Craftsman 917.258271 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
_ MODEL NUMBER 917.258271
/;N L
OWNER'S
MANUAL
• Assembly
• Operation
• Customer
Responsibilities
• Service and Adjustments
° Repair Parts
CAUTION:
Read and follow all safety rules and instructions
before .operating
this equipment.
.
FOR CONSUMER
ASSISTANCE
HOT LINE, CALL THIS TOLL FREE NUMBER:
1-800-659-5917

Advertisement

Table of Contents
loading

Related Manuals for Craftsman 917.258271

Summary of Contents for Craftsman 917.258271

  • Page 1 /;N L _ MODEL NUMBER 917.258271 OWNER'S MANUAL • Assembly • Operation • Customer Responsibilities • Service and Adjustments ° Repair Parts CAUTION: Read and follow all safety rules and instructions before .operating this equipment. FOR CONSUMER ASSISTANCE HOT LINE, CALL THIS TOLL FREE NUMBER: 1-800-659-5917...
  • Page 2 SAFETY RULES Safe Operation Practices for Ride-On Mowers IMPORTANT: THIS CUTTING MACHtNE IS CAPABLE OFAMPUTATING HANDS AND FEET AND THROWING OBJECTS. FA LURE TO OBSERVETHE FOLLOWING SAFETY iNSTRUCTiONS COULD RESULT IN SER OUS NJURY OR DEATH. GENERAL OPERATION ..• Read, understand, and follow air instructionsin the manual Tragic accidents can occur it the operator is not alert to the andQn the machine before starting.

  • Page 3: Product Specifications

    RIDING EQUIPMENT For two (2) years from the date of purchase, if this Craftsman Riding Equipment is maintained, lubricated and tuned up according to the instructions in the owner's manual, Sears will repair or replace, free of charge, any parts found to be defective in rnater[a] or workmanship.
  • Page 4 TABLE OF CONTENTS OPERATION....;....,......11-16 SAFETY RULES ............MAINTENANCE SCHEDULE ........17 PRODUCT SPECIFICATIONS ........3 SERVICE AND ADJUSTMENTS ......21-27 CUSTOMER RESPONSIBILITIES ..... 3, 17-20 WARRANTY .._............3 STORAGE ..............TABLE OF CONTENTS ..........

