Intelligent Orientation Control (IOC)

IOC allows users to lock the control orientation of the aircraft in different modes. There are three working
modes for IOC that can be selected in the DJI Pilot app. IOC only works when the aircraft is in F-mode,
therefore the user must toggle the flight mode switch to activate IOC. Refer to the table below:
Course Lock (CL)
Home Lock (HL)*
Point of Interest (POI)*
*Home Lock and Point of Interest feature are coming soon.
IOC Requirements
IOC is only available under the following conditions:
Modes IOC
GPS enabled
Course Lock
Home Lock
POI
Using IOC
Toggle the Flight Mode Switch F-mode and follow the instructions prompted on the DJI Pilot app to select
the desired IOC mode.
The nose direction, at the time that CL is set, will remain the forward direction
regardless of how the orientation and position of the aircraft changes. This will
remain fixed until you reset it or exit CL mode.
Record a Home Point (HP) and enter HL mode. The forward and backward
controls will move the aircraft farther from and closer to the established Home
Pont, regardless of how the orientation and position of the aircraft changes.
Point of Interest. Record a point of interest (POI). The aircraft can then circle
around the POI and the nose will always points toward the POI.
GPS counts
No None
Yes
Yes
Phantom 3 Advanced User Manual
Flight Distance Limits
None
Aircraft Home Point
≥10m
Aircraft Point of Interest
5m~500m
©
