Kenmore 41784092500 Installation Instructions Manual

Preqnstallation Requirements ................................ 2
Electrical Requirements ........................................ 2
Exhaust System Requirements ............................ 3-4
Gas Supply Requirements ..................................... 4
Location of Your Dryer.......................................... 4-5
Roughqn Dimensions ............................................ 6
Mobile Home Installation ...................................... 7
Unpacking ........................................................... 7
Reversing Door Swing ........................................... 7-8
Electrical Installation ............................................. 9
Grounding Requirements ....................................... 9
Electrical Connections--3-wire ............................... 10
Electrical Connections--4-wire ............................... 10
Gas Connection ..................................................... 11
General Installation ................................................ 11
Replacement Parts ................................................. 11
Before beginning installation, carefully read these instructions. This wilt simptify the installation and ensure
the dryer is installed correcdy and safely. Leave these instructions near the Dryer after installation for future
reference.
NOTE: The electrical service to the Dryer must conform with local codes and ordinances and the latest edition of the
National Electrical Code, ANSI/NEPA 70.
NOTE: The gas service to the Dryer must conform with local codes and ordinances and the latest edition of the
National Fuel Gas Code ANS! Z223.1.
NOTE: The Dryer is designed under ANSI Z 21.5.1 or ANS!/UL 2158 - CAN/CSA C22.2 (latest editions) for HOME
USE only. This Dryer is not recommended for commercial applications such as restaurants or beauty salons, etc.
Save These Instructions
Sears, Roebuck and COo,Heffman Estates, IL 6t}129 U.S.Ao
P/N 134528000 (0501)
