Hardware setup
For information on installing your MPX200 Multifunction Router, see "Installing the MPX200" in the
HP StorageWorks MPX200 Quick Start Instructions.
To set up the hardware for DMS:
1.
To manage the MPX200, the MPX200 must be accessible over the network connection from the
machine on which the mpx Manager is installed.
2.
Set up the MPX200 management port IP address. For details, see the HP StorageWorks MPX200
Multifunction Router Quick Start Guide.
3.
Connect the storage array (source and destination) controller ports to an Fibre Channel switch.
For a high availability topology, connect the two ports of each array on two different switches.
4.
Ensure that the controller ports are seen as online on the Fibre Channel switches.
5.
Connect the Fibre Channel ports of the MPX200 to the Fibre Channel switches where the array
controller ports are connected. For an HA topology, connect each Fibre Channel port of the
MPX200 to a different Fibre Channel switch.
6.
Ensure that the MPX200 Fibre Channel ports are seen as online on the Fibre Channel switches.
Software setup
Software setup for DMS includes configuring switch zoning and LUN presentation:
•
Zoning: Perform zoning on the Fibre Channel switches such that array controller ports are visible
to the MPX200, and the array is able to see MPX200 Fibre Channel ports and can present LUNs
to the MPX200.
•
LUN Presentation: Ensure the appropriate data LUNs are presented from the storage arrays to the
MPX200.
NOTE:
For HA configurations where the source or destination LUNs are visible from both MPX200 ports,
make sure that both MPX200 ports are configured under a single host or host group entity in the
array management software. This ensures that both MPX200 ports present the same set of LUNs to
have the same LUN ID. Failure to do so can lead to unpredictable and erroneous behavior.
Using DMS
General steps for data migration
To perform data migration:
1.
Plan for data migration.
2.
Zone the Fibre Channel ports from the MPX200 with the Fibre Channel ports of the storage array.
3.
Present the source LUNs and destination LUNs to the MPX200 using the array vendor's
configuration tools; for example, use Command View for HP Enterprise Storage Array (EVA) or
Navisphere for EMC CLARiiON.
150
Offline Data Migration
