Chapter 5
Preview Configuration
NOTE
Refer to Worksheets A and B when checking the
configuration.
The HP NetRAID Assistant Wizard Configuration Preview window, shown in
Figure 5-8, displays the configuration proposed for the physical and logical
drives.
Figure 5-8. HP NetRAID Assistant Wizard Configuration Preview Window
NOTE
The RAID level of a logical drive that spans arrays lacks the
terminal zero. Mentally add it to make RAID 1 into RAID 10
and RAID 5 into RAID 50.
Installation and Configuration
59
