2. Open a miguser session using the following command (the default password for miguser is
migration.):
miguser start -p migration
3. To access the array properties, enter the following command:
set array
4. Select a target ID by entering its index number.
5. At the prompts, modify the symbolic name, target type, or array bandwidth for the source and
destination arrays.
NOTE:
The DM CLI allows you to change the Bandwidth for Migration setting only if the Target Type
is either Source or Src+Dest Target.
6. At the Do you want to apply array license (yes/no) prompt, enter Yes (the default
is No) to apply your changes.
The following example shows how to change the array properties in the CLI.
MPX200 (miguser) #> set array
A list of attributes with formatting and current values will follow.
Enter a new value or simply press the ENTER key to accept the current value.
If you wish to terminate this process before reaching the end of the list
press 'q' or 'Q' and the ENTER key to do so.
Index WWPN, PortId
0 20:78:00:c0:ff:d5:9a:05, 00-00-00
1 50:00:1f:e1:50:0a:e1:49, 82-07-00
2 50:06:01:60:4b:a0:35:de, 82-03-00
3 50:00:1f:e1:50:0a:37:18, 00-00-00
Please select a Target Id from the list above ('q' to quit): 0
Symbolic Name (Max = 128 characters)
Target Type (1=SrcTarget, 2=DstTarget, 3=Src+Dest 4=None Target) [3
Bandwidth for Migration (0=Array Bandwidth, 50-1600 MBps )
Enable Load Balancing (0=Enable, 1=Disable)
Array based licensed applied.
All attribute values for that have been changed will now be saved.

Creating a Data migration job group

The HP StorageWorks mpx Manager provides both GUI and CLI interfaces to view and edit array
properties, including the bandwidth.

Setting array properties in the GUI

Follow these steps to create a data migration job group in the mpx Manager GUI:
1. In the left pane, select the Services tab to open the Services page.
By default, the MPX200 shows Group 0 created under the Data Migration Jobs item.
2. Right-click Data Migration Jobs, and from the shortcut menu, click Add Group.
154 Offline Data Migration
Symbolic Name Target Type
HP MSA2012fc-0 Src+Dest
HP HSV200-1 Src+Dest
DGC RAID-2 Src+Dest
HP HSV210-3 Src+Dest
[HP MSA2012fc-0]
]
[0 ]
[Enabled ]
