MODBUS MEMORY MAP
Address Description
1A15 Source 1 Phase AB or AC Voltage Magnitude
1A17 Source 1 Phase AB or AC Voltage Angle
1A18 Source 1 Phase BC or BA Voltage Magnitude
1A1A Source 1 Phase BC or BA Voltage Angle
1A1B Source 1 Phase CA or CB Voltage Magnitude
1A1D Source 1 Phase CA or CB Voltage Angle
1A1E Source 1 Auxiliary Voltage RMS
1A20 Source 1 Auxiliary Voltage Magnitude
1A22 Source 1 Auxiliary Voltage Angle
1A23 Source 1 Zero-Sequence Voltage Magnitude
1A25 Source 1 Zero-Sequence Voltage Angle
1A26 Source 1 Positive-Sequence Voltage Magnitude
1A28 Source 1 Positive-Sequence Voltage Angle
1A29 Source 1 Negative-Sequence Voltage Magnitude
1A2B Source 1 Negative-Sequence Voltage Angle
1A40 Source 2 Phase AG Voltage RMS
1A42 Source 2 Phase BG Voltage RMS
1A44 Source 2 Phase CG Voltage RMS
1A46 Source 2 Phase AG Voltage Magnitude
1A48 Source 2 Phase AG Voltage Angle
1A49 Source 2 Phase BG Voltage Magnitude
1A4B Source 2 Phase BG Voltage Angle
1A4C Source 2 Phase CG Voltage Magnitude
1A4E Source 2 Phase CG Voltage Angle
1A4F Source 2 Phase AB or AC Voltage RMS
1A51 Source 2 Phase BC or BA Voltage RMS
1A53 Source 2 Phase CA or CB Voltage RMS
1A55 Source 2 Phase AB or AC Voltage Magnitude
1A57 Source 2 Phase AB or AC Voltage Angle
1A58 Source 2 Phase BC or BA Voltage Magnitude
1A5A Source 2 Phase BC or BA Voltage Angle
1A5B Source 2 Phase CA or CB Voltage Magnitude
1A5D Source 2 Phase CA or CB Voltage Angle
1A5E Source 2 Auxiliary Voltage RMS
1A60 Source 2 Auxiliary Voltage Magnitude
1A62 Source 2 Auxiliary Voltage Angle
1A63 Source 2 Zero-Sequence Voltage Magnitude
1A65 Source 2 Zero-Sequence Voltage Angle
1A66 Source 2 Positive-Sequence Voltage Magnitude
1A68 Source 2 Positive-Sequence Voltage Angle
1A69 Source 2 Negative-Sequence Voltage Magnitude
1A6B Source 2 Negative-Sequence Voltage Angle
1A80 Source 3 Phase AG Voltage RMS
1A82 Source 3 Phase BG Voltage RMS
1A84 Source 3 Phase CG Voltage RMS
1A86 Source 3 Phase AG Voltage Magnitude
1A88 Source 3 Phase AG Voltage Angle
48
Range Units
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
