Sharp LC-60LE822E Service Manual

Sharp LC-60LE822E Service Manual

Lcd colour television
Hide thumbs Also See for LC-60LE822E:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.
SAFETY PRECAUTION
PRECAUTION........................................ . ............i
End of life disposal ................................. . .......... iii
MAJOR SERVICE PARTS ..................... . ..........iv
CHAPTER 1. SPECIFICATIONS
[1]
SPECIFICATIONS ................................. . ....... 1-1
[1]
Parts Name ............................................ . ....... 2-1
[1]
DIMENSIONS ........................................ . ....... 3-1
[1]
REMOVING OF MAJOR PARTS ........... . ....... 4-1
[2]
Caution Cleaning Glass ......................... . ....... 4-6
[3]
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.

SERVICE MANUAL

LCD COLOUR TELEVISION
LC-60LE822E
LC-60LE822ERU
MODELS
CONTENTS
[1]
[1]
CHAPTER 7. TROUBLESHOOTING TABLE
[1]
[2]
[1]
[1]
[2]
LC-60LE822E/LC-60LE822ERU
No. S90L460LE822E
FIGURE .........................................................5-1
ADJUSTMENT PROCEDURE ......................6-1
TROUBLESHOOTING TABLE ......................7-1
error .............................................................7-14
MAJOR IC INFORMATIONS .........................8-1
OVERALL WIRING DIAGRAM ......................9-1
SYSTEM BLOCK DIAGRAM .........................9-2
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.

Advertisement

Table of Contents
loading

Related Manuals for Sharp LC-60LE822E

Summary of Contents for Sharp LC-60LE822E

  • Page 1: Table Of Contents

    LC-60LE822E/LC-60LE822ERU SERVICE MANUAL No. S90L460LE822E LCD COLOUR TELEVISION LC-60LE822E LC-60LE822ERU MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig- inal condition and only parts identical to those specified should be used.

  • Page 2: Important Service Safety

    LC-60LE822E/LC-60LE822ERU LC-60LE822E SAFETY PRECAUTION Service Manual IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING • Use an AC voltmeter having with 5000 ohm per volt, or higher, sen- sitivity or measure the AC voltage drop across the resistor.

  • Page 3: Precautions For Using Lead-Free Solder

    LC-60LE822E/LC-60LE822ERU Precautions for using lead-free solder Employing lead-free solder • “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.

  • Page 4: End Of Life Disposal

    LC-60LE822E/LC-60LE822ERU End of life disposal End of life disposal...

  • Page 5: Outline

    LC-60LE822E/LC-60LE822ERU LC-60LE822E OUTLINE Service Manual MAJOR SERVICE PARTS PWB UNIT Ref No. Parts Code Description DKEYDF455FM07 MAIN Unit (*1) DUNTKF494FM02 R/C, LED Unit DUNTKF493FM03 ICON Unit DUNTKF493FM04 LOGO Unit RUNTKA761WJQZ TOUCH SENSOR Key Unit(*2) RUNTKA729WJQZ POWER/LED CONTROL Unit RUNTK4512TPZA LCD CONTROL Unit NOTE: (*1) Replace MAIN Unit (DKEYDF455FM07) in case of IC8401 or IC3302 failure.

  • Page 6: Specifications

    • As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

  • Page 7: Chapter 2. Operation Manual

    LC-60LE822E/LC-60LE822ERU CHAPTER 2. LC-60LE822E OPERATION MANUAL Service Manual [1] Parts Name TV (front view) (Volume buttons) (Programme [channel] buttons) INPUT (Input source button) MENU (Menu button) POWER (Power button) OPC sensor Remote control sensor Illumination LED TV (rear view) Antenna terminal...

  • Page 8: Remote Control Unit

    LC-60LE822E/LC-60LE822ERU Remote control unit (Standby/On) (Display information) Press to display the station information (channel number, signal, Press to access conventional etc.) in the upper right corner of the analogue TV mode. screen. P. INFO Press to access digital TV mode.

  • Page 9: Chapter 3. Dimensions

    LC-60LE822E/LC-60LE822ERU CHAPTER 3. LC-60LE822E DIMENSIONS Service Manual [1] DIMENSIONS 1439.0 Unit: mm 1334.2 580.0 400.0 40.0 174.0 368.0 NOTE • Dimensions do not include protrusions such as screws and some parts. 3 – 1...

