SALES NETWORK
SAMSUNG TECHWIN CO.,LTD.
•
145-3, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, 462-120, Korea
TEL : +82-31-740-8151~8 FAX : +82-31-740-8145
SAMSUNG TECHWIN AMERICA,LTD.
•
1480 Charles Willard St. Carson, CA 90746, UNITED STATES
TEL : +1-310-632-1234 FAX : +1-310-632-2195
www.samsungtechwin.com
www.samsungcctv.com
SAMSUNG OPTO-ELECTRONICS UK,LTD.
•
Samsung House, 1000 Hillswood Drive, Hillswood Business Park
Chertsey Surrey KT16 OPS
TEL : +44-1932-45-5308 FAX : +44-1932-45-5325
P/No. : Z6806-0750-01D
VAN 08. 12
High Strength
10X
Zoom
High-Resolution 10X Vandal-Proof Dome Camera SVD-4300
Thank you for purchasing a SAMSUNG CCD CAMERA.
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
User's Manual
ENGLISH
Advertisement
Table of Contents
Related Manuals for Samsung SVD-4300
Summary of Contents for Samsung SVD-4300
- Page 1 SALES NETWORK SAMSUNG TECHWIN CO.,LTD. • 145-3, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, 462-120, Korea Thank you for purchasing a SAMSUNG CCD CAMERA. TEL : +82-31-740-8151~8 FAX : +82-31-740-8145 Before attempting to connect or operate this product, SAMSUNG TECHWIN AMERICA,LTD. SAMSUNG OPTO-ELECTRONICS UK,LTD.
- Page 2 Before operating the camera, confirm the camera model and proper input power voltage. In order to that you can understand this manual thoroughly, we'll introduce our model description. ■ SVD-4300 SERIES •NTSC MODEL •PAL MODEL SVD-4300(W)N SVD-4300(W)P The lightning flash with an arrowhead symbol, within an equilateral triangle is ■...
- Page 3 Features Samsung Techwin cares for the environment at all product manufacturing stages to preserve the environment, and is taking a number of steps to provide customers with more environment-friendly products.The Eco mark represents Samsung Techwin s will to create environment-friendly products, and indicates that the product satisfies the EU RoHS Directive.
-
Page 4: Table Of Contents
Contents Precautions • CAM TITLE • WHITE BALANCE • BACKLIGHT Components and Accessories • MOTION DETECTION • FOCUS Overview • EXPOSURE • SPECIAL • RESET Connection • EXIT Connecting To Monitor Connecting To Power RS-485 communication control Troubleshooting Specification Operating Your Camera Menu Configuration Dimension Menu Setup... -
Page 5: Precautions
Precautions Do not install the camera in Do not install or use the camera in an Do not drop the camera or subject Never keep the camera face to extreme temperature conditions. environment where the humidity is high. them to physical shocks. strong light directly. -
Page 6: Components And Accessories
Components and Accessories Overview 1. SVD-4300 2. Instruction Manual 3. Quick Install Guide 4. Wrench 5. Ø5 Tapping Screws 4EA 6. Template 7. Installation Video Output Cable COLOR CCD CAMERA User’s Manual COLOR CCD CAMERA User’s Manual... -
Page 7: Overview
Overview Connection Pan Base Connecting to Monitor control panning angle of camera Connect the VIDEO-OUT jack to the VIDEO-IN jack of monitor. Rotate Base Holding Screw fix rotated position Rotate Base control rotating angle of camera Pan Base Holding Screws (Color : Silver) fix panned position Auto Focus 10x Zoom Lens Module. -
Page 8: Connecting To Power
RS-485- Using a RS-485 communication, it will be able to control the ZOOM/FOCUS and OSD menu at the SAMSUNG TECHWIN System Controller or DVR. (1) The case which it controls from the PC Using a RS-485 converter, It connects to RS-485 control cable outside camera... -
Page 9: Operating Your Camera
Operating Your Camera Menu Configuration Menu Setup Use the six buttons on back of the camera. MAIN SETUP MENU SET button AF button UP button CAM TITLE • • WHITE BALANCE ATW(OUTDOOR) MANUAL • • • BACKLIGHT • • • MIDDLE •... -
Page 10: Cam Title
Operating Your Camera 3. Press SET button. MAIN SETUP Change the status using the Select feature using the UP CAM TITLE or DOWN button. LEFT or RIGHT button. WHIET BAL BACKLIGHT MOTION DET FOCUS EXPOSURE SPECIAL RESET EXIT 3. Change the status of the selected feature using the LEFT or RIGHT button. 4. -
Page 11: White Balance
Operating Your Camera 5. Select on screen position of the CAM TITLE. WHITE BALANCE CONTROL Move the cursor to 'POS' and press SET button. Your camera provides three 'WHITE BAL' control modes for your choosing in adjusting the white balance. 1. -
Page 12: Backlight
Operating Your Camera Notes MOTION DETECTION • Proper White Balance may not be obtained under the following conditions. This product has a feature that allows you to observe movements of objects in When the scene contains mostly high color temperature object, such as a blue 4 different areas on the screen, and the words ‘MOTION DETECTED’... -
Page 13: Focus
Operating Your Camera •ONE PUSH : Focus is automatically adjusted just once, FOCUS after zoom position is changed. Select ' ONE PUSH' and press the SET button to confirm. Increase or decrease optical MAIN SETUP CAM TITLE zoom (ZOOM) or digital zoom (D-ZOOM) positions using the directional buttons WHIET BAL while verifying the changes on screen. - Page 14 Operating Your Camera •FAST: To move zoom fast. •SLOW: To move zoom slowly. ZOOM POS INIT: Configure zoom position using this feature. Position the indicator ove 'ZOOM POS INIT' using the LEFT or RIGHT button. Notes FOCUS SETUP • The 'ZOOM SPEED' mode cannot be used if 'MODE' is set to 'AUTO' and 'ZOOM TRK' is 'ON'.
