Samsung SPF83H Installation Manual

Frame manager
Hide thumbs Also See for SPF83H:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Manual
System Requirements
OS : Windows XP SP2
USB : Extended Host Controller (EHCT) for USB 2.0
RAM : 256 MB or above
Installation
Install the Application first before connecting the Digital Photo Frame to a PC.
1. Click Frame Manager icon in the main page of the CD manual to run the install file.
2. Press "Next" button.
3. Click on "Change" button to Select the path on your PC where you want the software to be stored/installed.
System Requirements
|
System Requirements
|
Installation
|
|
Installation
|
|
Installing USB
|
driver
Installing USB
|
driver

Advertisement

Table of Contents
loading

Related Manuals for Samsung SPF83H

Summary of Contents for Samsung SPF83H

  • Page 1 1. Click Frame Manager icon in the main page of the CD manual to run the install file. 2. Press "Next" button. 3. Click on "Change" button to Select the path on your PC where you want the software to be stored/installed. Installing USB...
  • Page 2 4. Press "Install" button to proceed. 5. Press "Yes" Button.
  • Page 3 6. Select "Yes, I want to restart my computer now" to boot the system. Click on "Finish" button.

  • Page 4: System Requirements

    Now Switch on the device (Samsung Digital Photo Player) and connect the USB cable (provided in the box with the unit) to the PC. 1. Connect the larger "standard USB" connector to the USB port of the PC. Connect the smaller "mini-USB" connector to the "PC" connector of the Samsung Digital Photo Fame.
  • Page 5 2. Select "No, not this time" button. 3. Click on "Next" button. 4. Click on "Next" button.
  • Page 6 6. Select "Search for the best driver in these locations" option. Check "Include this location in the search:" Now click on "Browse" button to select the directory where the Frame Manger software is installed. (Refer to Frame Manager Installation step 3).
  • Page 7 8. Press "Continue Anyway" button. 9. Press "Finish" button.
  • Page 8 10. Now the system is ready to be used.
  • Page 9 How To Use Digital Photo Frame As Mini-Monitor If USB cable is not connected and Digital Photo Frame is switched on, it starts working as a Photo Album. To use the Samsung Digital Photo Frame device as a secondary USB Monitor, first install the frame Manger on the Windows XP computer.
  • Page 10 Following screen will be shown on Digital Photo Frame. Select Mass-Storage option by clicking the button. Use Left / Right (button 5 and button 6 in above figure) button on device for selection and by pressing ENTER button (button 8 in above figure) on device.

  • Page 11: Brightness Control

    2. From the Menu, Click on menu item Mini-Monitor. 3. Rotate to 90 in Mini-Monitor Mode When the device is in Mini-Monitor mode 0 Degree, select "Rotate to 90°" to rotate the display by 90 degrees. 4. Rotate to 0 in Mini-Monitor Mode When the device is in Mini-Monitor mode 90 Degree, select "Landscape"...

  • Page 12: Update Firmware

    Click on Exit menu item. Update Firmware To update the firmware from PC through USB cable, please ensure the following : SAMSUNG Digital Photo Frame must be connected with PC using USB cable Device Mode must be connected as MINIMO or MASS STORAGE...
  • Page 13 9. During the transfer of file/files, following progress bas will appear. 10. After this please wait for completion of update on device.
