Specifications

This appendix provides general specifications including mechanical,
environmental and electrical for the Gigabit Ethernet/82543 PMC Module.

Safety Compliance

The Gigabit Ethernet/82543 PMC Module is a UL listed accessory.
This equipment is to be used only with products that are certified by an
internationally recognized safety organization (for instance, UL or CSA).

Physical Requirements

The Gigabit Ethernet/82543 PMC Module measures 149 mm by 74 mm
and is constructed using six-layer circuit board technology with four signal
layers and two power/ground layers. The PMC uses 32- and 64-bit PCI bus
connectors.
The PMC must be installed on a host module (for example, an SBC or
carrier card) that has an available PMC slot with a removable front panel
slot cover.
Ethernet/82543 PMC Module.
Characteristic
Form factor
PMC conformance
PCI interface
PCI controller
Protocols
BSpecifications
Table 3-1 gives the physical specifications of the Gigabit

Table 3-1. Physical Specifications

Specification
Single PMC
IEEE P1386.1/Draft 2.0
32- or 64-bit, 33 or 66 MHz master and slave PCI
Intel 82543GC
Ethernet 10 BaseTx, 100 BaseTx, 1000 BaseTx
B
B-1
