DIGITAL RECORDER
RS-232C COMMUNICATION CAPACITY
OPERATION MANUAL
MODEL
DX-TL5000E
DX-TL5000U
Contents
Connecting to a personal computer ........................................................... 2
Connection via a modem ....................................................................................... 2
Direct connection ................................................................................................... 2
RS-232C connector ............................................................................................... 2
RS-232C cable ...................................................................................................... 2
About command code table ........................................................................ 3
RS-232C settings .................................................................................................. 3
Command code system ......................................................................................... 3
Description of command code systems ................................................................. 3
Direct operation specification ........................................................................... 3
Quasi-front panel operation command type ..................................................... 4
Status condition change information function .................................................. 4
Command receipt confirmation function .......................................................... 4
Command code table ................................................................................... 5
<Search> ....................................................................................................... 12
<Copy> .......................................................................................................... 15
<PTZ Control> ............................................................................................... 16
<Record> ....................................................................................................... 17
<Timer>.......................................................................................................... 26
<Motion Det> ................................................................................................. 29
<System> ....................................................................................................... 30
<Menu data> .................................................................................................. 37
<Option> ........................................................................................................ 37
<COM/LAN> .................................................................................................. 38
<PTZ Setting> ................................................................................................ 39
<Restore> ...................................................................................................... 40
<Memory> ...................................................................................................... 41
<Other Settings> ............................................................................................ 42
RS-232C [Quasi-front panel operation] command form ...................................... 45
RS-232C Status condition change notification .................................................... 47
series
series

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric DX-TL5000E series

Summary of Contents for Mitsubishi Electric DX-TL5000E series

  • Page 1: Table Of Contents

    DIGITAL RECORDER RS-232C COMMUNICATION CAPACITY OPERATION MANUAL MODEL DX-TL5000E series DX-TL5000U series Contents Connecting to a personal computer ............2 Connection via a modem ..................2 Direct connection ....................2 RS-232C connector ....................2 RS-232C cable ...................... 2 About command code table ................ 3 RS-232C settings ....................

  • Page 2: Connecting To A Personal Computer

    Connecting to a personal computer This unit can be remotely controlled from a PC connected via a RS-232C connector. Connection via a modem Please use RS-232C straight cable (9 pin) to connect a modem with this unit. The setting of CTS should be set to “HIGH” or “ON”.

  • Page 3: About Command Code Table

    About command code table RS-232C settings Settings related to communication of this unit are made in the <System Menu> <COM/LAN> <RS-232C Setting>. Make the same settings as the connected modem or PC connected. When remotely controlling this unit from a PC, set “Communication Mode” in the <RS-232C Setting> to “Remote A,”...

  • Page 4: Quasi-Front Panel Operation Command Type

    About command code table (continued) Quasi-front panel operation command type This system specifies operations from a PC as if operating the actual operation panel of the unit while viewing the output picture. Each command is corresponded to the operation button of the unit. •...

