InSinkErator Model LC-50 Product Features

PROJECT:
APPLICATION
Designed for light duty foodservice operation in:
• Convenience/grocery store deli's
• Fast food restaurants
• Church/office kitchens
• Bed and breakfast inns
IMPORTANT: The model LC-50 is designed specifically for light duty
foodservice use. Use of this disposer in applications other than those
named above may void your warranty. If you are unsure of a potential
application, call the factory at 1-800-845-8345.
PRODUCT FEATURES & SPECIFICATIONS
• Foodservice design with the ease and flexibility of a household unit
• Disposer mounting included with unit. Mounting fits standard 3-1/2 – 4"
(88.9 mm – 101.6 mm) sink opening. No welding required.
• Standard wall switch operates the disposer
• Automatic reversing motor for longer life and trouble-free operation
• Stainless steel grind chamber
• Cast nickel chrome cutting element
• 1-year full warranty from date of installation
• 35 lb. (15.9 kg) shipping weight
• 1/2 HP
• Continuous-duty commercial motor
• 1725 RPM
• 5.8 amps
• Single Phase
DIMENSIONS
3
2
1
7 8
NOTE: Plumb 1-1/2" (38.1 mm) waste line to prevent standing water
in disposer motor housing.
4700 21st STREET
RACINE, WI 53406
TEL: 800-845-8345
FAX: 262 554-3620
www.insinkerator.com
InSinkErator is a division of Emerson Electric Co.
LIGHT DUTY MODEL LC-50
4
1
14-1/4"
2
3-5/16" min. ID
6
3 4-15/16"
5
4 3-7/16"
5 15/16" DIA
6 7-3/8"
7 4"
8 5-3/4"
9
9
15/16" ID
ELECTRICAL SPECIFICATIONS
LC50-11 – 120V, 60 Hz, 5.8 amps, UL/CUL
LC50-12 – 230V, 50/60 Hz, 375 watts
LC50-13 – 220-240V, 50 Hz, 375 watts,
BEAB, supplied with shuko plug
LC50-14 – 120V, 60 Hz, 5.8 amps, NOM
361.9 mm
85.1 mm
125.2 mm
86.8 mm
24.3 mm
187.1 mm
101.6 mm
145.2 mm
33.0 mm
Our products appear on The KCL CADalog
CD-ROM based CAD Foodservice Symbol
Library. More information is available from
Kochman Consultants, Ltd. at www.kclcad.com.
InSinkErator ©2008
ITEM NO.:
The Emerson logo is a
trademark and a service mark
of Emerson Electric Co.
Printed in USA Form No. F198-08J-45-02