  • Page 5: Accessories

    lllll I,IIM ACCESSORIE ATTACHMENTS i Hill ..................These accessories and attachments were available throughmostSears retail outletsand servicecenters Whenthe tractorwas purchased: Most Sears stores can order these items for you when you provide the model number of your tractor..ENGINE MAINTENANCE GAS CAN SPARK PLUG...
  • Page 6 OF HARDWARE PACK lllll Parts Bag contents shown full size Parts packed separately in carton ,,,, ,,,, (1) Hex Bolt "_ 3/8-16 ×1 II; I Seat , N- Video Cassette ( ) LaNe Flat Washer (1) Lockwasher 3/8 Steering Whee! Mulcher Plate _il;Hex'Bo/t'5/;6"-18x...
  • Page 7 ASSEMBLY . iii Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness_ TOOLS REQUIRED FOR ASSEMBLY...
  • Page 8 i lll HOW TO SET UP YOUR TRACTOR INSTALL SEAT (See Fig, 3) Adjust seat before tightening adjustment bolt. CONNECT BATTERY (See Fig. 2) • Remove cardboard packing on seat pan. • Place seat on seat pan and assemble shoulder bolt. CAUTION: Do not short battery termi- •...
  • Page 9 ASSEMBLY • Connect anti-sway bar to chassis bracket under left INSTALL MOWER AND DRIVE BELT (See footrest and retain with double loop retainer spring. Figs. 4 and 7) • Install clutch rod in clutch lever. Secure with retainer Be sure tractor is on level surface and mower suspension spring.
  • Page 10 ASSEMBLY INSTALL MULCHER PLATE DEFLECTOR SHIELD (See Figs. 5 and 6) • install two latch hooks to mulcher plate using screw, washer, tock washer, and weld nut as shown. NOTE: Pro-assemble weld nut to latch hook by inserting weld nut from the top with hook pointing down. •...
  • Page 11 illl These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning_ CAUTION OR REVERSE FORWARD FAST SLOW BATTERY WARNING ENGINEOFF ENGINE ON OIL PRESSURE CLUTCH LIGHTS ON LIGHTS OFF PARKING BRAKE UNLOCKED FUEL CHOKE...
  • Page 12 iiiiiiiiiiiiiiiii I,IIIH,,,,I I IIIIIIIIIIIIIIIII IIIIHIII I,I1,111111 IIIIIIII OPERATION KNOW YOUR TRACTOR " READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Comparethe illustrations withyour tractorto familiarizeyourselfwiththe locationsofvariouscontrolsand adjustments. Save thfs:manuat f0r future reference..:_:_ LIGHT IGNITION SWITCH CHOKE AMMETER SWITCH...
  • Page 13 iiiiiii, i ii i OPERATION iiiii IIIIIIIIIIII I I IIIII IIIIIIIIIIII IIIIIIIIIIIIIIIIIIIIIIII IIIIIIIIIIIIIIIIIIIIII iiiiii The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields while operating your tractor or performing any adjustments or repairs.
  • Page 14 nlnlIHIIIIIn,,Hll ii[llllllllllllllll i i IIIlllll,,,,Hnl, II Inll I IH, OPERATION inl, n, ,,i, i i i i i i i,i iiill i. lu,,,,,,,lllnl ,,,,,, ii ill Adjust mower to desired cutting height (See "TO AD- • If stopping is absolutely necessa_, push clutch/brake JUST MOWER CUTTING HEIGHT' in the Operation pedal quickly to brake position and engage parking section of this manual),...
  • Page 15 WARNING: Experience indicates that alcohol blended •: Before driving the unit in cold weather, the transmis- fuels (called gasohol or using ethanol or methanol) can sion should be warmed up as fol!ows: attract moisture which leads to separation and formation of :: Be sure the tractor is on level ground.
  • Page 16 MULCHING MOWING TIPS MOWING TIPS IMPORTANT: FOR BEST PERFORMANCE, KEEP • Tire chains cannot be used when the mower housing is MOWER HOUSING FREE OF BUILT-UP GRASS AND attached to tractor. TRASHI CLEAN AFTER EACH USE. • Mower should be properly teveled for best mowing •...
  • Page 17 CUSTOMER NSIBILITIES = AS YOU COMPLETE /__/_//_7 Check Brake Operation • Check Tire Pressure • v' Check for Loose Fasteners i I_ _ tk#*_ Sharpen/Rep lace Mbwer Blades Lubrication Chart : Check Battery Level/Recharge " Clean Battery and Terminals Check Transaxle Cooling Adjust Blade Belt(S ) Tension li##s Adjust Motion Drive Be s...
  • Page 18 ILITIES TRACTOR TO SHARPEN BLADE (See Fig. Care should be,taken to keep the blade balanced, An Always observe safety ru es when performing any mainte- unbalanced blade will cause excessive vibration and even- nance. tual damage to mower and engine. BRAKE OPERATION •...
  • Page 19 CUSTOMER NSIBILITIES V-BELTS After oil has drained corn pletely, replace oil drain plug and tighten securely. Check V-belts for deterioration and wear after 100 hours of Refill engine with oil through oil fill dipstick tube. Pour operation and replace if necessary. The belts are not slowly.
  • Page 20 u i ¸ ii i Lh ,,,, iiiniiii I lllll,llllll, Illlll CUSTOMER I IIIIIIIIIIIII I1111111 IIIII IMPORTANT: PETROLEUM SOLVENTS, SUCH AS MUFFLER KEROSENE, ARE NOT TO BE USED TO CLEAN THE Inspect and replace corroded muffler arid spark arrester (if CARTRIDGE.
  • Page 21 SERVICE AND ADJUSTMENTS llili= i ii CAUTION: BEFORE PERFORMING ANY SERVICE OR ADJUSTMENTS: Place motion control lever in neutral (N) position. Depress clutcWbrake pedal fully and set parking brake, Place attachment clutch in "DISENGAGED" position. Turn ignition key "OFF" and remove key. Make sure the blades and all moving parts have completely stopped.
  • Page 22 AND ADJUSTMENTS TO LEVEL MOWER HOUSING FRONT-TO-BACK ADJUSTMENT (See Figs. 23 and 24) IMPORTANT: DECK MUST BE LEVEL SIDE-TO-SIDE. IF Adjust the mower while tractor is parked on level ground or THE FOLLOWING FRONT-TO-BACK ADJUSTMENT IS driveway. Make sure tires are properly inflated (See NECESSARY.
  • Page 23 SERVICE AND ADJUSTMENTS TO REPLACE MOWER DRIVE BELT TO REPLACE MOWER BLADE DRIVE BELT (See Fig. 26) MOWER DRIVE BELT REMOVAL (See Fig. 25) - Park tractor on a level surface. Engage parking brake. Park the tractor on tevel surface. Engage parking brake. Disengage attachment clutch control.

