TABLE OF CONTENTS

TRACTOR PREPARTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFE OPERATION PRACTICES . . . . . . . . . . . . . . . . . . . . . 3
CALLING SERVICE INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
FINDING YOUR MODEL & SERIAL NUMBER . . . . . . . . . . . . . . . . . . . . . . 7
SAFETY LABELS FOUND ON YOUR UNIT . . . . . . . . . . . . . . . . . . . . . . . . 8
CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
LUBRICATION ILLUSTRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ENGINE INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
TROUBLE SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
OPTIONAL EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
SLOPE GAUGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
LIMITED WARRANTY - COMMERCIAL USE . . . . . . . . . . . . . . . . . . . . . 39
LIMITED WARRANTY - RESIDENTIAL USE . . . . . . . . . . . . . . . . . . . . . 41
QUICK REFERENCE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
SECTION 1: TRACTOR PREPARATION

Connect the Battery

Battery posts, terminals and
related accessories contain
lead and lead compounds.
Wash hands after handling.
The tractor is shipped with a sealed
battery, with the positive battery cable
factory connected. The negative cable
must be connected.
Note: Make sure the ignition switch is
in the "OFF" position before attaching
the battery cables.
• Open the tractor hood. Remove the
upper bulkhead baffle from the front of
the dash panel by lifting upward on
the baffle locking tab on each side.
• Remove the protective cap from the
negative terminal of the battery.
• Connect the black battery cable to
the negative battery post. Slide
terminal cover over the connection
and reinstall the upper baffle.

Positon the High Back Seat

For shipping purposes the seat is
installed sideways. Reposition the seat
as follows:
• Remove from the seat the two
screws NOT fastening the seat to
the hinge brackets.
• Loosen the RH screw and remove
the LH screw from the seat and
hinge bracket.
• Rotate the rear of the seat to the
right and align the four front seat
holes with matching holes in the LH
and RH hinge brackets.
• Temporarily install the three previ-
ously removed screws into the three
open front seat holes.
• See Section 8: Adjustments for final
seat adjustment procedures.
Rotate
Remove Screw
2
PAGE
Loosen Screw
