Gas hob
ZGS 782 IT
ZGS 782 ICT
GB
IE

Advertisement

Table of Contents
loading

Summary of Contents for Zanussi ZGS 782 IT

  • Page 1 Instruction booklet Gas hob ZGS 782 IT ZGS 782 ICT...
  • Page 2 Thank you for selecting our appliance Thank you for selecting our appliance Thank you for selecting our appliance Thank you for selecting our appliance Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances.
  • Page 3: Table Of Contents

    Contents Important Safety Information Important Safety Information ............Important Safety Information ................................... 4 4 4 4 4 Important Safety Information Important Safety Information ............Description of the Hob ................6 Instructions for the User Instructions for the User ..............
  • Page 4: Important Safety Information

    Important Safety Information Y Y Y Y Y ou MUST r ou MUST r ou MUST read these war ou MUST r ead these war ead these war nings car ead these war nings car nings carefully befor nings car efully befor efully befor efully before installing or...
  • Page 5 When using the hob for a long period time, the ventilation should be improved, by opening a window or increasing the extractor speed. Do not use this hob if it is in contact with water. Do not operate the hob with wet hands.
  • Page 6: Description Of The Hob

    Description of the Hob 1. Hob Top 2. Auxiliary Burner 3. Semi-rapid Burner 4. Rapid Burner 5. Triple Crown 6. Control knobs...
  • Page 7: Instructions For The User

    Instructions for the User INSTALLATION Any gas installation must be carried out by a registered Any gas installation must be carried out by a registered Any gas installation must be carried out by a registered Any gas installation must be carried out by a registered Any gas installation must be carried out by a registered competent person, and in accordance with existing rules competent person, and in accordance with existing rules...
  • Page 8: Operation

    Operation Operation Operation Operation Operation Hob burners control knobs Hob burners control knobs Hob burners control knobs Hob burners control knobs Hob burners control knobs The symbols on the knobs mean that : there is no gas supply there is maximum gas supply there is minimum gas supply Lighting the burners Lighting the burners...
  • Page 9 Do not keep the control knob pressed for more than 15 seconds. If the burner does not light even after 15 seconds, release the control knob, turn it the "off" position and wait for at least one minute before trying to light the burner again. When switching on the mains, after installation or a power cut, it is quite normal for the spark generator to be activated automatically.
  • Page 10 As soon as a liquid starts boiling, turn down the flame so that it will barely keep the liquid simmering. Use only pans or pots with flat Use only pans or pots with flat Use only pans or pots with flat Use only pans or pots with flat Use only pans or pots with flat bottom.
  • Page 11: Maintenance And Cleaning

    Maintenance and Cleaning Before any maintenance or cleaning can be carried out, Before any maintenance or cleaning can be carried out, Before any maintenance or cleaning can be carried out, Before any maintenance or cleaning can be carried out, Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob fr you must DISCONNECT the hob fr you must DISCONNECT the hob from the electricity supply...
  • Page 12 Pay attention when replacing the pan Pay attention when replacing the pan Pay attention when replacing the pan Pay attention when replacing the pan Pay attention when replacing the pan supports in order to avoid damaging supports in order to avoid damaging supports in order to avoid damaging supports in order to avoid damaging supports in order to avoid damaging...
  • Page 13: Something Not Working

    Something Not Working? If the hob is not working correctly, please carry out the following checks before contacting your local Service Force Centre. SYMPTOM SYMPTOM SYMPTOM SYMPTOM SYMPTOM SOLUTION SOLUTION SOLUTION SOLUTION SOLUTION There is no spark when Check that the unit is plugged lighting the gas.
  • Page 14: Instructions For The Installer Instructions For The Installer

    Instructions for the Installer Engineer technical data Engineer technical data Engineer technical data Engineer technical data Engineer technical data OVERALL DIMENSIONS OVERALL DIMENSIONS OVERALL DIMENSIONS OVERALL DIMENSIONS OVERALL DIMENSIONS Width: 744 mm Depth: 510 mm CUT OUT DIMENSIONS CUT OUT DIMENSIONS CUT OUT DIMENSIONS CUT OUT DIMENSIONS CUT OUT DIMENSIONS...
  • Page 15 BURNER RAPID SEMI-RAPID A U X I L I A R Y TRIPLECROWN TYPE OF GAS POSITION M A X MIN M A X MIN M A X MIN M A X NOMINAL THERMAL POWER 0.75 0.45 0.33 NATURAL GAS NOMINAL FLOW 20 mbar RATE...
  • Page 16: Important Safety Requirements

    Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). For appliances installed in the Republic of Ireland please refer to NSAI- Domestic Gas Installation I.S.
  • Page 17: Installation

    The minimum distance combustible material or a cooker hood can be fitted above the hob is 650 mm. For appliances installed in the Republic of Ireland please refer to NSAI- Domestic Gas Installation I.S 813 Current Edition Section 7- Permitted Locations of Appliance. Installation IMPOR IMPOR...
  • Page 18: Gas Connection

    On the end of the shaft, which includes the G 1/2" threaded elbow, adjustment is fixed so that the washer is fitted between the components as shown in the diagram. Screw the parts together without using excessive force. FO 0264 A) End of shaft with nut B) Washer C) Elbow...
  • Page 19: Building In

    Building In B B B B B uilding over a cupboard or drawer uilding over a cupboard or drawer uilding over a cupboard or drawer uilding over a cupboard or drawer uilding over a cupboard or drawer If the hob is to be installed above a cupboard or drawer it will be necessary to fit a heat resistant board below the base of the hob on the underside of the work surface.
  • Page 20: Fitting The Hob Into The Worktop

    Fitting the Hob into the Worktop Carry out the building in of the hob as follows: • place the seals supplied with the hob on the front edge of the cut out. Then, place them at 86 mm from the side edges and at 10 mm from the rear edge, as shown in the diagram, taking care that the seals meet without overlapping.
  • Page 21: Electrical Connections

    Electrical Connections Any electrical work required to install this hob should be Any electrical work required to install this hob should be Any electrical work required to install this hob should be Any electrical work required to install this hob should be Any electrical work required to install this hob should be carried out by a qualified electrician or competent person, carried out by a qualified electrician or competent person,...
  • Page 22: Wiring Diagram

    3) Connect the brown (live) wire to the terminal in the plug which is marked with the letter 'L' or coloured red. Upon completion there must be no cut, or stray strands of wire present and the cord clamp must be secure over the outer sheath. A cut off plug inserted into a 13 amp socket is a serious A cut off plug inserted into a 13 amp socket is a serious A cut off plug inserted into a 13 amp socket is a serious...
  • Page 23: Fault Finding

    Fault Finding Preliminary Electrical Systems Check Preliminary Electrical Systems Check Preliminary Electrical Systems Check Preliminary Electrical Systems Check Preliminary Electrical Systems Check Blue Brown S T A R T S T A R T S T A R T S T A R T S T A R T Isolate appliance and carry out:...
  • Page 24 A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK Appliance must be electrically disconnected - meter set on W (Ohms) x 1 scale and adjust zero if necessary. — Test leads from any appliance earth point to earth pin on plug. Resistance should be less than 0.1 W (Ohm), check all earth wires for continuity and all contacts clean and tight.
  • Page 25 Ignition System / Gas Ignition Ignition System / Gas Ignition Ignition System / Gas Ignition Ignition System / Gas Ignition Ignition System / Gas Ignition Check gas supply at Ignitor does not spark burner Check plug top fuse and Light burner manually replace if necessary Check polarity and Check by pass simmer...
  • Page 26: Commissioning

    Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. 1) Turn the gas tap to the MAX position and ignite. 2) Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times.
  • Page 27: Conversion From Natural Gas To Lpg

    Conversion from Natural Gas to LPG IMPOR IMPOR IMPOR IMPOR IMPOR T T T T T ANT The replacement/conversion from natural gas to LPG should only The replacement/conversion from natural gas to LPG should only The replacement/conversion from natural gas to LPG should only The replacement/conversion from natural gas to LPG should only The replacement/conversion from natural gas to LPG should only be undertaken by a competent person.
  • Page 28: Guarantee/Customer Service

    Standard guarantee conditions Standard guarantee conditions We, Zanussi-Electrolux, undertake that if within 12 months of the date of the purchase this Zanussi-Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·...
  • Page 29 Service and Spare Parts Service and Spare Parts Service and Spare Parts Service and Spare Parts Service and Spare Parts In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your local Service Force Centre by telephoning 0870 5 929 929 0870 5 929 929 0870 5 929 929...
  • Page 30: European Guarantee

    European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qualifications: •...
