Section 5 - Advanced Network Configuration
Path: Network > QoS > QoS Priority > 802.1P Priority
If you selected CoS for your QoS configuration, use the following procedure to configure and assign priority to
the CoS fields in the IP packets.
1. Go to Network > QoS > QoS Priority. On the middle menu on the QoS Priority page, click the 802.1P
Priority tab. In the 802.1p Priority List, each row corresponds to a CoS field in an IP packet. Select a
CoS field by right-clicking on it and clicking Edit. This brings up a popup box called 802.1P Priority
Configuration.
2. On the Queue drop-down list, select one of the following priorities:
– Highest
– Medium
– Low
– Lowest
3. Repeat step 2 for each additional CoS field you want to prioritize.
4. When you finish, click Save.
