E78134
1. Remove the spare wheel.
2. Unscrew the retaining bolt by
turning anti-clockwise and
remove the jack with the wheel
brace.
E78135
Wheels and tyres
213
1. After using the jack, turn the
handle until the arrow on the arm
points directly towards the dot in
order to attach the wheel brace
to the jack.
2. Clip the wheel brace onto the jack
handle and fold the handle back
against the jack as shown in the
graphic.

Jacking and lifting points

CAUTION
Use only the specified jacking
points. If you use other positions,
you may damage the body, steering,
suspension, engine, braking system
or the fuel lines.
