M M 4 4 0 0 S S T T U U D D I I O O R R E E V V E E R R B B
8 8 A A l l g g o o r r i i t t h h m m S S e e l l e e c c t t b b u u t t t t o o n n s s
Press to select one of the following three algorithms:
Hall: The Hall reverb simulates a rather large hall while
preserving the natural characteristics of the source
material. This is excellent for many studio applications
requiring medium to long decay times and especially
on vocal material.
Room: The Room algorithm simulates a relatively small,
well furnished room. In such a room, many reflections
are absorbed by soft materials, and the sound is
reflected and sustained only by the walls, windows and
maybe some furniture. The Room reverb will work well
on almost all instruments.
Plate: Prior to the digital era, either reverberating
springs or large metallic plates were used to create
reverb. Plate reverbs typically have a very diffuse and
bright sound. The Plate reverb algorithm can be used
with great effect on many percussive instruments.
9 9 P P r r e e D D e e l l a a y y
The Pre Delay parameter defines a short delay placed
between the direct signal and the reverb diffuse field.
By using a pre-delay, the source material is kept clear
and undisturbed by the more diffuse reverb diffuse
field arriving shortly after.
1 1 0 0 D D e e c c a a y y T T i i m m e e
The decay parameter determines the length of the
reverb diffuse field. The length is defined as the time it
takes for the diffuse field to decay approximately by 60 dB.
1 1 1 1 H H i i C C o o l l o o r r
The Hi Color parameter changes the "color" of the
reverb. From dark to crisp and bright, the Hi Color
parameter can really change the characteristics and
style of the reverb.
18
1 1 2 2 M M i i x x
This is a dry/wet mix control for the reverb. You should
use the "mix" option when you are using the M40
Studio Reverb as an insert effect on a track in your
DAW.
1 1 3 3 1 1 0 0 0 0 % %
Deactivates the mix control and sets a 100% wet mix.
This is the setting to use when you are using the M40
reverb as a send effect, and also when using it as a cue
reverb for recording. When using the M40 Studio
Reverb in the TC Near Control Panel, always enable
100%. In 100% mode the MIX knob is grayed out.
N N o o t t e e s s o o n n t t h h e e M M 4 4 0 0 S S t t u u d d i i o o R R e e v v e e r r b b
• The M40 Studio Reverb is available only when the TC
Near Control Panel is open.
• The M40 Studio Reverb does not consume any CPU
power when the reverb is inactive. The Reverb is
inactive when the REVERB LED on the Desktop Konnekt
is "off".
• The display indicates "Power off" when the REVERB
button on the Desktop Konnekt 6 is turned fully counter
clockwise.
• The display indicates "Disabled" when the Reverb
Disabled function is activated on the Setup page.
• The M40 Studio Reverb is not available at quad speed
sample rates (176.4 kHz and 192 kHz.