  • Page 24: Adjustments Brake

    :AND ADJUSTMENTS TO REPLACE MOTION DRIVE BELT TO ADJUST BRAKE (See Fig, 27) (See Fig. 28) Your tractor is equipped with an adjustable brake system which is mounted on the side of the transaxle. Park the tractoron levelsurface. Engage parking brake. For assistance, there is a belt installation guide decal on If tractor requires more than six (6) feet stopping distance bottom side of left footrest.
  • Page 25 SERVICE AND ADJUSTMENT TO ADJUST MOTION CONTROL LEVER TO ADJUST STEERING WHEEL ALIGNMENT (See Fig. 29) If steering wheel crossbars are not horizontal (left to right) when wheels are positioned straight forward, remove steer- The motion control lever has been preset at the factory and ing wheel and reassemble per instructions in the Assembly adjustment should not be necessary.
  • Page 26 SERVICE ANDADJUSTMENTS TO START ENGINE WITH A WEAK BATTERY TO REPLACE FUSE Replace with 30 amp automotive-type plug-in fuse. (See Fig. 32) fuse holder is located behind the dash. TO REMOVE HOOD AND GRILL ASSEMBLY (See Fig. 33) teries, Always wear eye protection and smoking materials away from bat- •...

  • Page 27: Carburetor

    SERVICE AND ADJUSTMENTS • With throttlecontrollever in slow position,hold throttle TO ADJUST CHOKE CONTROL (See Fig. 35) lever against idle speed screw and adjust idle speed The choke control has been preset at the factory and screw to obtain 1200 to 1400 RPM. adjustmentshould not be necessary.

