8. API for Controlling External Devices Connected to VN-E4 _
of External Devices via Pass-through
8.2. Control of External Devices via Pass-through
By using the pass-through feature, data sent to VN-E4 via the network will be output from the serial port of VN-E4. In addition, Ack received
by the serial port of VN-E4 will be returned to the client via the network.
Reserve the pass-through feature via API, connect the TCP for transmission of pass-through data (49152 for serial port 1 and 49153 for serial
port 2), followed by sending the data.
(1) Reservation of Pass-through Feature via API
API Character String
Example
from.ip
from.protocol
to.serial(Number)
from.ip_translate
Example of Response
Interpretation
Example of Error
Response
Allowed users
/api/receive?from=network&from.ip=Data1&from.protocol=Data2&to=serial(Number)
/api/receive?from=network&from.ip=10.0.0.100&from.protocol=tcp_passive&
from.ip_translate=on&to=serial(2)
Specify the IP address of the client.
Specify as tcp_passive. This indicates establishment of TCP connection to TCP49152 from the client.
Specify the serial port used in Number. Specify as 1 or 2.
When from.ip_translate is set to off, VN-E4 will standby to receive the pass-through data from the IP address
specified at from.ip. When from.ip_translate is set to on, VN-E4 will ignore from.ip and standby to receive the
pass-through data from the source IP address of this API.
HTTP/1.1 200 OK<CRLF>
Connection: Keep-Alive<CRLF>
Content-Length: 104<CRLF>
content-type: text/plain<CRLF>
date: Fri, 13 MAY 2005 07:33:12 GMT<CRLF>
server: VN-E4 API Server/1.0.0<CRLF>
keep-alive: timeout=5, max=5<CRLF>
x-vne4_response:
from=network&from.ip=10.0.0.100&from.protocol=tcp_passive&from.session=ra
w&from.ip_translate=on&to.serial(2)&to.baud=9600&to.bit=8&to.stopbit=1&to
.parity=none<CRLF><CRLF>
200 OK<CRLF>
Reserve the pass-through feature of VN-E4 . The following error will be returned when the specified serial
port in currently being used by another client.
HTTP/1.1 200 OK<CRLF>
Connection: Keep-Alive<CRLF>
Content-Length: 104<CRLF>
content-type: text/plain<CRLF>
date: Fri, 13 MAY 2005 07:33:12 GMT<CRLF>
server: VN-E4 API Server/1.0.0<CRLF>
keep-alive: timeout=5, max=5<CRLF>
x-vne4_response:
from=network&from.ip=10.0.0.100&from.protocol=tcp_passive&from.session=ra
w&from.ip_translate=on&to.serial(2)&to.baud=9600&to.bit=8&to.stopbit=1(to
.parity=none<CRLF><CRLF>
403 Forbidden<CRLF>
admin, operator
Reservation of serial port 1 will be disabled when Service at the rear panel of VN-E4 is selected. When an API
is sent in this case, an error will be returned.
8.2. Control
73
