Samsung HG32EC690 Installation Manual

Hide thumbs Also See for HG32EC690:
Table of Contents

Advertisement

Quick Links

LED TV
Installation manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please
register your product at
www.samsung.com/register
Model
Serial No.
[HC690-EUROPE]Install Guide-X0ENG.indd 1
2014-04-08
11:20:31

Advertisement

Table of Contents
loading

Related Manuals for Samsung HG32EC690

Summary of Contents for Samsung HG32EC690

  • Page 1 LED TV Installation manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Model Serial No. [HC690-EUROPE]Install Guide-X0ENG.indd 1 2014-04-08 11:20:31...

  • Page 2: Instruction

    ONLINE mode and full control is through the SBB/STB. If the TV is in ONLINE mode, it stops receiving IR(Samsung remote) commands and acts according to interface protocol. Stand-Alone: If SBB/STB is not identified, the TV should be switched to STAND-ALONE mode with restricted operation.

  • Page 3: Table Of Contents

    Contents Instruction ................................2 Operational Modes ............................... 2 Still image warning ............................... 2 Securing the Installation Space..........................2 Accessories................................4 Installing the LED TV Stand ..........................5 Assembling the swivel (32 inch TVs or larger) ....................... 7 Viewing the Connection Panel ..........................9 TV Controller ..............................

  • Page 4: Accessories

    Accessories ✎ Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. ✎ The items’ colour and shapes may vary depending on the model. • Remote Control & Batteries (AAA x 2) • Power Cord / Data Cable • Quick Set up Guide • Safety Guide (Not available in all locations)

  • Page 5: Installing The Led Tv Stand

    Installing the LED TV Stand The 32” and larger LED TVs have swivel stands. You can set these stands so that the TVs swivel 20 degrees left and right or 90 degrees left and right. Stand Components When installing the stand, use the provided components and parts. 1 EA B 1 EA 28"...
  • Page 6 HG32EC690 / HG40EC690 / HG48EC690 / HG55EC690 (M4 X L12) ✎ Place a soft cloth over the table to protect the TV, and then place the TV on the cloth screen-side down. ✎ Insert the Stand Guide into the slot on the bottom of the TV.

  • Page 7: Assembling The Swivel (32 Inch Tvs Or Larger)

    Assembling the swivel (32 inch TVs or larger) ] WARNING: If you configure the TV to swivel, you must attach it securely to the floor, a desk, a dresser top, etc. as described in the installation instructions. The 32” and larger LED TVs have swivel stands. You can configure these stands so that the TVs swivel 20 degrees left and right, 60 degrees left and right, or 90 degrees left and right using the BRACKET HOLDER SWIVEL.
  • Page 8 Hotel Mount Kit ¦ Bolt + Nut Short Bolt (2EA) Long Bolt (2EA) Nut (2EA) Washer (2EA) Affix the stand to a flat surface such as a Bottom dresser top, desk top, or entertainment center as shown. WARNING: To prevent injury, you must attach this TV securely to the floor, a table, a dresser top, etc. with the Hotel Mount Kit as described in these instructions.

  • Page 9: Viewing The Connection Panel

    Viewing the Connection Panel HG28EC690** HG32EC690** HG40EC690** HG48EC690** HG55EC690** ✎ Whenever you connect an external device to your TV, make sure that power on the unit is turned off. ✎ When connecting an external device, match the colour of the connection terminal to the cable.
  • Page 10 AV IN – Connect audio cables to "R-AUDIO-L" on your TV and the other ends to corresponding audio out jacks on an A/V device. – Connects Component video / audio. – Connect RCA audio cables (optional) to "R - AUDIO - L" on the rear of the TV set and the other ends to corresponding audio out jacks on the external device.
  • Page 11 ✎ Optimal resolution is 1920 X 1080 @ 60 Hz. Horizontal Frequency Vertical Frequency Pixel Clock Frequency Sync Polarity Mode Resolution (KHz) (Hz) (MHz) (H / V) 720 x 400 31.469 70.087 28.322 640 x 480 35.000 66.667 30.240 832 x 624 49.726 74.551 57.284...
  • Page 12 7 RJP: This port is an RJP (Remote Jack Pack) communication port that enables connecting different devices to additional modules to improve device use and convenience. PC/ DVI AUDIO IN: Connects to the audio input jacks on an Amplifier/Home Theater. 9 VOL-CTRL: Used to control the volume of the Bathroom speaker.