  • Page 28: Cleaning

    STORAGE Immediately prepare your tractor for storage at the end of ENGINE the season or if the tractor will not be used for 30 days or more. FUEL SYSTEM IMPORTANT: ]T IS IMPORTANT TO PREVENT GUM CAUTION: Neverstore the tractor with DEPOSITS FROM FORMING IN ESSENTIAL...
  • Page 29 ,i i i i, TROU POINTS CAUSE PROBLEM CORRECTION Will not start Out of fuel. Fill fuel tank, Engine not "CHOKED" pmpedy. See =TO START ENGINE" in Operation section. Engine flooded. Wait several minutes before attempting to start. ,. Bad spark plug. Replace spark plug.
  • Page 30 TROUB G POINTS PROBLEM CORRECTION Engine continues to run Faulty operator-safety presence control system. Check wiring, switches and connections. If not when operator leaves seat corrected, contact an authorized service center/ with attachment:clutch department. engaged " Poor cut-uneven Worn, bent or loose blade. Replace blade, T_ghten blade bolt.
  • Page 31 TRACTOR - - MODEL NUMBER 917.258271 SCHEMATIC BATTERY STARTER SLACK CLUTCH t BRAKE (PEDAL UP) WHITE SEAT SWITCH (NOT OCCUPIED) SWITCH ..IGNITION sLAcK NT CLUT GROUNDING CONNECTOR HOUR }_ (_LUTCH OFF)_rl METER (OPTIONAL) BLACK IGNITION _ SPARK PLUG UNIT (2 PLUGS ON TWIN CYL.
  • Page 32 REPAIR PARTS TRACTOR - - MODEL NUMBER 917,258271 ELECTRICAL...
  • Page 33 145491 121305X Switch, Seat 140301 Switch, Ignition 4 Position Nut, Ignition 124211X Cover, Ignition Switch 141226 109310X Key, Molded, Craftsman 156442 Harness, Ignition Bolt Blk Fin Hex 1/4-20 UNC x 1/2 71110408 131563 Cover, Terminal Solenoid 145673 73640400 Nut Keps BIk Hex 1/4-20 UNC...
  • Page 34 REPAIR PARTS TRACTOR - - MODEL NUMBER 917.258271 CHASSIS AND ENCLOSURES 3 3/...
  • Page 35 REPAIR PARTS TRACTOR -- MODEL NUMBER 917.258271 CHASSIS AND ENCLOSURES PART DESCRIPTION Chassis 159527 Drawbar 140356 17490612 Screw, Thd., Roll. 3/8-16 x 3/4 Type STD551025 Washer 13/32 x 3/4 x 16 Gauge 155272 Bumper Hood/Dash 150156X011 Dash, Silkscreened STD533710 Bolt, Carriage 3/8-16 x 1 155927 Panel, Dash, LH 145660...
  • Page 36 REPAIR PARTS : ..: TRACTOR ..MODEL NUMBER 917;258271 DRIVE --.._:--..-18 "- )/48 "118 _._.----- 100 92------ ©...
  • Page 37 PARTS REPAIR TRACTOR." MODEL NUMBER 917,258271 DRIVE PART PART DESCRIPTION DESCRIPTION 140186 Pulley, Engine 150071 Transaxle (See Breakdown) 71170764 Bolt Hex 7/16-20 x 4 Gr. 5 Hydro Gr Model No. 310-0650 STD551143 Washer 142431 Spring, Return, Brake 154778 Keeper Belt Engine Full-Proof 143995 Pulley, Transaxle Rod Shift Fender STLT...
  • Page 38 REPAIR PARTS TRACTOR - - MODEL NUMBER 917.258271 STEERING ASSEMBLY f_ t _1 ,_-'---42 :.._-----'17 •...
  • Page 39 REPAIR PARTS TRACTOR - - MODEL NUMBER 917,25827:1 STEERING ASSEMBLY PART DESCRIPTION 139768 Wheel Steering Std Black AxteAsm Front 154427 156483 Spindle Asm Lh 157473 Spindle Asm Rh 6266H Beadng Race Thrust Harden 121748X Washer 25/32 X 1 5/8 X 16ga Washer 27/32 X 1 1/4 X 16 Ga 19272016 12000029...
  • Page 40 REPAIR PARTS TRACTOR - - MODELNUMBER 917.258271 ENGINE 41 33 OPTIONAL EQUIPMENT Spark Arrester...
  • Page 41 REPAIR PARTS TRACTOR- - MODEL NUMBER917.258271 ENGINE PART DESCRIPTION 151273 Control Throt Paddle 32 22 17720410 Screw Hex Thd Cut 1/4-20x5/8 T Engine (See Breakdown) Briggs Model No. 42E707-1831-A1 Muffler Exhaust 149723 Exhaust Asm. Left 144069 144068 Exhaust Asm, Right Clamp Tube Double Engine 138129 BoUt 5 /16 - 18 UNC X 3/4 W/Sems...
  • Page 42 REPAIR PARTS TRACTOR- -MODEL NUMBER 917.258271 MOWER LIFT 2524 161718 13---mV...
  • Page 43 REPAIR PARTS TRACTOR - - MODEL NUMBER 917,258271 MOWER LIFT PART DESCRIPTION 159460 Wire Asm,, Inner/Sprg, w/Plngr LT Shaft Asm. Lift 159471 Pin Groove 105767X 12000002 E Ring _5133-62 Washer 21/32 x I x 21 Ga. 19211621 120183X Bearing Nylon 125631X Gdp Handle Fluted 122365X...
