OIL CHANGE REMINDER SYSTEM

This system informs the operator of the time for replacing
ENGINE OIL on the basis of the recommended maintenance
schedule. When the total motor operating hours have reached
the preprogrammed hours, the "OIL" lamp will flash, and the
buzzer will begin a series of double beeps if engine is not run-
ning (but ignition switch is ON). The above mentioned indication
will repeat until the activated system is manually cancelled.
NOTE:
This system will activate up to 2 100 hour's operation.
INDICATION OF SYSTEM ACTIVATION
Buzzer
OFF
Ign. switch
ON
Buzzer
OFF
ON
Oil Lamp
OFF
CANCELLATION
Procedure
1. Turn the ignition key to "ON" position.
2. Pull out the emergency stop switch plate 1.
3. Pull up the emergency stop switch knob 2 three times in ten
seconds. A short beep will be heard if cancellation is suc-
cessfully finished.
4. Turn the ignition key to "OFF" position.
5. Set the switch plate 1 in original position.
NOTE:
• Canceling of the system activation is possible regardless of whether or not the engine oil has been
replaced. Once the system has operated, however, SUZUKI strongly recommends that the engine oil be
replaced before canceling the system activation.
• Even if the engine oil has been replaced with the system not operating, it is still necessary to perform the
cancellation.
OIL lamp
ON
: Indicator check (No relation to OIL CHANGE REMINDER SYSTEM)
ENGINE CONTROL SYSTEM
Action
Starting operation
(*1) (*4)
Indication Cancellation
(*2) (*4)
Indication Cancellation
(*3) (*4)
Indication Cancellation
(*3) (*4)
Indication Cancellation
Repeat
*1 : Lapse of initial 20 hour's operation
*2 : Lapse of 80 hour's operation
*3 : Lapse of 100 hour's operation
*4 : When performing cancellation before
system activation