  • Page 13: Tv Controller

    TV Controller TV Controller is a multi directional button that helps navigate without using the remote control. ✎ Some functions which require a PIN code may not be available. ✎ The product colour and shape may vary, depending on the model. ✎...

  • Page 14: Viewing The Remote Control

    Viewing the Remote Control ✎ This remote control has Braille points on the Power , Channel , and Volume buttons and can be used by visually impaired persons. Turns the TV on and off. Display and select available video sources. Have direct access to channels Alternately selects Teletext, Double or Mix.

  • Page 15: Connecting The Tv With Sbb

    Installing batteries (Battery size: AAA) ✎ NOTE • Use the remote control within 23 feet of the TV. • Bright light may affect the performance of the remote control. Avoid using nearby special fluorescent light or neon signs. • The colour and shape may vary depending on the model. • Remote control button 'HOME' &...
  • Page 16 List of Vendors and Compatible Data Cables Supplied with the TV ¦ • Confirm that you are using the correct data cable for your vendor. Refer to the code label on the data cables. English [HC690-EUROPE]Install Guide-X0ENG.indd 16 2014-04-08 11:20:40...

  • Page 17: Connecting The Bathroom Speakers

    Connecting the Bathroom Speakers You can connect the Bathroom Speakers using the following method. Connecting through the Variable Output (available without an external amplifier) ¦ TV Rear Panel Speaker VOL+ Volume Control Box VOL- 1. Connect the VARIABLE AUDIO OUT port of the TV to the Bathroom Wall Speakers of the hotel.
  • Page 18 Audio Loop In ¦ An additional Headphone Box can be installed on a bed or business desk for added convenience. The installation procedures are given below. • Detailed Drawing of the Headphone Box. TV Rear Panel HEADPHON BOX Headphone Box Shield wire TV Headphones jack Red Wire (Audio-R)

  • Page 19: Connecting The Mediahub Hd

    Connecting the MediaHub HD Output to any external source connected to MediaHub HD on the hotel desk. MediaHub HD Rear TV Rear Panel HDMI RS/232 1 RS-232 Data Cable 2 HDMI cable 1. Connect the port of the TV and the RS/232 port of the MediaHub HD. 2.

  • Page 20: Connecting The Rjp (Remote Jack Pack)

    5. Connect the port of the TV and the RS/232 port of the RJP. ✎ The RJP (Remote Jack Pack) compatible with this Samsung TV is TeleAdapt TA-7610, TA-7650 (HD) and TA- 7660 (HD Plus). • RJP (Remote Jack Pack): RJP stands for Remote Jack Pack. The RJP is a hardware module that has different Audio Video inputs (A/V, Audio, PC and HDMI) and corresponding outputs.
  • Page 21 • The RJP can be returned to the factory default settings by pressing the A/V and HDMI buttons simultaneously for 10 seconds. All LEDs blink 5 times to acknowledge that this has been finished. • The RJP will automatically turn off any LEDs after 5 minutes to avoid unnecessary light pollution in the hotel room. The LEDs that were turned off will turn on again if the guest touches any of the buttons and the 5 minute timer will restart.

  • Page 22: Connecting To A Common Interface Slot (Your Tv Viewing Card Slot)

    Connecting to a COMMON INTERFACE slot (Your TV viewing Card Slot) ✎ Scenario 1: When no inputs are connected. Attaching the CI Card Adapter Attach the adapter as shown side. ✎ To install the CI CARD Adapter, please remove the sticker attached to the TV. To connect the CI CARD Adapter, follow these steps.