  • Page 5: Command Code Table

    Command code table Detail of the numbers: : When “Delimiter” in the <RS-232C Setting> is set to “CR,” carriage return code (0DH) is input. When “Delimiter” is set to “CR•LF,” carriage return code (0DH) and line feed code (0AH) are input. : When “Delimiter”...
  • Page 6 Command code table (continued) RS-232C [Direct operation specification] operation setting command form (2/7) Status Note Command name Command RC ≥ :Output port Display SW,** **** ≤ EX,** SW,** **** 00:Output A 01:Output B ≥ **** :Switcher command 0100:Single screen sequential 0101:CH1 0102:CH2 0103:CH3...
  • Page 7 Command code table (continued) RS-232C [Direct operation specification] operation setting command form (3/7) Command name Command Status Note CP1,** ≤ RC ≥ :Copy destination device Start copy 00:Copy 1 01:Copy 2 EX,** CP1,** ≥ :Copy destination group 00:SerialBus 01:NAS 02:SCSI 03:DVD/CD 04:USB Memory (for copy 1 only) 05:Internal (for copy 2 only)
  • Page 8 Command code table (continued) RS-232C [Direct operation specification] operation setting command form (4/7) Status Note Command name Command Clear warning display ≤ RC ≥ :Clearing warning display command EX,** ≥ 0:Clear :Error type (Refer to page 4.) :System mode number (Refer to Power command) Load/save menu data RC ≥...
  • Page 9 Command code table (continued) RS-232C [Direct operation specification] operation setting command form (5/7) Status Note Command name Command Execute data lock RC ≥ DLOKS,** :Device area including the data to be locked EX,** DLOKS,** ≤ 01:Normal 02:Alarm ≥ :Bookmark number of start point 00:1 01:2 02:3...
  • Page 10 Command code table (continued) RS-232C [Direct operation specification] operation setting command form (6/7) Status Note Command name Command Select Source PDV,** ≤ RC ≥ :Output port of playback picture Device EX,** PDV,** ≥ 00:Output A :Playback device 01:Main 02:Copy 1 03:Copy 2 :Playback device group <For Main>...
  • Page 11 Command code table (continued) RS-232C [Direct operation specification] operation setting command form (7/7) Command name Command Status Note PB21,** ≤ Search by Book Mark RC ≥ :Output port of playback picture EX,** PB21,** 00:Output A ≥ :Bookmark number to be searched 00:1 01:2 02:3...

  • Page 12: Rs-232C [Direct Operation Specification] Menu Setting Command Form

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Search> (1/3) Refer to [Direct operation specification] operation setting command for carring out search function. Status Note Menu Menu item Command <Writing of menu information> Select Source Playback Device <Menu setting>...
  • Page 13 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Search> (2/3) Refer to [Direct operation specification] operation setting command form for carring out search function. Menu Menu item Command Status Note <Menu setting> <Writing of menu information> ***** :08048 Find data...
  • Page 14 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Search> (3/3) Refer to [Direct operation specification] operation setting command form for carring out search function. Menu Menu item Command Status Note Search by Motion year <Menu setting> <Writing of menu information>...

  • Page 15: Copy

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Copy> (1/2) Menu Menu item Command Status Note <Menu setting> <Writing of menu information> ***** :12000 Copy data to Range of Copy DW,***** RC ≥ ***** :00000-00002 Copy 1 Drive ***** ≤...

  • Page 16: Ptz Control

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Copy> (2/2)/<PTZ Control> Menu Menu item Command Status Note ***** :12023 Set Copy 1 Drive Copy Data <Menu setting> <Writing of menu information> ***** (continued) DW,***** RC ≥ 00000:All 00001:Alarm *****...

  • Page 17: Record

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Record> (1/9) Menu Menu item Command Status Note <Menu setting> <Writing of menu information> Normal Recording Frame / Field ***** :02339-02354 RC ≥ Menu DW,***** 02339:CH1 02340:CH2 02341:CH3 EX,** DW,***** *****...
  • Page 18 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Record> (2/9) Menu Menu item Command Status Note Motion Detection <Menu setting> <Writing of menu information> ***** :02396 Alarm Recording Recording DW,***** RC ≥ ***** Menu ***** ≤ EX,** DW,***** *****...
  • Page 19 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Record> (3/9) Menu Menu item Command Status Note <Menu setting> <Writing of menu information> ***** :02739-02754 Normal Recording Frame / Field DW,***** RC ≥ 02739:CH1 02740:CH2 02741:CH3 Menu EX,** DW,***** *****...
  • Page 20 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Record> (4/9) Menu Menu item Command Status Note Motion Detection <Menu setting> <Writing of menu information> ***** :02796 Alarm Recording Recording DW,***** RC ≥ ***** Menu ***** ≤ EX,** DW,***** *****...
  • Page 21 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Record> (5/9) Menu Menu item Command Status Note <Menu setting> <Writing of menu information> Normal Recording Frame / Field ***** :03139-03154 RC ≥ Menu DW,***** 03139:CH1 03140:CH2 03141:CH3 EX,** DW,***** *****...
  • Page 22 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Record> (6/9) Menu Menu item Command Status Note <Menu setting> <Writing of menu information> Alarm Recording Motion Detection ***** :03196 Recording DW,***** RC ≥ ***** Menu ***** ≤ EX,** DW,***** *****...
  • Page 23 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Record> (7/9) Menu Menu item Command Status Note <Writing of menu information> Normal Recording Frame / Field <Menu setting> ***** :03539-03554 DW,***** RC ≥ Menu 03539:CH1 03540:CH2 03541:CH3 ***** ≤...
  • Page 24 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Record> (8/9) Menu Menu item Command Status Note <Menu setting> <Writing of menu information> Alarm Recording Motion Detection ***** :03596 Recording DW,***** RC ≥ ***** Menu ***** ≤ EX,** DW,***** *****...
  • Page 25 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Record> (9/9) Status Note Menu Menu item Command <Menu setting> <Writing of menu information> ***** :03618 Emergency Frame / Field DW,***** RC ≥ ***** Recording Setup EX,** DW,***** ***** ≥...