  • Page 10: Chapter 4. Removing Of Major Parts

    LC-60LE822E/LC-60LE822ERU CHAPTER 4. LC-60LE822E REMOVING OF MAJOR PARTS Service Manual [1] REMOVING OF MAJOR PARTS 1. Removing of Stand Unit and Rear Cabinet Ass’y. 1. Remove the 3 lock screw and detach the Support Cover 2. Remove the 4 lock screws and detach the Stand Unit 3.
  • Page 11 LC-60LE822E/LC-60LE822ERU 2. Removing of Speaker-L/R. 1. Remove the 2 lock screws and detach the Stand Cover 2. Disconnect SP wire. 3. Detach the Speaker-L , Speaker-R 4. Detach the Insulation Sheet (AC) MAIN Unit [SP] Insulation Sheet (AC) [SP] Speaker-R...

  • Page 12: Main Unit

    LC-60LE822E/LC-60LE822ERU 3. Removing of Connectors 1. Disconnect the following connectors from the MAIN Unit. (SB, LB, PD, LW, RA, RL) 2. Disconnect the following connectors from the POWER/LED Drive Unit. (AS, L1, L2, LB, PD, PL) 3. Disconnect the following connectors from the LCD Control Unit. (LW, PL)
  • Page 13 LC-60LE822E/LC-60LE822ERU 4. Removing of MAIN Unit, POWER/LED Drive Unit, Woofer, Stand Angle,60” LCD Panel Module Unit. 1. Remove the 6 lock screws and detach the MAIN Unit 2. Remove the 2 lock screws and detach the Terminal Angle (Bottom) 3. Remove the 2 lock screws and detach the Terminal Angle (Side) 4.
  • Page 14 LC-60LE822E/LC-60LE822ERU 5. Removing of R/C, LED Unit, ICON Unit, LOGO Unit, Front Cabinet Ass’y, Glass Front Panel Ass’y, TOUCH SENSOR KEY Unit. 1. Detach the R/C, LED Unit 2. Detach the ICON Unit 3. Detach the LOGO Unit 4. Remove the 25 Hooks and detach the Front Cabinet Ass’y...

  • Page 15: Caution Cleaning Glass

    LC-60LE822E/LC-60LE822ERU [2] Caution Cleaning Glass (4)Have a designated place at the time of the handling. Back side : Black print part 1. Glass handling Front side : Protection tape part CAUTION: (1) As for handling, wear clean gloves, protective footwear- You must not have a clear surface.
  • Page 16 LC-60LE822E/LC-60LE822ERU 2. Glass cleaning CAUTION: (1) Visual inspection is done on the black mat. black mat glass (2) Dust and trash are taken with an air blow. Air blow (3) Dirt is wiped out with cloth. Ex.) Cotton (4) When dirt doesn't clean, it is wiped out with Alcohol.

  • Page 17: How To Replace The Touch Sensor Key Pwb

    LC-60LE822E/LC-60LE822ERU [3] How to replace the Touch Sensor key PWB 1. Replace the touch sensor key PWB in a clean room. Be sure to remove the dust from the unit before carrying it into the clean room. 2. Remove the touch sensor key PWB from the front glass.
  • Page 18 LC-60LE822E/LC-60LE822ERU ii) Adhere the ITO section to the front glass. (Use the positioning jig.) Tape fixing the FPCB and ITO sections (Adhered by the supplier) iii-1. Peel the release paper of the double-sided tape on the ITO section. iii-2. Slowly adhere it from the end using a roller.
  • Page 19 LC-60LE822E/LC-60LE822ERU iv) Peel the protective sheet of the OCA. Lift the ITO section, then peel the protective sheet by about half by means of the pull tap. * Peeling it completely reduces workability. Check the order due to workability. v) Contact the FPCB and joint end of the transparent electrode film with the glass.
  • Page 20 LC-60LE822E/LC-60LE822ERU — MEMO — 4 – 11...

  • Page 21: Chapter 5. Touch Sensor Unit Positioning Figure

    LC-60LE822E/LC-60LE822ERU LC-60LE822E CHAPTER 5. TOUCH SENSOR UNIT POSITIONING FIGURE Service Manual [1] TOUCH SENSOR UNIT POSITIONING FIGURE TOUCH SENSOR KEY Unit 5 – 1...
  • Page 22 LC-60LE822E/LC-60LE822ERU — MEMO — 5 – 2...