  • Page 23: Setting The Hotel Option Data

    • Interactive mode : TV works with an SI STB or SBB. • Standalone mode : TV works alone, without an SI STB or SBB. • Interactive mode : Samsung / OCC / MTI / Nstreams / Enseo / Cardinal / SI Vendor...
  • Page 24 Hotel TV Function Description Category Item initial value When there is a mismatch between the data in the channel map and the transmitted data , the TV autotunes the channels to restore the data/parameters in the channel map. Channel Rescan • On: When Channel Rescan Message is ON, The OSD showing that the Message channels are being rescanned will be displayed to Hotel Guests.
  • Page 25 … • BMP or AVI files only. • Max file size : BMP - 960 X 540. AVI - 30MB. • The file can only be named samsung.bmp or samsung.avi. Logo Display Time … Hospitality Logo Display Time (3/5/7 seconds).
  • Page 26 Hotel TV Function Description Category Item initial value REACH Server 1hour Standby REACH Server will be operated, according to time setting Update Time REACH Update Make TV operate REACH Server after 1 minute in Stand-by mode. Immediate Set the default channel for REACH Server REACH Server …...
  • Page 27 Welcome Message ¦ The welcome message is used to display custom messages on the TV every time TV is turned on by a Guest in Hotel room. – Welcome message settings are found in the Hotel Option Menu. – Welcome message should be ON in order to display the message on power-on. Hospitality Mode Standalone Widget Solution...
  • Page 28 • Logo File Format – The TV supports only BMP and AVI format. – The file name must be samsung.bmp or samsung.avi. – The maximum resolution of the BMP format is 1280 x 720. – The maximum file size for AVI format is 50MB.
  • Page 29 USB Cloning ¦ USB Cloning is used to download user-configured settings (Picture, Sound, Input, Channel, Setup, and Hotel Setup) from one TV set and upload them to other TV sets. All the user-defined settings from the TV (Master Set) can be copied to the USB device. • Cloning from TV to USB: This copies stored data from the TV set to the USB device.
  • Page 30 Setting Auto Initialize ¦ When you clone settings from one TV to another, you clone both the guest side menu and hotel side menu settings: Picture, Sound, Input, Channel, Setup, and Hotel Setup). This lets you set nearly all of the menu values on your hospitality TVs to the same, standard settings.
  • Page 31 Plug & Play ¦ Hotel Plug & Play automatically performs Hotel mode selection, Country Setup, Clock Setup and Picture mode Setup. – Hotel Plug & Play is available only one time when power is first turned ON. – This is available after first setting up the TV and transferring Clone TV data to a USB drive. –...
  • Page 32 – When Standalone Plug & Play is selected from “Easy Set Up” OSD, “Select Menu Language” OSD is displayed. – Initial Highlight : English – Display time: OSD timeout and operation are the same as Samsung's consumer TV models. – If the ENTER button is pressed, “Select Area”...
  • Page 33 Multi Code Remocon ¦ Multi Code Remocon is a special transmitter which is designed to control each TV with one remote. This is useful where there is more than one TV in a location, such as in a hospital the set ID number is displayed in the source osd.
  • Page 34 CH Bank Editor (Smoovie TV Only) ¦ Channel Bank Editor edits channels, with 3 different Bank Options. Depending on the Bank card, there are specific channels Hotel customers can enjoy. Setting the CH Bank Editor under Stand-alone Mode 1. Enter the Hotel Standalone menu by “MUTE+1+1+9+Enter” 2.
  • Page 35 Channel Editor ¦ Channel Editor edits channel number a and name. – Use Channel Editor to sort the channels as user-desired channel numbers. Hospitality Mode Standalone Widget Solution SI Vendor System Power On Channel Menu OSD Clock Music Mode Remote Jack Pack Channel Editor External Source Bathroom Speaker...
  • Page 36 Smovie TV used( Satellite ) Mixed Channel Map On (Satellite and Air or Cable both usedused) Only Satellite used Step If the tv starts with Hotel P&P If P&P alredy done If the tv starts with Hotel P&P If P&P alredy done Do P&P all: Air or Cable auto Do the P&P except channel store Enter Hotel menu...
  • Page 37 How to use Schedule Viewing in Channel List (digital channels only) When you set the Schedule Viewing in Channel List, you can only set the programme in Programme View. 1. Press the CH LIST button, then select a desired digital channel. 2.
  • Page 38 My Channel ¦ Determines the country and genre for the channels provided by the hotel, and if the user selects a country and genre, shows the corresponding channels. • You must select the country first, or you can not set a genre. • If you select the genre without adding any channels, the channel list displays all of the available channels.
  • Page 39 ✎ Notes • This section describes the layout of the Front UI that appears when the TV is turned on. (Factory Mode > Genre Mode: Enable) • The genre is a sub-list for each country. • The broadcast screen that was being displayed the last memorial channel. –...
  • Page 40 Highlight Interaction [Country Items] • This page is only to indicate possible interactions. It may not be exactly identical to actual screens. ✎ Notes • Users can navigate the items in each country & genre list by pressing the up or down remote control keys. • Circular navigation is supported.
  • Page 41 Highlight Interaction [Default Genre] • This page is only to indicate possible interactions. It may not be exactly identical to actual screens. My Channel My Channel Current status : All Country/Sports Current status : All Country/Sports Country Genre Country Genre ▲...
  • Page 42 Mode Change Interaction 1 (1/2) • This page is only to indicate possible interactions. It may not be exactly identical to actual screens. My Channel My Channel Current status : All Country/Sports Current status : All Country/Sports Country Genre Country Genre ▲...
