FIRMWARE UPDATE

Download the latest MED600X3D Firmware from www.mede8erforum.com. UnZIP or UnRAR or join with HJ
Split and will find a file named install.img. Copy this file to the root directory of a Flash Drive. Plug the USB
Flash drive into one of the USB Host Ports on the MED600X3D.
DO NOT REMOVE POWER DURING THE EMERGENCY RECOVERY PROCEDURE.
Setup Menu Update with Auto Configuration Restore
Open the Setup Menu and select the "Misc" tab. Now select USB upgrade option. After +- 5 sec the screen
will display the current Firmware Version and the New Firmware Version. You will have the option to select
"OK" or "Cancel". Select "OK" and the MED600X3D will reboot and after +- 10 seconds the update process
will begin. During the update process the top Navigation Buttons LED will flash and you should see an install
progress bar on your TV screen. After the update is complete the MED600X3D will reboot with the new
firmware installed.
If the MED600X3D does not reboot within 5 seconds (after pressing the "Enter"
button) then press the "Home" button to initiate
Emergency Method (Resets Configuration to Default)
Disconnect the power jack at the rear of the MED600X3D then plug it back in - Now press the on/off button
and hold it pressed for 20 seconds and then release.
After approximately 15 seconds the LED on the MED600X3D will flash blue and you will get a progress bar on
your TV display (some TV's will not display this) wait until the MED600X3D re boots itself +- 60 sec. Your
MED600X3D firmware is now updated.
USB Host Port
Press on/off button for 20 Sec
REMOTE CONTROL OVER NETWORK
Enable the Web Remote in the Setup Menu. Remote Control the MED600X3D from a mobile device such as a
iPhone, iPad or any device that has WiFi and a built in Web Browser. Enter the MED600X3D IP into your Web
Browser with the correct Port number eg http://xxx.xxx.xxx.xxx:1024 "x" is your actual IP
DLNA DMR
The MED600X3D comes with a DLNA DMR function. That stands for Digital Living Network Alliance Digital
Media Renderer. That means another DLNA device can use the MED600X3D to process media without you
having to do anything else with the MED600X3D other than turning it on. Music can be played without having
to turn on the TV, or you can display photo's on your TV directly from your phone.
A Device which controls this process is called a DLNA DMC - Digital Media Controller. You can get DMC apps
for many devices - Android phones / tabs - Iphone / Ipad. Android Honeycomb dosn't come with a DMC
installed. Android Market has a lot of them, but not all are able to detect both the MED600X3D's DMR, and the
MED600X3D's Upnp server successfully. Bubbleupnp has been tested with MED600X3D and we suggest that
this is a good app to start playing and testing DLNA DMR functionality. Remember to turn the DMR 'on' in the
MED600X3D Setup Menu.
Page13