  • Page 23: Chapter 6. Adjustment

    LC-60LE822E/LC-60LE822ERU CHAPTER 6. LC-60LE822E ADJUSTMENT Service Manual [1] ADJUSTMENT PROCEDURE 1. Adjustment method after PWB and/or IC replacement due to repair The unit is set to the optimum at the time of shipment from the factory. If any value should become improper or any adjustment is necessary due to the part replacement, make an adjustment according to the following pro- cedure.
  • Page 24 LC-60LE822E/LC-60LE822ERU 2. Notes of Touch sensor unit Touch sensor unit (RUNTKA761WJQZ) is fixed directly in the module glass. The unit cannot never be recycled when exfoliated from the module glass. Therefore, please exchange the touch sensor units when the module glass is changed.
  • Page 25 LC-60LE822E/LC-60LE822ERU 6. Description of display (1) Present page / number of total pages (4) Inducing display (3) Present colour system (2) Input that has been selected now (5) Inch setting and Model name display 1/21 INPUT1 AUTO EURO xxxxx MAIN Version 1.00 (E 2009/**/** )
  • Page 26 LC-60LE822E/LC-60LE822ERU 7. Adjustment process mode menu The character string in brackets [ ] will appear as a page title in the adjustment process menu header. Page Line Item Description Remarks (adjustment detail, etc.) 1/21 MAIN Version 1xxx (xxxxx) Main software version...
  • Page 27 LC-60LE822E/LC-60LE822ERU Page Line Item Description Remarks (adjustment detail, etc.) 5/21 HDMI CEC TEST Enter HDMI CEC test INSPECT USB TERM Enter Reading inspection of USB memory terminal HDMI EDID WRITE Enter HDMI EDID WRITING MONIDATA READ [TEMP/OPC] MONITOR Temperature/OPC Acquisition tool.
  • Page 28 LC-60LE822E/LC-60LE822ERU Page Line Item Description Remarks (adjustment detail, etc.) 14/21 FRC-N Firmware Version xxxxx FRC-N Boot Script Version xxxxx FRC-N Device Version xxxxx TCON FPGA1 Serial Flash Version xxxxx TCON FPGA2 Serial Flash Version xxxxx TCON FPGA1 Config Rom Version...

  • Page 29: Special Features

    LC-60LE822E/LC-60LE822ERU Page Line Item Description Remarks (adjustment detail, etc.) 21/21 EEP SAVE Writing setting values to EEPROM. EEP RECOVER Reading setting values from EEPROM. MONITOR ERROR CAUSE RESET Reset of monitor error cause MODEL NAME LE705 MODEL NAME PANEL SIZE Panel size setting.

  • Page 30: Lamp Error Detection

    LC-60LE822E/LC-60LE822ERU 9. Lamp Error detection 1. Function This LCD colour TV set incorporates a Lamp error detection feature that automatically turns off the power for safety under abnormal lamp or lamp circuit conditions. If by any chance anything is wrong with the lamp or lamp circuit or if the lamp error detection feature is activated for some rea- son, the following will result.

  • Page 31: Public Mode

    LC-60LE822E/LC-60LE822ERU 10. Public Mode 1. Starting the Public Mode • There are two following ways to display the PUBLIC Mode setting screen. 1) Method of needing password a) Turn off the power, refer to “3. Method of shuts down for Power supply”...
  • Page 32 LC-60LE822E/LC-60LE822ERU 4. Basic operation in the Public Mode Change or execution of the set value. Vol (+/-) or Cursor ( / ) Movement to the selected item. CH ( ) or Cursor ( / ) Decision (ok) Execution (Used by the items “Execution” and “RESET”.) Public Mode setting screen.
  • Page 33 LC-60LE822E/LC-60LE822ERU 2) Instantaneous current shutdown setting in turning off the power [SHUT DOWN MODE] Option “NORMAL” or “QUICK” Default NORMAL Function • This function decides whether scanning digital tuner is enabled or disabled when the power is standby. NORMAL : Scanning digital tuner is enabled when the power is standby.
  • Page 34 LC-60LE822E/LC-60LE822ERU 7) Main Unit Operation [PANEL BUTTON] Option “RESPOND” or “NORESPOND” (loop enabled) Default “RESPOND” Function • RESPOND : The main unit’s keys are enabled. • NO RESPOND : The main unit’s keys are disabled excluding the POWER key (RECEPTION/STANDBY key).
  • Page 35 LC-60LE822E/LC-60LE822ERU 10)OSD display [ON SCREEN DISPLAY] Option “YES”, “NO” or “LIMITED” (loop enabled) “LIMITED” is looped only in case of need (destination). Default “YES” Function • : OSD is displayed • : the following OSD is not displayed. Registration, setting, adjustment menu, channel call, volume bar, and input select •...
  • Page 36 LC-60LE822E/LC-60LE822ERU 13)Speaker ON/OFF selection [LOUD SPEAKER] Option “ON” or “OFF” (loop enabled) Default Function : The sound from the speakers is output. : The sound from the speakers is not output even if the headphones are not used. Remarks •...
  • Page 37 LC-60LE822E/LC-60LE822ERU 11.2. PAL signal adjustment Adjustment point Adjustment conditions Adjustment procedure Setting [Signal] • Feed the PAL full field colour bar signal (75% colour saturation) to EXT1 SCART IN. Full field colour bar composite [VIDEO input signal] signal [Terminal] 100% white...
  • Page 38 LC-60LE822E/LC-60LE822ERU 11.5. ADC adjustment (Component 15K) Adjustment point Adjustment conditions Adjustment procedure Setting [Signal] • Feed the COMPONENT 15K 100% full field colour bar signal (100% COMP15K, 50Hz colour saturation) to EXT3 COMPONENT IN. 100% Full field colour bar Signal...

