- Page 1 User Guide EVGA Z97 Classified Specs and Initial Installation (Part 1) - 1 -...
-
Page 2: Table Of Contents
Table of Contents Before you Begin………………………………………………………………………3 Parts Not in the kit…………………………………………………………………….4 Intentions of the kit……………………………………………………………………4 Motherboard Specifications……………………………………………………………5 Unpacking and Parts Descriptions……………………………………………………..7 Equipment……………………………………………………………………………..7 Hardware Installation…………………………………………………………………..8 Component legend………..……………………………………………………………8 PCI-E Slot Breakdown………………………………………………………………..9 Rear I/O Panel legend………………………………………………………………..10 Preparing the Motherboard…………………………………………………………...11 Installing the CPU…………………………………………………………………….11 Installing the Cooling Device……………………………………….…………...…….12 Installing System Memory (DIMMs)……………...…………………..…..………...13 Compliance Information……………………………………………………………...14 - 2 -... -
Page 3: Before You Begin
BIOS that is focused on functionality, ultra high quality components and robust PCI-E 3.0 and memory trace layout. With these features and more, it is clear that the EVGA Z97 motherboards are engineered to exceed the best. - 3 -... -
Page 4: Parts Not In The Kit
Hard Drive or SSD Keyboard / Mouse Monitor (Optional) Optical Drive EVGA assumes you have purchased all the necessary parts needed to allow for proper system functionality. For a full list of supported CPUs on this motherboard, please visit www.evga.com/support/motherboard... -
Page 5: Motherboard Specifications
Motherboard Motherboard Specifications Size: EATX form factor of 12 inches x 10.3 inches Microprocessor support: Intel Socket 1150 Processor Operating Systems: Supports Windows 8 / 7 Contains Intel Z97 chipset System Memory support: Supports Dual channel DDR3 up to 2666MHz+. Officially supports up to 32GB of DDR3 memory. - Page 6 Onboard Audio: Creative Core3D Quad-Core Audio Processor (CA0132) Supports 6-channel (5.1) audio Supports Optical Output PCI-E 3.0 Support: Low power consumption and power management features Power Functions: Supports ACPI (Advanced Configuration and Power Interface) Supports S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4 (Suspend to disk - depends on OS), and S5 (soft - off) Expansion Slots: 5x PCI-E 16x slot 2x16/8, 1x8, 1x8/4, 1x8...
-
Page 7: Unpacking And Parts Descriptions
Unpacking and Parts Descriptions Equipment The following accessories are included with the EVGA Z97 Classified Motherboard: The EVGA Z97 Classified Motherboard This PCI-E motherboard contains the Intel Z97 chipset. I/O Shield Installs in the system case to block radio frequency transmissions, protect internal components from dust, foreign objects, and aids in proper airflow within the chassis. -
Page 8: Hardware Installation
Intel Z97 Classified Motherboard The EVGA Z97 Classified Motherboard with the Intel Z97 and PCH Chipset. Figure 1 shows the motherboard and Figure 2 shows the back panel connectors FIGURE 1. Z97 Classified Motherboard Layout - 8 -... -
Page 9: Pci-E Slot Breakdown
1. CPU Socket 1150 12. Debug LED / CPU Temp Monitor 23. Mini PCI-E/mSATA 2. Intel Z97 Southbridge 13. CMOS Battery 24. Front Panel Audio Connector 3. CPU Fan Header (1 amp PWM) 14. USB 3.0 Headers 25. EVGauge 4. DDR3 Memory DIMM Slots 1-4 15. -
Page 10: Rear I/O Panel Legend
Figure 2. Chassis Rear Panel Connectors 1. USB 2.0 4. Intel i210 NIC 7. Optical Out 2. USB 3.0 5. Intel i217 NIC 8. Analog Audio Output Jacks 3. BIOS/CMOS Reset 6. Mini Display Port Analog Audio Port Breakdown 2/2.1 (Channel) 4.0/4.1 (Channel) 5.1 (6 Channel) Blue... -
Page 11: Preparing The Motherboard
Preparing the Motherboard Installing the CPU Be very careful when handling the CPU. Hold the processor only by the edges and do not touch the bottom of the processor. Note: Use extreme caution when working with the CPU, not to damage any pins in the CPU socket on the motherboard! Use the following procedure to install the CPU onto the motherboard: Remove the plastic protective socket cover by pulling... -
Page 12: Installing The Cooling Device
Align the notches on the CPU to the notches in the socket. Lower the processor straight down into the socket. Note: Make sure the CPU is fully seated and level in the socket. Lower the load plate so it is resting on the CPU. Carefully lock the lever back into place. -
Page 13: Installing System Memory (Dimms)
Installing System Memory (DIMMs) Your Z97 Classified has (4) 240-pin slots for DDR3 memory. These slots support 2GB, 4GB and 8GB DDR3 DIMMs. There must be at least one memory slot populated to ensure normal operation. The Intel Z97 chipset supports dual channel memory; supports a maximum of 32GB of DDR3 and up to 2666MHz+ in dual channel configuration. -
Page 14: Compliance Information
Original Purchaser. Upon termination, for any reason, all copies of Software and materials must be immediately returned to EVGA and the Original Purchaser shall be liable to EVGA.com CORP for any and all damages suffered as a result of the violation or default.