  • Page 26: Timer

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Timer> (1/3) Menu Menu item Command Status Note ***** :12200 Program Selection Select program <Menu setting> <Writing of menu information> ***** and Program number to be used DW,***** RC ≥...
  • Page 27 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Timer> (2/3) Menu Menu item Command Status Note Configure Day of The Week <Writing of menu information> ***** <Menu setting> 12325:Line 1 12340:Line 2 12355:Line 3 Timer Program 2 DW,***** RC ≥...
  • Page 28 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Timer> (3/3) Menu Menu item Command Status Note ***** :12500-12539 Define Holidays <Menu setting> <Writing of menu information> 12500:Month 12501:Day (1-1) (holizontal line-vertical line) DW,***** RC ≥ 12502:Month 12503:Day (1-2) *****...

  • Page 29: Motion Det

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Motion Det> Menu Menu item Command Status Note <Menu setting> <Writing of menu information> Set Motion Detection Sensitivity ***** DW,***** RC ≥ Pattern A 04000:1CH 04100:2CH 04200:3CH ***** ≤...

  • Page 30: System

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <System> (1/7) Menu Menu item Command Status Note ***** :00010 Time/Date Setting year <Menu setting> <Writing of menu information> ***** :00001-00037 (year 2001-2037) DW,***** RC ≥ :Error type (Refer to page 4.) ***** ≤...
  • Page 31 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <System> (2/7) Menu Menu item Command Status Note ***** :00000 Menu Language <Menu setting> <Writing of menu information> <For DX-TL5000E> Selection DW,***** RC ≥ ***** ***** ≤ EX,** DW,***** ***** ≥...
  • Page 32 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <System> (3/7) Menu Menu item Command Status Note <Writing of menu information> <Split 4a screen> <Split 4b screen> Multiplexer Setting Split 4 screen <Menu setting> DW,***** RC ≥ ***** :01100-01103 *****...
  • Page 33 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <System> (4/7) Menu Menu item Command Status Note Multiplexer Setting Split 16 screen <Menu setting> <Writing of menu information> <Split 16 screen> (continued) DW,***** RC ≥ ***** :01180-01195 EX,** DW,***** *****...
  • Page 34 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <System> (5/7) Menu Menu item Command Status Note <Writing of menu information> <Split 9a screen> <Split 9b screen> Multiplexer Setting Split 9 screen <Menu setting> (continued) DW,***** RC ≥ ***** :01316-01324 *****...
  • Page 35 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <System> (6/7) Menu Menu item Command Status Note Multiplexer Setting Sequence/ <Menu setting> <Writing of menu information> ***** :01400-01415 (continued) Single DW,***** RC ≥ 01400:display order 1 01401:display order 2 EX,** DW,***** *****...
  • Page 36 Command code table (continued) RS-232C [Direct operation specification] menu setting command form <System> (7/7) Menu Menu item Command Status Note On Screen <Menu setting> <Writing of menu information> ***** :00003 Clock/ Display Setting DW,***** RC ≥ ***** :00000-00002 Display Mode ***** ≤...

  • Page 37: Menu Data

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Menu Data>/<Option> Menu Menu item Command Status Note Load Menu Data Device Select <Menu setting> <Writing of menu information> ***** :00100 DW,***** RC ≥ ***** ***** ≤ EX,** DW,***** ***** ≥...

