APPENDIX A
This appendix contains information about the SIMATIC HawkEye™ 1600T
connectors:
• "Power & Primary I/O Connector" on page A-2
• "Serial & Secondary I/O Connector" on page A-4
• "Ethernet Connector" on page A-6
• "Light Port Connector" on page A-7
• "QuickSet® Switch" on page A-8