  • Page 39: White Balance Adjustment

    LC-60LE822E/LC-60LE822ERU 12. White Balance Adjustment For white balance adjustment, adjust the offset values on pages 11/21. [Condition of the unit for inspection] : Modulated light (+16), Colour temperature (High) AV MODE: DYNAMIC Active Backlight: OFF OPC: OFF Asing Time: Min,60 minute...

  • Page 40: Upgrading The Software

    LC-60LE822E/LC-60LE822ERU 14. Initialization to factory settings CAUTION: When the factory settings have been made, all user setting data, including the channel settings, are initialized. (The adjustments done in the adjustment process mode are not initialized.) Keep this in mind when initializing these settings.
  • Page 41 LC-60LE822E/LC-60LE822ERU 6. The caution for update showes up. • The picture will temporary go dark until the software update display apeeares • Wait several minutes and don't unplug the AC cord Select OK when if there is no problem. 7. Software update starts.

  • Page 42: Troubleshooting Table

    LC-60LE822E/LC-60LE822ERU CHAPTER 7. LC-60LE822E TROUBLESHOOTING TABLE Service Manual [1] TROUBLESHOOTING TABLE No power (Central Icon LED failure to light up) or No startup (Central Icon LED is flashing) Is the AC cord connector tightly connected to the set? Reconnect the AC cord tightly and turn on the power again.
  • Page 43 LC-60LE822E/LC-60LE822ERU The sound is not emitted from the Speaker & Woofer though the picture has come out. No sound output in all modes? Is the signal output from pins (F30/AOLRCK), (F28/AOBCK) Check IC3302 and its peripheral circuits. (G28/AOSDATA0) of IC3302 (Digital AV decode & Main CPU)? Is the signal sent to pins (7), (8), (9) of IC2701 (DSP)? Check the line between IC3302 and IC2701.
  • Page 44 LC-60LE822E/LC-60LE822ERU No sound (during the reception of TV (ANALOG) broadcasting) Does not the sound go out though the picture has come out when UHF/VHF is received? Is a SIF signal output from pin (13) of TUNER (TU1101)? Check the tuner and its peripheral circuits.
  • Page 45 LC-60LE822E/LC-60LE822ERU Is signal output to pins (122/TS_VALIDO, 123/TS_CLKO, 124/ Check IC4405 and its peripheral circuits. TS_DATAO, 124/TS_SYNCO) of IC4405? Is signal sent to pins (A30/TS_CPUIN_VAL, B30/ Check the line between IC4405 and IC3302. TS_CPUIN_CLK, C30/TS_CPUIN_SYNC, C29/TS_CPUIN_D0) of IC3302 (Digital AV decode & Main CPU)? Refer to “No sound output in all modes.”...
  • Page 46 LC-60LE822E/LC-60LE822ERU No sound from external input devices (1) Does not the sound of the audio signal input to EXT1 go out? Is there a audio input signal to pins (19/AUDIO_IN_L) and (21/ Check the setting of an external input device that connects with AUDIO_IN_R) of EXT1 (SC505)? EXT1.
  • Page 47 LC-60LE822E/LC-60LE822ERU No sound from external input devices (4) Does not the sound of the audio signal input to HDMI1/2/3/4 go out? Please Refer to “[External input HDMI-1/2/3/4] No picture on the display (10)”. No sound from external output device (1) No audio signal output to EXT1 terminal.
  • Page 48 LC-60LE822E/LC-60LE822ERU No sound from external output device (3) No sound from DIGITAL AUDIO OUTPUT terminal. Is the audio signal output to pins (1) of sound output terminal Check D520 and peripheral circuits. (D520)? Is SPDIF_MUTE signal SPDIF_MUTE [H29/IC3302] or Check the peripheral circuits of IC3302 and SPDIF_MUTE.
