Diagrams

5-1.CIRCUIT BOARD LOCATION
5-1-1 KDL- 32"
HTL BOARD
(HOTEL MODEL ONLY)
**SMART
B* Board Type
(Segment: LW)
Size
OTHERS EUROPE JAPAN
32" BKX/BLX BKE/BLE BKJ/BLJ
B** BOARD
CHASSIS BOX(OTHERS)
SWITCH
UNIT
(HUS)
CHASSIS BOX(EU)
CORE
B** BOARD
TUNER (BKT)
BOARD (EU)
SWITCH
UNIT
(HUS)
** SMART CORE BLOCK <SIDE VIEW>
WLAN MODULE
(WIFI)
HSC BOARD
SECTION 5
DIAGRAMS
5-1-2. KDL-42"
HTL BOARD
(HOTEL MODEL ONLY)
**SMART CORE
B* Board Type
(Segment: LW)
Size
OTHERS EUROPE
42" BKX/BLX BKE/BLE
HIR BOARD
W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/
W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A
CHASSIS BOX(OTHERS)
SWITCH UNIT (HUS)
CHASSIS BOX(EU)
B**
JP BOARD
SWITCH
UNIT
BKJ/BLJ
(HUS)
RB1G CHASSIS
B** BOARD
TUNER (BKT)
BOARD (EU)
232