  • Page 43 Mode Change Interaction 1 (2/2) • This page is only to indicate possible interactions. It may not be exactly identical to actual screens. My Channel Current status : All Country/Sports Country Genre ▲ ENTER All Country Austria News Belgium (Dutch) Radio Genre Mode change to Austria/News.
  • Page 44 Mode Change Interaction 2 (1/2) • This page is only to indicate possible interactions. It may not be exactly identical to actual screens. My Channel My Channel Current status : All Country/Sports Current status : All Country/Sports Country Genre Country Genre ▲...
  • Page 45 Power On Scenario [Last Memory] • This page is only to indicate possible interactions. It may not be exactly identical to actual screens. POWER Current Status : Austria / News Power Off • Current Genre Mode : Austria / News POWER My Channel Current status : All Country/Sports...
  • Page 46 Genre Editor: This configures the genres of each of the hotel TV channels. • This can be used through the Hotel Menu (Factory). • Supported genres include News, Radio, Entertainment, Sports and Hotel. • More than one genre can be selected for each channel at the same time. Country Editor (Channel Editor): This is the editor that configures the country for each of the hotel TV channels.
  • Page 47 Elements Name Description • When the user enters this screen, the currently selected default item is highlighted. • The Country Icon + Category Name are provided. (If the highlight is in the Main Frame, only the icon is displayed.) • Moving the highlight –...
  • Page 48 ✎ Notes • This is a definition of the Tools menu in the Left Frame Category. • Only the Info item for each Register/Country is provided. Elements Category Tools menu Descriptions Registered, Country Information Registered Channels. The number of channels of each country. • • The items are displayed without ‘Channel’.
  • Page 49 ✎ Notes • This is the component for when there are no channels registered to the country category. Elements Description Description The message is displayed when the currently selected country does not contain any items. Main Frame [Channel Browser] English [HC690-EUROPE]Install Guide-X0ENG.indd 49 2014-04-08 11:20:51...
  • Page 50 Key Guide Button Action Nav. Help CH UP/DOWN Moves the page. Page ENTER Selects or enters the corresponding Channel Browser area. Select RETURN Returns to the previous step (Factory Mode). Return UP/DOWN Moves the highlight up or down. (No Guide) RIGHT Moves the highlight to the Channel Browser area.
  • Page 51 Channel Common Elements [+ Icon-method] Channel list representation rules Standard Item Construction • Check Box + Status Icon + Digital Channel Number + Channel Name Digital channels • Channel number representation format: ###-### (The channel number is represented by ‘-’.) ATSC • Check Box + Analog Icon + Analog Channel Number + Channel Name Analog channels...
  • Page 52 Add to Countries / Edit Countries (1/2) • Channel Manager > Browser > Tools > Add to Countries Key Guide Button Action Nav. Help ENTER Selects the highlighted item. Enter Cancels and returns to the previous screen (Tools). Return RETURN UP/DOWN Moves the highlight over country items.
  • Page 53 Elements Name Description • If there are no channels that have been registered to the country list in Add to Countries the selected channels, “Add to Countries” is displayed as the title. • A check box is displayed depending on whether the country that was Window selected when entering the screen is registered or not.
  • Page 54 ✎ Notes • This is the definition for Edit Countries. • The highlighted channel item or more than one selected channel item is added or deleted from the Country category. • Timeout (60 sec) Elements Name Description • If there is a registered channel among the selected channels, Edit Coun- tries is displayed as the title.
  • Page 55 Elements Name Description • Both the numeric keys and the Up/Down keys are supported. – Selected Channel: Shows the currently selected channel name. – Number: Shows the new channel number. Edit Channel (The currently allocated channel name is also displayed.) Number Window –...
  • Page 56 Key Guide Button Action Nav. Help If a user presses the button, the channel number is initialized. Reset ENTER Applies the changes and closes the window. Enter RETURN Cancels or returns to the previous screen (Tools). Return Changes the channel number of the selected channel. Adjust 0~9T Enters a digit.
  • Page 57 Edit Channel Name • Channel Manager > Browser > Tools > Edit Channel Name Key Guide Button Action Nav. Help GREEN Saves the changes and returns to the Channel Manager. Done ENTER Saves the channel name and moves the cursor to the next field. Enter RETURN Cancels and returns to the previous screen (Tools).
  • Page 58 Tools [Edit Mode] Edit Mode Content Highlight (when the number of the checked item is 0 or 1) When there is more than one checked item. Add to Countries Edit Countries (when an already-registered item is checked.) Add to Countries Channel Name Edit Edit Countries (when an already-registered item is checked.) Edit Channel Number...
  • Page 59 CH Banner [when a channel number is allocated to an external input] ✎ Notes • The TV channel banner specifications are applied. • When there is an unsupported item or there is no corresponding information, the item values are not displayed. • The channel name is represented as the ‘external input name’.
  • Page 60 Sound Bar ¦ • Samsung Sound-Bar & Hospitality TV – Use Samsung Sound-Bar & hospitality TV support HDMI 1.4 to listen to TV sound on the Sound-Bar by using a single HDMI cable. – Supporting model. • Sound-Bar : HW-F350/F450/F550 • Operation of “Hotel Mode”...

