket screw to secure the card to the
computer chassis.
5. At this point, refer to section Connecting the WOL Cable
to install the WOL Cable between the NIC and the PC
motherboard.
6. Replace the computer cover.
7. Reconnect the computer power cord, and switch
computer power on.
computer boot program is Plug and Play compliant,
then at power-up the BIOS will automatically configure
any newly installed DFE-530TX adapter.
NOTE: Due to a fault in some Plug-n-Play BIOS programs, it
happens occasionally that a newly installed adapter is
assigned an Interrupt Number which is already assigned to
6
If the BIOS section of your
Installation
