D-Link DWC-2000 User Manual page 194

Section 7 - Viewing Status and Statistics
Path
Status> Wireless Information> Access
Point > > All APs
Status > Wireless Information > Access
Point > Managed
Status > Wireless Information > Access
Point > Peer Managed
Status > Wireless Information > Access
Point > Authentication Failed
Status > Wireless Information > Access
Point > RF Scan
Status > Wireless Information > Access
Point > De-Authentication Attacks
Status > Wireless Information > Access
Point > Hardware Capability
Status > Wireless Information >
Associated Clients > Global Status
Status > Wireless Information >
Associated Clients > Associated Clients
Status > Wireless Information >
Associated Clients > Ad Hoc Clients
Status > Wireless Information >
Associated Clients > Detected Clients
Status > Wireless Information >
Clustering
Status > Wireless Information> WDS
Groups Status
Status> Wireless Information> WDS
Group Status > WDS Group AP Status
Status > Wireless Information> WDS
Group Status> WDS AP Status
Status > Wireless Information> WDS
Group Status> WDS Link Status
Status > Wireless Information> WDS
Group Status> WDS Link Statistics
D-Link DWC-2000 User Manual
Shows summary information about managed, failed, and rogue
access points the wireless controller has discovered or detected.
Shows details about the managed access points.
Shows information about the access points that each peer controller
in the cluster manages.
Shows information about access points that failed to establish
communication with the wireless controller.
Shows information about other access points and wireless clients
that the managed AP has detected.
Shows information about rogue APs that the Cluster Controller has
attacked by using the de-authentication attack feature.
Shows information about radio hardware and IEEE mode supported
by access points, along with software images available for
downloading to access points.
Shows statistics about all the clients' traffic while the clients are
associated with managed access points as well as throughout the
roaming session.
Shows information about all the clients connected through managed
access points.
Shows information about all ad-hoc clients.
Shows information about clients that have authenticated with
an access point, and clients that disassociate and are no longer
connected to the system.
Shows information about other wireless controllers in the network.
Shows the summary information about configured WDS links
Shows WDS group AP status configured APs and links in the WDS
Group.
Shows the status of configured APs and links in the WDS Group.
Shows WDS links in the WDS Group.
Shows the statistic WDS links in the WDS Group.
Description Page
213
214
216
217
218
219
221
223
224
228
229
231
232
233
235
236
237
194
