Read and understand this manual and all instructions before operating this Mower.
Battery-Powered Mower
Safety & Operating Instructions
UPDATED
MAY 2010
Model: CE6.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CE6.4 and is the answer not in the manual?

Questions and answers

Related Manuals for Neuton CE6.4

Summary of Contents for Neuton CE6.4

  • Page 1 Battery-Powered Mower Safety & Operating Instructions Model: CE6.4 UPDATED MAY 2010 Power Equipment EUTON 75 Meigs Road Vergennes, VT 05491 Toll-Free phone: 1-866-NEUTON1 (638-8661) Fax: 1-802-877-1213 Website: www.neutonpower.com MAIL INFO NEUTONPOWER Read and understand this manual and all instructions before operating this Mower.

  • Page 2: Table Of Contents

    Tools Needed: This indicates you will need a special tool to perform a maintenance function on your Mower. Neuton Power Equipment reserves the right to discontinue, change, and improve its products at any time without notice or obligation to the purchaser. The descriptions and specifications contained in this manual were in effect at the end of printing.

  • Page 3: Chapter 1: Important Safety Considerations

    Chapter 1: Important Safety Considerations We want you to enjoy years of safe and productive use from your NEUTON Battery-Powered Mower. Please take time to read the following instructions for safely operating your new Machine. Danger Label (268971) WARNING Label (259341)

  • Page 4: Preparing To Use Your Mower

    Mower before starting. • Never operate the NEUTON Mower without the proper guards or other safety and protective devices in place and properly connected. Inspect the machine and cutting blade to determine proper installation of these devices to determine they are in good repair, and they operate properly.

  • Page 5: Handling The Battery Safely

    Charger label matches the voltage of your Battery. Use of a different Charger may not allow the Battery to fully recharge and may cause a fire or explosion. Use of a non-approved NEUTON Charger will void your warranty.

  • Page 6: Chapter 2: Setting Up Your Neuton Mower

    Chapter 2: Setting Up Your NEUTON Mower NEUTON Mower Package Contents NEUTON CE 6.4 Mower Body Assembly (268531) Upper Handlebar Assembly (268771) (4) Handlebar Connector Knobs (175791) Lower Handlebar (267731) (2) Main Cable Retainers (268961) (2) Upper Handlebar Carriage Bolts (175781)

  • Page 7: Battery

    Step 1: Read the Safety & Operating Instructions before proceeding. The NEUTON Mower is a motorized cutting machine that uses a sharp Blade. For your safety, and for best results, it is important to read the information in “Chapter 1: Important Safety Considerations” before you assemble or use the Mower.

  • Page 8: Upper Handlebar

    Rotate the Handlebar into the upright position (Figure 5) and insert the two (2) 8mm x 25mm Carriage Bolts (the smaller of the four (4) Bolts included with your Neuton Product Pack) from the inside through one of the three (3) holes and screw on the Black Handlebar Connector Knobs also included in the Neuton Product Pack.
  • Page 9 • Use the NEUTON 36V Charger only with the NEUTON 36V Battery. Use of other Chargers or the NEUTON 36V Charger with other types of Batteries may result in bursting of the Battery, which could cause personal injury and property damage.
  • Page 10 Rear Bagger The NEUTON Rear Bagger lets you cut and catch your grass clippings, eliminating the need to rake. The Rear Bagger easily attaches to the rear of the Mower (Figure 10). The Bagger shipped unassembled. The following instructions outline the steps necessary to assemble, install, and remove the Bagger.
  • Page 11 If the Battery is not oriented correctly, it will not fully depress into the opening. If this happens, remove the Battery, recheck the orientation, and try again. Battery Cap Retainer Arm Label Figure 18 Figure 19 Safety & Operating Instructions NEUTON CE6.4 Battery-Powered Mower -...
  • Page 12 NOTE: The Analog Voltage Gauge will only show the Battery's voltage when the Battery is correctly inserted in the machine and the machine has been turned on as described in Chapter 3: Operating your Neuton Mower. Analog Voltage Gauge Figure 21...
  • Page 13 Spare Cutting Blade Blade Sharpener Protective Cover Rear Side Discharge Chute To learn more about these accessories, call us at 1- 866-Neuton1 (638-8661) or visit us on our web site: www.neutonpower.com Figure 22 Safety & Operating Instructions NEUTON CE6.4 Battery-Powered Mower -...
  • Page 14 NEUTON CE6.4 Product Specifications Motor 3800 Tip Speed 18,000 ft./min. AMP Idle 5 – 6 AMP Cutting 10 – 12 MAX Torque (Stall) 2.28 Ft.-Lbs. Size 750W, 36V DC/50 Amp Noise Under 80 Decibels Controls Start/Stop Safety Control Lever(s), Start and Stop...

