Quick setup for Telephone Conference Calls

While all components delivered with the Revolabs FLX2 Conference Phone are partially
charged, we recommend charging the Speaker, the Microphones, and the Dialer for at
least 8 hours or overnight before configuring and using the system.
Please note that the Revolabs FLX2 Conference Phone comes with two different power
supplies. Please ensure that you are using the correct power supply when connecting
the Base Station and the Charger Base.
Connecting the Base Station
Place the Base Station close to the analog
telephone outlet you want to use for the
conference phone. Connect the Base Station to
the telephone network using the provided RJ 11
Telephone cable. Use the 5 Volt power supply to
connect the Base Station to the power outlet.
The Base Station will power up.
Connecting the Charger Base
Place the Charger Base at a location where you
can easily access the Microphones and the
Speaker for your conference calls, e.g. on a side
board, a desk, or the conference table. Connect
the Charger Base to the power outlet using the
provided 12-15V power supply. Place the
Speaker, the Microphones, and the Dialer in the
respective openings of the Charger Base to
charge them.
The Dialer and Speaker will automatically connect
to the Base Station after a short time if it is
powered up. You will hear a confirmation chime
from the Speaker once the system is ready for
use. If the Speaker or the Dialer is not powered
up, take them out of the Charger Base for a few
seconds and put them back in. This will switch on
the component.
To switch on the microphones
take them out of the charger
base. They will automatically
power up and connect to the
base station.
