Summary of Contents for Samsung SPF-85M
-
Page 2: Installation
Using and Safety Symbols Power Installation Cleaning Safety Symbols Make sure to follow the directions below to prevent accidents and damage to the product. Failure to follow the accompanying directions may lead to serious injury or death. Failure to follow the accompanying directions may lead to minor personal injury or property damage. Using and Safety Symbols Power... - Page 3 Do not connect more than one appliance to a single outlet, as an overheated outlet may cause fire. Do not use force to pull the power cord. Don't place anything heavy on the power cord, as this may cause electric shock or fire. Make sure to turn the power off and disconnect the power plug from the outlet before moving the product.
-
Page 4: Safety Symbols
Using and Safety Symbols Power Installation Cleaning Installation When installing the product on a cabinet or shelf, do not let the front end of the product project beyond its front edge. Failing to do so, may cause the product to fall, resulting in a product malfunction or personal injury. - Page 5 Using and Safety Symbols Power Installation Cleaning Using and Cleaning Do not insert any metal objects such as forks, wire, or gimlets, or flammable items such as paper or matches into the ports at the back of the product, as this may cause electric shock or fire.
- Page 6 If the product needs to be installed in a location that doesn't satisfy general conditions, make sure to contact one of our service engineers about the installation as the product may encounter serious quality problems due to its environment. This refers to locations exposed to conditions such as heavy fine dust, chemicals, high or low temperature, moisture, or when the product needs to be used continually without a break over a long time.
- Page 7 Features Components Front Back Side Features Expansion of built-in memory using memory cards. Instant view of stored images. Background music function. Provides a Mini-Monitor function. Stylish Design A premium, stylish design that can be used as a decoration on a desk or table. A rotating stand that allows vertical/horizontal placement.
- Page 8 Warranty Quick Start User Manual (Not available in all locations) Cables USB cable Power cord Power Adapter (A-mini B type) Features Components Front Back Side Front The product color and shape may vary depending on the model. [MENU] Menu Button Displays the menu window at the bottom left corner of the screen.
- Page 9 Back The product color and shape may vary depending on the model. Connect the power adapter to this jack. DC –In Jack Connect the power cord to the power terminal of the power adapter. Turns the product on or off. ] Power Button Hold down the power button for about 2 seconds.
- Page 10 You can listen to sound by connecting headphones or earphones to the product. Headphone connection jack MEMORY CARD Allows you to insert an optional memory card. (Only applicable for SD/MS card) Connect a PC or an external device using a USB cable. Connect your Digital Photo Frame to a PC's USB terminal Up stream terminal with a USB cable.
-
Page 11: Memory Card
Power Memory Card Connecting the Power Connect the adapter cable to the power terminal on the back of the product. Connect the power cord to the power adapter. Plug the power cord for the product into a nearby outlet. Press the [ ] button to turn on the power. - Page 12 (For more information on external devices and their cables, contact a relevant service center.) Samsung carries no liability for external device malfunctions caused by using any cable except the standard cables specified for each device. Some external products provide a cable that does not meet USB standards. Hence, they may cause a malfunction.
- Page 13 MEMORY CARD Slide the card in the direction marked on the top of the card. Removing the memory card while playing MP3s, movies, or photos, may cause the product to operate abnormally. In this case, turn the product off and on. Recommended capacity for different memory card types SD / MicroSD / MiniSD ≤...
- Page 14 If no button is pressed for ten (10) minutes, Slideshow or Clock mode is activated. However, if a music file is being played, Clock mode is activated and the filename of that music file is displayed. You can switch to Clock mode even when the movie is paused. In some cases, you can switch to the Movie List screen.
- Page 15 If you press the Menu button, the menu of the selected item is displayed on the screen. Menu Description Open Opens the selected folder. Copy Copies the selected folder. Delete Deletes the selected folder. The menu displayed when selecting a thumbnail. If you press the Menu button, the menu of the selected item is displayed on the screen.
- Page 16 If you press the Menu button, the menu of the selected item is displayed on the screen. This product can only support up to 4,000 pictures. If there are more than 4,000 pictures, slideshow will not be played for the remaining pictures.
- Page 17 Direct Functions Menu Description MENU Opens the on-screen menu and exits from the menu. Plays the next file. Plays the previous. Adjusts the volume. Play or pause a Slideshow. User Photo Music Movie Clock & Alarm Settings Guide Music The menu displayed when selecting a list. If you press the Menu button, the menu of the selected item is displayed on the screen.
- Page 18 If you press the Menu button, the menu of the selected item is displayed on the screen. Sub-Menu Menu Description All musics, Music in Folder, Shuffle all musics, Shuffle music in Folder, Repeat one music Play Mode Selects the play mode. Direct Functions Menu Description...
- Page 19 Sub-Menu Menu Description Play Movie Plays a file. All movies, Movie in Folder, Shuffle all movies, Shuffle movie in Folder, Repeat one movie Play Mode Selects the play mode. Copy Copies the selected file to a different storage device. (Activated when a storage device is connected.) Copy All Files Copies all files to a different storage device.
