GE D90 Plus Communications Manual page 93

CHAPTER 2: MODBUS COMMUNICATION
Address Description
64D0 Overfrequency 1 Function
64D1 Overfrequency 1 Block
64D2 Overfrequency 1 Source
64D3 Overfrequency 1 Pickup
64D4 Overfrequency 1 Pickup Delay
64D5 Overfrequency 1 Reset Delay
64D7 Overfrequency 1 Events
64D8 Reserved (4 items)
64DC ...Repeated for Overfrequency 2
64E8 ...Repeated for Overfrequency 3
64F4 ...Repeated for Overfrequency 4
Power Swing Detect (Read/Write Grouped Setting)
65C0 Power Swing Detect Function
65C1 Power Swing Detect Source
65C2 Power Swing Detect Mode
65C3 Power Swing Detect Supervision
65C4 Power Swing Detect Forward Reach
65C5 Power Swing Detect Forward RCA
65C6 Power Swing Detect Reverse Reach
65C7 Power Swing Detect Reverse RCA
65C8 Power Swing Detect Outer Limit Angle
65C9 Power Swing Detect Middle Limit Angle
65CA Power Swing Detect Inner Limit Angle
65CB Power Swing Detect Delay 1 Pickup
65CC Power Swing Detect Delay 1 Reset
65CD Power Swing Detect Delay 2 Pickup
65CE Power Swing Detect Delay 3 Pickup
65CF Power Swing Detect Delay 4 Pickup
65D0 Power Swing Detect Seal In Delay
65D1 Power Swing Detect Trip Mode
65D2 Power Swing Detect Block
65D4 Power Swing Detect Event
65D5 Power Swing Detect Shape
65D6 Power Swing Detect Quad Forward Middle
65D7 Power Swing Detect Quad Forward Outer
65D8 Power Swing Detect Quad Reverse Middle
65D9 Power Swing Detect Quad Reverse Outer
65DA Power Swing Detect Outer Right Blinder
65DB Power Swing Detect Outer Left Blinder
65DC Power Swing Detect Middle Right Blinder
65DD Power Swing Detect Middle Left Blinder
65DE Power Swing Detect Inner Right Blinder
65DF Power Swing Detect Inner Left Blinder
Load Encroachment (Read/Write Grouped Setting)
6700 Load Encroachment Function
6701 Load Encroachment Source
6702 Load Encroachment Minimum Voltage
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
Range Units
0 to 1 ---
0 to 65535 ---
0 to 5 ---
20 to 65 Hz
0 to 65.535 s
0 to 65.535 s
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 5 ---
0 to 1 ---
0.05 to 30 pu
0.1 to 500 ohms
40 to 90 degrees 1
0.1 to 500 ohms
40 to 90 degrees 1
40 to 140 degrees 1
40 to 140 degrees 1
40 to 140 degrees 1
0 to 65.535 s
0 to 65.535 s
0 to 65.535 s
0 to 65.535 s
0 to 65.535 s
0 to 65.535 s
0 to 1 ---
0 to 65535 ---
0 to 1 ---
0 to 1 ---
0.1 to 500 ohms
0.1 to 500 ohms
0.1 to 500 ohms
0.1 to 500 ohms
0.1 to 500 ohms
0.1 to 500 ohms
0.1 to 500 ohms
0.1 to 500 ohms
0.1 to 500 ohms
0.1 to 500 ohms
0 to 1 ---
0 to 5 ---
0 to 3 pu
MODBUS MEMORY MAP
Step Format Default
1 F102 0 (Disabled)
1 F300 0
1 F167 0 (SRC 1)
0.01 F001 6050
0.001 F001 500
0.001 F001 500
1 F102 0 (Disabled)
1 F001 0
1 F102 0 (Disabled)
1 F167 0 (SRC 1)
1 F513 0 (Two Step)
0.001 F001 600
0.01 F001 5000
F001 75
0.01 F001 5000
F001 75
F001 120
F001 90
F001 60
0.001 F001 30
0.001 F001 50
0.001 F001 17
0.001 F001 9
0.001 F001 17
0.001 F001 400
1 F514 0 (Delayed)
1 F300 0
1 F102 0 (Disabled)
1 F085 0 (Mho Shape)
0.01 F001 6000
0.01 F001 7000
0.01 F001 6000
0.01 F001 7000
0.01 F001 10000
0.01 F001 10000
0.01 F001 10000
0.01 F001 10000
0.01 F001 10000
0.01 F001 10000
1 F102 0 (Disabled)
1 F167 0 (SRC 1)
0.001 F001 250