  • Page 49 LC-60LE822E/LC-60LE822ERU No picture on the display (1) The picture doesn't appear in all modes. Is the LVDS signal output from IC3302 (DIGITAL_AV_DECODER_&_MAIN_CPU_&_VIDEO PROCESSER) respectively? LVDS0_D0N/P (D14/C14), LVDS0_D1N/P (D15/C15), LVDS0_D2N/P (D16/C16), LVDS0_CLKN/P_83MHz (D17/C17), LVDS0_D3N/P (D18/C18), LVDS0_D4N/P (D19/C19), LVDS1_D0N/P (B14/A14), LVDS1_D1N/P (B15/A15), LVDS1_D2N/P (B16/A16), LVDS1_CLKN/P_83MHz (B17/A17), LVDS1_D3N/P (B18/A18), LVDS1_D4N/P (B19/A19) Check IC3302 and its peripheral control circuits.
  • Page 50 LC-60LE822E/LC-60LE822ERU [External input EXT1] No picture on the display (5) Does not the picture of the CVBS signal input to EXT1 go out? Is CVBS signal sent to pin (14) of EXT1 (SC505)? Check the setting of an external input device that connects with EXT1.
  • Page 51 LC-60LE822E/LC-60LE822ERU [External input EXT2] No picture on the display (8) Does not the picture of the CVBS signal input to EXT2 go out? Is a CVBS signal input to pin (3) of EXT8 (J505)? Check the setting of an external input device that connects with EXT2.
  • Page 52 LC-60LE822E/LC-60LE822ERU [External input HDMI-1/2/3/4] No picture on the display (11) Does not the picture/sound of the HDMI signal input to HDMI-1/2/3/4 go out? Is the Hot plug detection function output from pin (19) of the Check the line between SC1503 and pin (45) of IC1504 (HDMI- HDMI-1 (SC1503) normal? SW).
  • Page 53 LC-60LE822E/LC-60LE822ERU <During external connection> No picture on the monitor No picture appears on EXT1connected monitor during the ATV/DTV reception. Is CVBS signal output into pin (2) of EXT1 (SC505)? Check the setting of an external input device that connects with EXT1.
  • Page 54 LC-60LE822E/LC-60LE822ERU No light (Back Light doesn't light) Is the AC cord connector tightly connected to the set? Reconnect the AC cord tightly and turn on the power again. Are the wire harnesses and other cables properly connected in Reconnect the wire harnesses and other cables properly in the the set? set.

  • Page 55: Led Flashing Specification At The Time Of The Error

    LC-60LE822E/LC-60LE822ERU [2] LED flashing specification at the time of the error Display method • Refer to Table 1. • LED that can be used is only one of the central icons. This expresses the error situation by combining blinking at low speed and blinking at high speed.
  • Page 56 LC-60LE822E/LC-60LE822ERU Table 1. Concrete flashing pattern Expression for a rough content Expression for Details Item low-speed high-speed low-speed high-speed Cause blinking blinking blinking blinking Lamp system failure Flashes once — Flashes once Flashes once Lamp error Power PWB failure Flashes twice —...
  • Page 57 LC-60LE822E/LC-60LE822ERU LED flashing timing chart at the time of the error 100ms 400ms 1.6sec 1) Low-speed blinking Error type Expression of Central Icon LED Note: Pins are monitor microprocessor pins (IC2002). Lamp failure H: ON Refer to “Lamp failure details”.
  • Page 58 LC-60LE822E/LC-60LE822ERU 4) Communication failure details (Low-speed blinking: Flashes 3 times + High-speed blinking) Error type Expression of Central Icon LED Note: Basically, debug print logs are analyzed or communication logs are analyzed by a bus monitor. Initial communication H: ON Initial communication from the main CPU is not received.