- Page 20 Clock & Alarm Sub-Menu Detailed Menu Menu Description Month, Day, Year, Hour, Minute, am/pm (when the Time Format is set to 12 Hours). Month, Day, Year, Hour, Minute (when the Time Format is set to 24 Hours). Date and Time Sets the date and time.
- Page 21 Sub-Menu Detailed Menu Menu Description English, Deutsch, Español, Français, Italiano, Nederlands, Polski, Русский, Language Português, Svenska, Türkçe, 简体中文, 日本語,한국어 You can select the language for the product. Brightness 0~100 Adjusts the brightness of the screen. Auto Rotation Off, On Off : If you set the frame on its edge during a SlideShow, even if the sensor detects the change, the picture does not rotate accordingly.
- Page 22 USB cable, the screen will not be turned off even if the Off Time is reached. You can update the product by using a USB memory stick or memory card Firmware Update (SD/MS). For the latest firmware file, visit www.samsung.com. Reset Settings Yes, No Update/Reset...
- Page 23 The Digital Photo Frame not only allows you to appreciate photos but also provides an additional Mini-Monitor function. The Mini-Monitor is a function for using the Digital Photo Frame as an auxiliary monitor. Its usage is simple as the Digital Photo Frame connects to your PC via a USB cable. This function allows you to work more efficiently at your PC by using an additional monitor.
- Page 24 11. If the video card's driver is updated while Frame Manager is installed, the Mini-Monitor function may not operate properly. In this case, remove Frame Manager and install it again. 12. If the rotation function of Frame Manager is used, the current location setting of Mini-Monitor may be changed. Even if the rotation function is used, the screen will not be shown to be rotating in the [Display Properties] window.
-
Page 25: Specifications
Specifications Supported Files Specifications Items Specifications Model Name SPF-85M Type 8 "(20 cm)TFT Resolution 800 x 600 Panel Contrast Ratio 500 : 1 Interface Digital 6 bit JPEG Max Image Resolution 3200x2400(8Mb) Photo (Progressive,CMYK JPEG is not supported.) MPEG4 : Advanced Simple Profile(ASP), Audio(MP3), 4Mbps... - Page 26 1.7 lbs / 787 g (Without Stand) Weight 1.8 lbs / 827 g (With Stand) The product design may differ according to the model, and specifications are subject to change without prior notice for product performance enhancement. Class B Equipment (Information Communication equipment for residential use) This product complies with the Electromagnetic Compatibility Directives for residential Use and can be used in all areas including common residential areas.
-
Page 27: Troubleshooting
The button operating sound will not be heard while a [Background Music, there is no button operating sound. Music, or Movie file] is playing. Check whether the FrameManager program is installed. The FrameManager icon is not displayed. Select Start- Programs - Samsung - FrameManager to restart FrameManager. Reboot your computer. - Page 28 2) Cable for Connecting Other Devices terminal, use the USB cable provided with the external device. Troubleshooting Terminology Service Centers Service Centers If you need a product service, contact or visit a Samsung service center. For services for network connection and the Server. Services Contacts...
- Page 29 Samsung Electronics web site http://www.samsung.com If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. North America U.S.A 1-800-SAMSUNG (7267864) http://www.samsung.com/us CANADA 1-800-SAMSUNG (7267864) http://www.samsung.com/ca MEXICO 01-800-SAMSUNG (7267864) http://www.samsung.com/mx Latin America ARGENTINE 0800-333-3733 http://www.samsung.com/ar...
- Page 30 022 - 607 - 93 - 33 PORTUGAL 808 20 - SAMSUNG (7267864) http://www.samsung.com/pt SLOVAKIA 0800-SAMSUNG (7267864) http://www.samsung.com/sk SPAIN 902 - 1 - SAMSUNG (902 172 678) http://www.samsung.com/es SWEDEN 0771 726 7864 (SAMSUNG) http://www.samsung.com/se SWITZERLAND 0848 - SAMSUNG(7267864, CHF 0.08/min) http://www.samsung.com/ch 0845 SAMSUNG (7267864) http://www.samsung.com/uk...
- Page 31 3030 8282 INDIA 1800 110011 http://www.samsung.com/in 1-800-3000-8282 INDONESIA 0800-112-8888 http://www.samsung.com/id JAPAN 0120-327-527 http://www.samsung.com/jp MALAYSIA 1800-88-9999 http://www.samsung.com/my NEW ZEALAND 0800 SAMSUNG (0800 726 786) http://www.samsung.com/nz 1-800-10-SAMSUNG(726-7864) 1-800-3-SAMSUNG(726-7864) PHILIPPINES http://www.samsung.com/ph 1-800-8-SAMSUNG(726-7864) 02-5805777 SINGAPORE 1800-SAMSUNG(726-7864) http://www.samsung.com/sg 1800-29-3232 THAILAND http://www.samsung.com/th 02-689-3232 TAIWAN 0800-329-999 http://www.samsung.com/tw...