  • Page 44 REPAIR PARTS TRACTOR - - MODEL NUMBER 917.258271 MOWER DECK "I9 103102 ,oo_] _.F_102...
  • Page 45 REPAIR PARTS TRACTOR - -MODEL NUMBER 917.258271 MOWER DECK PART PART DESCRIPTION DESCRIPTION Deck Asm., Mower 46" 156948 156493 Pulley Idler 138457 Bracket Asm., Sway Bar Washer 13/32 x 13/I6 x 12 Ga. 19131312 4939M Retainer Spring Bolt Fin Hex 3/8-16unc x I Gr, 5 74780616 130832 Arm, Suspension, Rear (Sway Bar)
  • Page 46 REPAIR PARTS TRACTOR - - MODEL NUMBER 917.258271 SEAT ASSEMBLY //lO _\\'5 PART PART DESCRIPTION DESCRIPTION Seat 140123 121248X _Bushing snap BIk Nyl 50 Id Bolt Rdhd ShtNk 1/4-20xl-3/8 140551 Bracket Pnt Pi,2otSeat (blk) 72050411 Bolt Fin Hex 3/8-16 UNC x 1 74760616 1343OO Spacer Split 28 X 96 Zinc...
  • Page 47 DESCRIPTION 156439 158215 Decal, Insert, Hood Decal Fender Danger Sears 156810 Decal Fend Auto Sears Gold 138047 Decal, Battery Diehard Sears Decal Hood Rh Craftsman 156787 151299 Decal Deck Mower EZ3 Mulching 149516 273503 Decal Hp Engine Decal Battery 138311...
  • Page 48 REPAIR PARTS TRACTOR-- MODEL NUMBER 917,258271 HYDRO GEAR TRANSAXLE -MODEL NUMBER 310-0650...
  • Page 49 REPAIR PARTS TRACTOR - - MODELNUMBER 917.258271 HYDRO GEAR TRANSAXLE - MODEL NUMBER 310-0650 KEY PART KEY PART NO. NO. DESCRIPTION DESCRIPTION 142884 Washer 7/16 x 7/8 x .060 142930 Housing, Lower I42931 Assembly, Upper Housing 150829 Differentia[ Assembly 142991 Washer 3/4 x 1.5 x .13 142932 Seal, Lip...
  • Page 50 REPAIR PARTS TRACTOR , MODEL NUMBER 917=.258271 BRIGGS & STRATTON ENGINE - MODEL NUMBER 42E707, TYPE NUMBER 183i-A1 615 q_ 868 _ _ 40 42@_p _ 3341 127 _ Y4_22_ 284_, 284A ¸,...
  • Page 51 REPAIR PARTS TRACTOR- -MODEL NUMBER 917.258271 BRIGGS & STRATTON ENGINE , MODEL NUMBER 42E707, TYPE NUMBER 1831-A1 i 358 GASKET SET ! 1861 PUMP REPAIR KITI" _i• ! 121 CARBURETOR _119 195s1'1 __356 ¸ ' .....
  • Page 52 REPAIR PARTS TRACTOR-- MODEL NUMBER 917.258271 BRIGGS & STRATTON ENGINE - MODEL NUMBER 42E707, TYPE NUMBER 1831-A1 209A 414 207y...
  • Page 53 REPAIR PARTS TRACTOR MODEL NUMBER 917,258271 BRIGGS & STRATTON ENGINE - MODEL NUMBER 42E707, TYPE NUMBER 1831-A1 ]1058 OWNER'S MANUALJ [ 1019 LABEL KIT] REQUIRES SPECIAL TOOLS TO INSTALL. SEE REPAIR INSTRUCTION MANUAL. 308A...
  • Page 54 REPAIR PARTS TRACTOR-- MODEL NUMBER 917.258271 BRIGGS & STRATTON ENGINE - MODEL NUMBER 42E707, TYPE NUMBER 1831-A1 KEY PART KEY PART NO, NO. DESCRIPTION NO. NO. DESCRIPTION 93208 Screw, Phillips 497074 Cylinder Assembly 222511 Washer, Spring 399265 Bushing 95039 Screw, Hex 391086 * Seat, Oil Carburetor...
  • Page 55 REPAIR PARTS • TRACTOR ,L MODEL NUMBER 917,258271 BRIGGS & STRATTON ENGINE - MODELNUMBER 42E707, _PE NUMBER 1831-A1 • KEY PART KEY PART NO. NO, DESCRIPTION NO. NO. DESCRIPTION Screw, Hex Head 93585 Lever Assembly, Governor 491297 Bolt, Governor Lever 93853 Washer 62199...
  • Page 56 SERVICE NOTES...
  • Page 57 ,,,,,,,,,,,,,,,,...
  • Page 58 IHIIIIIII "...
  • Page 59 SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION ONLY RIDE UP AND DOWN HILL, NOT ACROSS HILL SIGHTING " SIGHT AND HOLD THIS LEVEL WITH SKY LINE OR TREE. 15 ° MAX. Operate your Tractor up and down the face of slopes (not _! "J_ greater than 15°), never across the face.

  • Page 60: Replacement

    [RaFTSMRN® OWNER'S 19.5 HP MANUAL ELECTRIC START 46" MOWER AUTOMATIC(HYDROSTATIC) LAWN TRACTOR MODEL NO. Each tractor has its own model number. Each engine has its own model number. 917.258271 The model number for your tractor will be found on the model plate located under the seat.