  • Page 59: Chapter 8. Major Ic Informations

    LC-60LE822E/LC-60LE822ERU CHAPTER 8. LC-60LE822E MAJOR IC INFORMATIONS Service Manual [1] MAJOR IC INFORMATIONS REF NO Name Part Code Description [MAIN UNIT] IC8401 RH-iXC147WJQZQ Flash This IC is 512MB NAND flash memory. This IC stores the software data that processes the system of TV such as the graphic processing, the LCD controls, and backlights etc.
  • Page 60 LC-60LE822E/LC-60LE822ERU — MEMO — 8 – 2...

  • Page 61: Chapter 9. Overall Wiring/Block Diagram Overall Wiring Diagram

    LC-60LE822E/LC-60LE822ERU LC-60LE822E CHAPTER 9. OVERALL WIRING/BLOCK DIAGRAM Service Manual [1] OVERALL WIRING DIAGRAM OVERALL WIRING DIAGRAM Woofer QCNW-K570WJQZ POWER Unit P2702 P9602 J3301 QCNW-K980WJQZ J9501 P9601 QCNW-K979WJQZ J504 MAIN Unit Audio out J505 AV-IN P2701 20 19 QCNW-K568WJQZ SC501 PC/COMP...

  • Page 62: System Block Diagram

    LC-60LE822E/LC-60LE822ERU [2] SYSTEM BLOCK DIAGRAM SYSTEM BLOCK DIAGRAM CVBS MAIN CVBS/LR EXT2 CVBS_L/R CVBS [LW] CVBS/LR P2601 (41p) S-Video EXT1 (SCART1) TUNER CVBS OUT IC504 TUNER_OUT TUNER OUT LR_OUT TUNER OUT L/R MM1506XN Mute From CPU or FS/FB FAST_SW UCON...

  • Page 63: Parts Guide

    LC-60LE822E/LC-60LE822ERU PartsGuide PARTS GUIDE No. S90L460LE822E LCD COLOUR TELEVISION LC-60LE822E LC-60LE822ERU MODELS CONTENTS PRINTED WIRING BOARD SUPPLIED ACCESSORIES ASSEMBLIES PACKING PARTS LCD PANEL MODULE (NOT REPLACEMENT ITEM) CABINET PARTS SERVICE JIGS (USE FOR SERVICING) Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.
  • Page 64 LC-60LE822E/LC-60LE822ERU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES MAIN Unit DKEYDF455FM07 R/C, LED Unit DUNTKF494FM02 ICON Unit DUNTKF493FM03 LOGO Unit DUNTKF493FM04 TOUCH SENSOR Key Unit RUNTKA761WJQZ RUNTKA729WJQZ POWER/LED CONTROL Unit LCD CONTROL Unit RUNTK4512TPZA [2] LCD PANEL MODULE 60"...
  • Page 65 LC-60LE822E/LC-60LE822ERU [3] CABINET PARTS POWER/LED Drive Unit R/C, ICON LOGO Unit Unit Unit MAIN d TOUCH Unit SENSOR Unit 60" LED PANEL Module...
  • Page 66 LC-60LE822E/LC-60LE822ERU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] CABINET PARTS Front Cabinet Ass'y CCABAC609WJ35 Front Cabinet Not Available R/C Decoration Cover HDECQB420WJ3A Front Decoration Plate HDECZA031WJSA Coner Tape, x4 PSHEZA252WJZZ Up Side Tape PSHEZA256WJZZ Side Tape, x2 PSHEZA261WJZZ...
  • Page 67 LC-60LE822E/LC-60LE822ERU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] CABINET PARTS Screw, x3 XBPS840P12000 Screw, x4 XBPS950P12KS0 Screw, x7 XEBS940P10000 Material Label TLABN0134BMZZ [4] SUPPLIED ACCESSORIES Remote control unit ( x 1) “AAA” size alkaline battery ( x 2)
  • Page 68 LC-60LE822E/LC-60LE822ERU [5] PACKING PARTS (NOT REPLACEMENT ITEM)
  • Page 69 LC-60LE822E/LC-60LE822ERU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] PACKING PARTS (NOT REPLACEMENT ITEM) Packing Case (Top) SPAKCF901WJZZ Packing Case (Bottom) SPAKCF498WJZZ Rear Pad SPAKAA639WJZZ Wrapping Paper SPAKPB550WJZZ Wrapping Paper (Stand) SPAKPB551WJZZ Packing Add. (Top) SPAKXC923WJZZ Packing Add. (Bottom)
  • Page 70 LC-60LE822E/LC-60LE822ERU COPYRIGHT © 2010 BY SHARP CORPORATION ALL RIGHTS RESERVED. No Part of this publication may be reproduced, stored in a retrieval system, or transmitted in any from or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