  • Page 61: Sirch

    SIRCH • Introduction SIRCH (Samsung Interactive Remote Control for Hospitality) is a professional interactive remote controller for DTV that lets you deliver TV firmware updates, cloning data, and channel mapping changes to several hundred hospitality TVs simultaneously. Mounted at the broadcast head-end system in hotels, motels, resorts, hospitals, and apartment buildings, it delivers modulated RF control signals to hospitality sets in each guest room through coax cable.
  • Page 62 – Plan to use Manual SIRCH to test whether SIRCH has been installed properly. ✎ NOTE • Please visit www.lumantek.com/sirch/ for more information. • SIRCH Windows Application Program User's Manual is available at http://www.samsung.com/us/business/ hospitality. English [HC690-EUROPE]Install Guide-X0ENG.indd 62 2014-04-08...
  • Page 63 ¦ • System Overview The ‘Samsung Interactive Remote Control for Hospitality (SIRCH)’ application is a Remote Control Update system designed to provide better and more cost-effective service for Hospitality industries. This allows user/operators to configure the guest TV with RF distributing system. Using this helps the user to set and configure the guest room TV Set parameters.
  • Page 64 GETTING STARTED ¦ • Installation instructions for Windows XP/Vista/2007 1. To install Samsung Interactive Remote Control for Hospitality (SIRCH), locate and open the setup directory of SIRCH and double-click on the file “setup.exe”. 2. Click on Next Button to proceed for Installation wizard of SIRCH.
  • Page 65 3. User can choose options form File Menu to proceed to his specific application requirement. • Uninstalling SIRCH Application 1. To uninstall SIRCH go to StartMenu → Programs → Samsung → SIRCH → Uninstall.exe. 2. Follow the steps of uninstall wizard. English [HC690-EUROPE]Install Guide-X0ENG.indd 65...
  • Page 66 • Create New Clone Files After launching SIRCH, the application shows a window asking for Model and Mode selection. The application starts with the utility to create new clone files thus other utilities can be called from File Menu. To create new files user may follow the following steps: 1.
  • Page 67 • Modify existing Clone files To modify the existing clone files, the user must follow these steps: 1. Go to File Menu → Load from file. If the option is disabled user is probably on the next screen so he must come back to main screen by clicking back button.
  • Page 68 • Hospitality Options Setting After clicking Proceed the application navigates users to another screen with different tabs: next screen with different tabs Hospitality Options, channel map and generate navigating to other Tabs does not lead to any loss of unsaved data.
  • Page 69 • Channel Map Configuration The Channel Map tab shows a list of channels in a table with every channel, channel name, PTC no., Program No., Modulation and Program Type shown. Channel map information is only configured for English. Channel names in any other language, in a clone file loaded from a TV, will remain undisturbed after changes resulting from the SIRCH application.
  • Page 70 • Modifying an existing Channel from the list To modify parameters for an existing channel , including PTC number, program type, etc., follow these steps: 1. Select Air, Cable or Satellite. 2. Select Analog or Digital. 3. Select the channel from the list to Modify and click on Modify button. 4.
  • Page 71 • Saving Clone Files To save the clone files with modified parameters and channel map configuration, user must follow these steps: 1. When finished changing data on the Interactive/Standalone menu and one the Channel map, click Save. 2. A browser window open, asking for the location to save the data.
  • Page 72 • Launching Ventus application Go to File Menu → Utility → Generate and click GO for Launch Ventus • Upgrading the clone or binary file on TV To upgrade the clone for binary file on the TV, use a prepared merged stream (Binary_outputstream.mpg or clone_ outputstream.mpg).
  • Page 73 • Update SIRCH Version To update the SIRCH version for Clone and user should follows as below. 1. Go to File Menu → Update Software Version. 2. A window opens asking for the Software Version (Clone File Up gradation). 3. User should provide a higher version than the TV's current version in version value. E.g. If software version is set as 01a0 in SIRCH PC application, then current TV SIRCH version should be less than this value for update.
  • Page 74 • FAQs If SIRCH has a problem, first review this list of possible problems and solutions. • Test SIRCH modulator controller settings: – The SIRCH upgrade only supports OpenCable & DVB-C – Recommended settings: – Parameters Constellation: 64 QAM – Remux(H/W) : Off –...
  • Page 75 – PC application: SIRCH Version (Clone): 0002, TV SIRCH Version: 0002. Update is not possible. – Merge TV Binary : support to upgrade Main SW. – You need to contact Samsung to use Merge TV Binary. – Merge TV Binary cannot upgrade Sub Micom English [HC690-EUROPE]Install Guide-X0ENG.indd 75...
  • Page 76 • Merged TS Stream should be located in D:\stream\OpenCable(US) or D:\stream\DVBC(EU) – You can check the SIRCH merged stream if you tune to the SIRCH channel. English [HC690-EUROPE]Install Guide-X0ENG.indd 76 2014-04-08 11:20:56...
  • Page 77 • Cautions for Hospitality mode options – Hospitality Mode: should be Standalone. – Interactive mode cannot support SIRCH. – Power On Source must be set to TV. If you select other external sources, SIRCH cannot support an upgrade. – If you try to upgrade SIRCH in external source (PC/HDMI…), SIRCH could not support upgrade by manual SIRCH / SIRCH Update Time.

