Thank you for purchasing this CLARKE 37" Wood lathe, designed for DIY and semi professional use.
Before assembling this machine, please read this manual thoroughly and follow all instructions
carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the
date of purchase. Please keep your receipt as it will be required as proof of purchase. This guarantee
is invalid if the product is found to have been abused or tampered with in any way, or not used for the
purpose for which it was intended.
Faulty goods should be returned to their place of purchase, no product can be returned to us without
THIS MACHINE MUST NOT BE MODIFIED, OR USED FOR ANY PURPOSE
SPECIFICATIONS
Motor .............................................................................................. 230V 50Hz 1Ph
Turning Capacity
Spindle Speeds
Headstock Drive Spindle
Tailstock Spindle ............................................................................ No. 1 Morse Taper
Tailstock Spindle Advance ........................................................... 2
Overall Dimensions (LxWxH) ......................................................... 54
WARNING:
Power Rating ................................ 370W
Switch Type ................................... No Volt Release
(Between Centres) ....................... 37 in (940mm)
(Over Bed) .................................... 12 in Dia (305mm)
1. .................................................... 475 RPM
2. .................................................... 838 RPM
3. .................................................... 1374 RPM
4. .................................................... 2215 RPM
5. .................................................... 3260 RPM
Inboard .......................................... a. No. 1 Morse Taper
....................................................... b. External 3/4 UNF thread
Outboard ...................................... External 3/4 UNF Left Hand
3
thread
3 / in (60mm)via hand wheel)
8
1 / x 15 3 / x 12 1 / in
8 4 8
(1,375x400x308 mm)