  • Page 38: Com/Lan

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <COM/LAN> When changing “Transmission Mode” in <RS-232C Setting> via RS-232C command, the actual operation may not reflect the new setting correctly. Check the communication operation after changing the setting. Menu Menu item Command...

  • Page 39: Ptz Setting

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <PTZ Setting> Menu Menu item Command Status Note ***** PTZ Camera Device <Menu setting> <Writing of menu information> 00400:CH1 00405:CH2 00410:CH3 Configuration DW,***** RC ≥ 00415:CH4 00420:CH5 00425:CH6 ***** ≤...

  • Page 40: Restore

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Restore> Status Note Menu Menu item Command <Menu setting> <Writing of menu information> ***** :12080 Restore Data to Range of Restore RC ≥ ***** Main HDD from DW,***** EX,** DW,***** *****...

  • Page 41: Memory

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Memory> Display <Memory> menu on the screen before setting the following items. Status Note Menu Menu item Command <Writing of menu information> Data Management Main Device Repeat <Menu setting> ***** :01553-01555 DW,*****...

  • Page 42: Other Settings

    Command code table (continued) RS-232C [Direct operation specification] menu setting command form <Other Settings> Command name Command Status Note Registering bookmark RC ≥ :Bookmark number BKMS,** ≤ 00:1 01:2 02:3 EX,** BKMS,** ≥ 03:4 04:5 05:6 06:7 07:8 :Error type (Refer to page 4.) Inputting password RC ≥...

  • Page 43: Rs-232C [Direct Operation Specification] Status Check Command Form

    Command code table (continued) RS-232C [Direct operation specification] status check command form (1/2) Status Note Command :System status <Inquiry for RC ≥ 00:Power off 02:Waiting for starting codec task recorder status> EX,** (41) 03:Waiting for starting system 04:Power on (device operation) MD? ≤...
  • Page 44 Command code table (continued) RS-232C [Direct operation specification] status check command form (2/2) Command Status Note <Inquiry for RC ≥ :Display output port 00:Output A 01:Output B display status> EX,** SWQ,** SWQ,** ≤ **** ≥ :Error type (Refer to page 4.) **** :Display mode 0101:CH1...

  • Page 45: Rs-232C [Quasi-Front Panel Operation] Command Form

    Command code table (continued) RS-232C [Quasi-front panel operation] command form (1/2) Status Note Operational Button Command Power On/Off POWER KKP0 ≤ RC ≥ EX,** KKP0 ≥ :Error type (Refer to page 4.) REC/STOP KKR0 ≤ RC ≥ Recording EX,** KKR0 ≥ RC ≥...
  • Page 46 Command code table (continued) RS-232C [Quasi-front panel operation] command form (2/2) Operational Button Command Status Note Turning the JOG dial to the right JOG dial KKJ0 ≤ RC ≥ EX,** KKJ0 ≥ KKJ1 ≤ RC ≥ Turning the JOG dial to the left EX,** KKJ1 ≥...

  • Page 47: Rs-232C Status Condition Change Notification

    Command code table (continued) Status condition change notification (1/2) Status Note Mode Warning notification LOG,**** **** :Log number 1100:Recording/Full (Normal area) ************ ≥ 1101:Recording/Full (Alarm area) 1102:Recording/Full (LPA area) 1200:Recording/Remaining capacity warning (Normal area) 1201:Recording/Remaining capacity warning (Alarm area) 1202:Recording/Remaining capacity warning (LPA area) :Recording operational error :Abnormal recording operation :Abnormal playback operation...
  • Page 48 Command code table (continued) RS-232C Status condition change notification (2/2) Mode Status Note Alarm notification NTFY01,** :Alarm number 00:Alarm 1 01:Alarm 2 02:Alarm 3 03:Alarm 4 ************ ≥ 04:Alarm 5 05:Alarm 6 06:Alarm 7 07:Alarm 8 08:Alarm 9 09:Alarm 10 10:Alarm 11 11:Alarm 12 12:Alarm 13...
