Page 1
Leggere attentamente questo manuale d’istruzioni prima di utilizzare il monitorLCD. Vi ringraziamo per aver scelto un monitor LCD Sanyo che vi consentirà di trascorrere momenti piacevoli e divertenti. Lea este manual de instrucciones antes de usar su nuevo monitor. Deseamos que disfrute de él muchas horas.
Page 2
LCD monitor. Use a damp cloth for cleaning. Important recycling information. This LCD monitor should have a minimum distance of 5cm away Your SANYO product is designed and from the wall and the monitor should have 10cm distance around manufactured with high quality materials and the top and sides components which can be recycled and reused.
This End-User License will be governed by laws of England and rights in the Software to you. The Software provided hereunder the User may only bring claims in the English Courts and SANYO may contain or be derived from portions of materials provided to shall be entitled to bring a claim in the courts of any jurisdiction.
INST ALLA TION INST ALLA TION Step : 1 Mains Connection AV2 / DVI AV2 / DVI PC-IN PC-IN ■ AUDIO IN AUDIO IN DVI-D DVI-D Connect the display unit to VGA, BNC and Scart connector as required. MONITOR OUT IN IN IN IN AV2 / DVI...
REMOTE CONTROL REMOTE CONTROL TV/AV button To switch from AV1, RGB, AV2, AV3, PC or DVI mode press repeatedly. Press and hold in a few seconds, an AV selection Standby bar appears. Select the mode you require using the keys To switch the monitor on and off.
INST ALLA TION INST ALLA TION Controls and Menus Menu Operation Brightness Contrast Color Sharpness Preset Personal / Dynamic / Standard / Eco Noise Reduction Min/ Mid / Max / Auto / OFF Dyn. Skin Tone ON / OFF Text Brightness Min/ Mid / Max Sound Volume...
MENU OPERA TION MENU OPERA TION PC menu settings Sound menu Connect your PC to either PC-IN or RGBHV on the rear of the set. Press the MENU button and select Sound using the e or d Once connected select PC mode or AV2 (RGBHV, see page 4 for buttons, press the 8 button to enter.
PC OPERA TION / INST ALLA TION MENU PC OPERA TION / INST ALLA TION MENU RS232C settings Installation Menu This monitor can be controlled via the RS232C connector using a This LCD monitor allows you to set up the following:- suitable computer/ control commands ■...
OPERA TION OPERA TION Selecting of picture size ■ Full ■ Screen options Today there are various transmission formats with different size 16:9 Letterbox Video ratios, eg. 4:3 , 16:9 and video formats such as letterbox. ✐ When in High Resolution (720p / 1080i) YPbPr or DVI, the picture will remain fixed in 16:9 format ‘Full size’...
SPECIFICA TIONS / HELPFUL HINTS SPECIFICA TIONS / HELPFUL HINTS Specification Common specification Power source 220~240V 50Hz Colour system PAL (NTSC3.58),SECAM AV terminal AV1: Scart CENELEC Standard Input: Composite video, RGB (5V RGB with 5V sync to pin 14) and audio-L/R Output: TV-output with composite video and audio-L/R AV2: BNC Input: RGB, H and V / Y, Pb, Pr and audio L/R...
PC/DVI-D / COMPONENT SIGNAL SUPPORT TIMING LIST PC signal support timing Horizontal Vertica l Freq uency Freq uency Res olution Rema rk (kHz) (Hz) 720_ 400 31.47 70.09 DOS(VGA ) 640_ 480 31.50 60.00 DOS(VGA VESA 60Hz) 640_ 480 37.50 75.00 VGA VESA 75Hz 640_ 480...
