FC.02
0:RTU,1 start bit,8 data bits,no parity check,1 stop bit.
1:RTU,1 start bit,8 data bits,even parity check,1 stop bit
2:RTU,1 start bit,8 data bits,odd parity check,1 stop bit
3:RTU,1 start bit,8 data bits,no parity check,2 stop bit.
4:RTU,1 start bit,8 data bits,even parity check,2 stop bit
5:RTU,1 start bit,8 data bits,odd parity check,2 stop bit
6:ASCII,1 start bit,7 data bits,no parity check,1 stop bit.
7:ASCII,1 start bit,7 data bits,even parity check,1 stop bit
8:ASCII,1 start bit,7 data bits,odd parity check,1 stop bit
9:ASCII,1 start bit,7 data bits,no parity check,2 stop bit.
10:ASCII,1 start bit,7 data bits,even parity check,2 stop bit
11:ASCII,1 start bit,7 data bits,odd parity check,2 stop bit
12:ASCII,1 start bit,8 data bits,no parity check,1 stop bit.
13:ASCII,1 start bit,8 data bits,even parity check,1 stop bit
14:ASCII,1 start bit,8 data bits,odd parity check,1 stop bit
15:ASCII,1 start bit,8 data bits,no parity check,2 stop bit.
16:ASCII,1 start bit,8 data bits,even parity check,2 stop bit
17:ASCII,1 start bit,8 data bits,odd parity check,2 stop bit
This parameter defines the data format used in serial communication protocol.
Code
FC.03
This parameter means the interval time when the drive receive the data and sent it to
the upper monitor.If the answer delay is shorter than the system processing time,then the
answer delay time is the system processing time,if the answer delay is longer than the
system processing time,then after the system deal with the data,waits until achieving the
answer delay time to send the data to the upper monitor.
Date format
Name
Communication on delay time
126
0ÿ^50 00
Setting Range
0ÿ^200mS0 5mS0