-
Page 15: Exposure
Operating Your Camera SMART ZOOM : EXPOSURE 'SMART ZOOM' is acted by motion perception. 'SMART ZOOM' acts zoom as 'TARGET ZOOM' that is established if motion is sensed. (Condition : when all 'MOTION DET MODE' and 'SMART ZOOM MODE' are 'ON') 'SMART ZOOM' EXPOSURE SETUP returns as 'START ZOOM' after delay as 'DWELL TIME' establishing after action. - Page 16 Operating Your Camera IRIS: Set 'IRIS' to 'AUTO' or 'MANUAL'. Position the indicator over 'IRIS' using the UP •A.FLK (NTSC: 1/100, PAL: 1/120): Flicker-free mode or DOWN button and then select the desired iris mode using the LEFT or RIGHT •ESC: Automatic shutter speed setting (optimal) button.
- Page 17 SENS-UP BRIGHTNESS 25..IRIS AUTO SSNR(Samsung Super Noise Reduction): On screen noise reduction. SHUTTER 1. Position the indicator over 'SSNR' using the UP or DOWN button. NORMAL 2. Set 'SSNR' to the desired mode using the LEFT or RIGHT button.
-
Page 18: Special
Operating Your Camera •PRESET NO : Up to eight different preset configurations are supported. SPECIAL USER PRESET SETUP SPECIAL SETUP PRESET NO. NO. 1 USER PRESET PRESET MODE PRIVACY PRESET SAVE DAY/NIGHT COLOR PRESET CLEAR SYNC COMM ADJ PRESET DEFINED IMAGE ADJ •PRESET MODE: Configure initial settings under FOCUS, EXPOSURE, etc. - Page 19 Operating Your Camera •PRESET CLEAR: Clear configured preset. •GROUP SEL : Choose up to eight groups. Each group can consist of four mask areas. USER PRESET SETUP •AREA SEL : Configure eight mask areas. PRESET NO. NO. 1 •AREA MODE : Mask area display. PRESET MODE •MASK TONE : Adjust desired mask color level.
-
Page 20: Reset
Operating Your Camera SYNC : Two synchronization modes are available INTERNAL and EXTERNAL LINE-LOCK. •CAM ID : Assign ID number to the camera. It is restricted available to set ID from In LINE-LOCK mode, it synchronizes the camera’s video out signal to the external 0 to 255. -
Page 21: Troubleshooting
Troubleshooting Specifications Refer to the following table if you are experiencing trouble with your camera. SVD-4300(W)N SVD-4300(W)P Contact an authorized technician if the table does not provide you with a Input Voltage AC24V(±10%), DC 12V(±10%) solution to the trouble. Input Current 290mA(Steady-state) 460mA(Zoom, Focus, Day&night motor operating) -
Page 22: Dimension
Ø 148mm SVD-4300(W)N SVD-4300(W)P Communication RS485 External Control(TRX+,TRX-) 2400bps, 4800bps, 9600bps, 19200bps, 38400bps and 57600bps selectable SAMSUNG TECHWIN PROTOCOL AVAILABLE PELCO-D PROTOCOL AVAILABLE Privacy Function ON/OFF(32Zones, It consists of 8Group 4Programmable Zone per Screen) FLIP Vertical, Horizontal, Vertical-Horizontal, OFF Selectable... -
Page 23: Declaration Of Conformity
DECLARATION OF CONFORMITY MEMO Application of Council Directive(s) 89 / 336 / EEC Manufacturer's Name SAMSUNG TECHWIN CO., LTD Manufacturer's Address SAMSUNG TECHWIN CO., LTD 42, SUNGJU-DONG CHANGWON-CITY, KYUNGNAM, KOREA, 641-716 European Representative Name European Representative Address Equipment Type/Environment CCTV Camera... - Page 24 MEMO...
