Plug-in Portable Test Unit (PTU)

Specially designed for reliable testing of the MCR and HSISC
protection systems on each phase, by means of tertiary
injection. The test unit is also used to prove both overcurrent
and earth fault pick-up levels. Can also be employed to
test for tripping in order to verify efficient microprocessor
operation. The test unit incorporates a set of rechargeable
batteries and includes a charger unit as standard.

Accessories Performance Data

Device
Auxiliary & carriage switch
Motor operator
Closing coil
Shunt trip
Instantaneous undervoltage
release
Auxiliary power unit
Operating Voltage (V)
AC DC
250
125
250
220-250 -
110-130 110-130
380-440 48, 60
24-30
220-250 220-250
110-130 110-130
380-440 48
24-30
220-250 220-250
110-130 110-130
380-440 48
24-30
380-440 110-130
220-250 30-48
110-130
110, 220, 380 110, 220

Auxiliary Power Unit (APU)

Available to be fi tted within the circuit breaker cubicle, an APU
ensures that MPRO receives independent and continuous
power at all times. The APU accepts any input supply voltage
within 380VAC, 110V, 220V AC/DC. Maximum input current
is 0.5 A. 1m length cable (twisted pair) should be used to
connect auxiliary supply and MPRO protection relay.
Operating range
-
-
-
0.85 to 1.1 times
rated voltage
0.85 to 1.1 times
rated voltage
0.70 to 1.1 times
rated voltage
-
-
-
-
M-PACT Plus
Rating
(Amps resistive)
10
5
0.25
AC-50VA
DC-50W
AC-300VA
DC-250W
AC-300VA
DC-250W
Inrush power consumption 300VA
Holding power consumption 20VA
-
A
B
C
X
A.23
