CHAPTER 2: MODBUS COMMUNICATION
Address
Description
3741
Disturbance Record Available Files
3742
Disturbance Record Last Cleared Date
3744
Disturbance Record Number of Cycles per Record
3745
Disturbance Record Memory Available
3746
Disturbance Record Channel Active
3747
Disturbance Record Ready to Capture
User-Programmable Pushbuttons Common (Read/Write Command)
3918
User Pushbutton Input State
User-Programmable Pushbuttons (Read/Write Setting) (30 Modules)
3920
User Pushbutton 1 Function
3921
User Pushbutton 1 Set
3922
User Pushbutton 1 Reset
3923
User Pushbutton 1 Autoreset
3924
User Pushbutton 1 Autoreset Delay
3925
User Pushbutton 1 Local Lock
3926
User Pushbutton 1 Remote Lock
3927
User Pushbutton 1 Dropout Time
3928
User Pushbutton 1 Events
3929
User Pushbutton 1 Reserved (3 items)
392C
...Repeated for User Pushbutton 2
3938
...Repeated for User Pushbutton 3
3944
...Repeated for User Pushbutton 4
3950
...Repeated for User Pushbutton 5
395C
...Repeated for User Pushbutton 6
3968
...Repeated for User Pushbutton 7
3974
...Repeated for User Pushbutton 8
3980
...Repeated for User Pushbutton 9
398C
...Repeated for User Pushbutton 10
3998
...Repeated for User Pushbutton 11
39A4
...Repeated for User Pushbutton 12
39B0
...Repeated for User Pushbutton 13
39BC
...Repeated for User Pushbutton 14
39C8
...Repeated for User Pushbutton 15
39D4
...Repeated for User Pushbutton 16
39E0
...Repeated for User Pushbutton 17
39EC
...Repeated for User Pushbutton 18
39F8
...Repeated for User Pushbutton 19
3A04
...Repeated for User Pushbutton 20
3A10
...Repeated for User Pushbutton 21
3A1C
...Repeated for User Pushbutton 22
3A28
...Repeated for User Pushbutton 23
3A34
...Repeated for User Pushbutton 24
3A40
...Repeated for User Pushbutton 25
3A4C
...Repeated for User Pushbutton 26
3A58
...Repeated for User Pushbutton 27
3A64
...Repeated for User Pushbutton 28
3A70
...Repeated for User Pushbutton 29
PLUS
D90
LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
Range
Units
0 to 65535
---
0 to 400000000
---
0 to 65535
---
0 to 2
---
0 to 1
---
0 to 1
---
0 to 4294967295
---
0 to 2
---
0 to 65535
---
0 to 65535
---
0 to 1
---
0.2 to 600
s
0 to 65535
---
0 to 65535
---
0 to 60
s
0 to 1
---
0 to 65535
---
MODBUS MEMORY MAP
Step
Format
Default
1
F001
0
1
F050
0
1
F001
0
1
F075
0 (GREEN)
1
F108
0 (Off)
1
F108
0 (Off)
0.1
F003
0 (Disabled)
1
F109
0 (Disabled)
1
F300
0
1
F300
0
1
F102
0 (Disabled)
0.1
F001
10
1
F300
0
1
F300
0
0.1
F001
0
1
F102
1 (Enabled)
1
F001
0
73