  • Page 15: Chapter 3: Operating Your Neuton Mower

    Starting, stopping, and restarting an electric Motor repeatedly within a few seconds can generate a great deal of heat and damage the Motor. To protect the life of your NEUTON Mower, always wait at least five (5) seconds after stopping before restarting the Mower.

  • Page 16: Chapter 4: Charging And Caring For The Battery

    The Battery The NEUTON Mower comes with a sealed, lead acid Battery already installed at the factory. The Battery is 36 volts and rated at 10 amp-hours. The Battery should not leak, regardless of the position in which it is stored. Read “Handling the Battery Safely”...

  • Page 17: Recycling Your Used Battery

    INMETCO, P.O. Box 720, 245 Portersville Road, Ellwood City, PA 16117, (724) 758-2825; fax (724) 758-2845 To learn more about hazardous waste recycling, visit the Web site for Battery Council International [www.batterycouncil.org] or for the Environmental Protection Agency [www.epa.gov]. Safety & Operating Instructions NEUTON CE6.4 Battery-Powered Mower -...

  • Page 18: Chapter 5: Servicing Your Neuton Mower

    Blade to throw objects. Check components frequently, and replace them with the manufacturers recommended parts when necessary. • Check the Blade and Motor mounting bolts at frequent intervals for proper tightness. Use only authorized NEUTON replacement parts. • Keep your Mower free of grass, leaves, or other debris build-up.

  • Page 19: Removing And Attaching The Blade

    Battery to discharge faster. When this occurs, sharpen the Blade (assuming the Blade is otherwise in good condition). Tools and Supplies Needed: Mower • Fine-Toothed File or NEUTON Blade Sharpener (optional) • Safety Glasses Blade Adapter • Vise Remove the Blade (see “Removing and Attaching the Blade”).

  • Page 20: Chapter 6: Troubleshooting Tips

    Neuton Power Equipment Toll Free at: 1-866-NEUTON1 (638-8661) for assistance. Always remove the Battery before performing any adjustments, maintenance, or repairs to your Mower. Troubleshooting Table...
  • Page 21 ⇒ Verify your Standard 110V wall outlet is functioning correctly by plugging a lamp or other electrical device into the same socket on the wall outlet you are intending to use. Safety & Operating Instructions NEUTON CE6.4 Battery-Powered Mower -...

  • Page 22: Chapter 7: Parts Lists, Schematic Diagrams, And Warranty

    Chapter 7: Parts Lists, Schematic Diagrams, and Warranty Parts List - NEUTON CE6.4 Mower NOTE: Part numbers listed are available through Neuton Power Equipment. Ref# Part# Description 272141 Upper Handlebar Assembly 272041 Main Cable Retainer, Assy (Kit) 175791 Knob, Handlebar Connector, Black...
  • Page 23 Schematic Diagrams - NEUTON CE6.4 Mower 091013 Safety & Operating Instructions NEUTON CE6.4 Battery-Powered Mower -...
  • Page 24 091015 www.neutonpower.com...
  • Page 25 NOTES: Safety & Operating Instructions NEUTON CE6.4 Battery-Powered Mower -...

  • Page 26: Warranty Registration

    Please fill out this Warranty Registration card and mail it with a copy of your proof of purchase to the address referenced at the bottom of this page. IMPORTANT NOTE: If you purchased directly from Neuton Power Equipment or a Neuton Power Equipment dealer, you do not need to complete this registration form.
  • Page 27 CE6.4 Battery-Powered Mower is fit for ordinary purposes for which a product of this type is used. Neuton Power Equipment however, limits the implied warranties of merchantability and fitness in duration to a period of two (2) years in personal residential household use.
  • Page 28 Daily Checklist and Storing for your NEUTON Mower To help maintain your NEUTON Mower for optimum performance, we recommend you follow this checklist each time you use your machine. Also, follow the checklist for storing the machine. Do not insert the Battery until you have completed all of the daily checks and you have moved the Mower to the area that you are going to mow.