  • Page 78: Installing The Wall Mount

    Contact a technician for assistance when installing the wall mount bracket. We do not advise you to do it yourself. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you select to install the TV on your own.

  • Page 79: Securing The Tv To The Wall

    Anti-theft Kensington Lock The Kensington Lock is not supplied by Samsung. It is a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration, depending on the manufacturer.

  • Page 80: Specifications

    10% to 80%, non-condensing Storage Temperature -4°F to 113°F (-20°C to 45°C) Storage Humidity 5% to 95%, non-condensing Model Name HG28EC690 HG32EC690 HG40EC690 Display Resolution 1366 x 768 1920 x 1080 Stand Swivel (Left / Right) 0˚ 20˚ / 60˚ / 90˚...

  • Page 81: Dimensions

    Dimensions ▪ Front view / Side view HG28EC690 (Unit: mm) HG28EC690 643.4 609.5 347.0 311.4 396.5 435.1 62.9 163.4 HG32EC690 / HG40EC690 / HG48EC690 / HG55EC690 (Unit: mm) HG32EC690 721.4 700.4 394.8 450.8 428.5 465.6 49.1 192.6 HG40EC690 906.6 887.6 500.2...
  • Page 82 ▪ Jack panel detail / Rear view HG28EC690 (Unit: mm) HG28EC690 271.7 140.5 147.3 78.7 113.5 392.4 HG32EC690 / HG40EC690 / HG48EC690 / HG55EC690 (Unit: mm) 260.2 95.9 176.5 114.2 110.5 477.7 HG32EC690 HG40EC690 352.8 124.0 195.4 156.3 196.9 620.8 HG48EC690 337.0...
  • Page 83 ▪ Base Stand detail HG28EC690 / HG32EC690 (Unit: mm) 311.4 163.4 122.5 HG40EC690 / HG48EC690 / HG55EC690 (Unit: mm) R9.5 R3.8 556.5 149.5 NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV.
  • Page 84 Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Customer Care Centre Web Site AUSTRIA 0810 - SAMSUNG (7267864, € 0.07/min) www.samsung.com BELGIUM 02-201-24-18 www.samsung.com/be (Dutch) www.samsung.com/be_fr (French)
