Trademarks
®
Autel
,
MaxiSys
®
MaxiCheck
are trademarks of Autel Intelligent Technology Corp., Ltd., registered in
China, the United States, and other countries. All other marks are trademarks or
registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or transmitted in
any form or by any means electronic, mechanical, photocopying, recording, or
otherwise without the prior written permission of Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on the latest
information available at the time of printing.
Autel reserves the right to make changes at any time without notice. While information
of this manual has been carefully checked for accuracy, no guarantee is given for the
completeness and correctness of the contents, including but not limited to the product
specifications, functions, and illustrations.
Autel will not be liable for any direct, special, incidental, or indirect damages, or for any
economic consequential damages (including the loss of profits) as a result of using this
product.
IMPORTANT
Before operating or maintaining this unit, please read this manual carefully, paying
extra attention to the safety warnings and precautions.
For Services and Support
pro.autel.com
www.autel.com
1-855-288-3587 (North America)
+86 (0755) 8614-7779 (China)
support@autel.com
For technical assistance in all other markets, please refer to
manual.
®
®
,
MaxiDAS
,
®
MaxiCOM
,
MaxiRecorder
i
®
®
,
MaxiCOM
Technical Support
,
and
in this

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MaxiCOM MK900-BT and is the answer not in the manual?

Questions and answers

Cheta Alexandru
March 26, 2025

einstellung sprache

0
3 comments:
Mr. Anderson
March 26, 2025

To change the language setting on the Autel MaxiCOM MK900-BT:

1. Tap the Settings application on the MaxiCOM Job Menu.
2. Tap the Language option in the left column.
3. Select the desired language. A check mark will appear next to the selected language.
4. Tap the Home button in the top-left corner to return to the MaxiCOM Job Menu or select another setting to adjust.

This answer is automatically generated

0
Cheta Alexandru
March 28, 2025

@Mr. Anderson

0
Cheta Alexandru
March 28, 2025

@Mr. Anderson Vielen Dank,Ich habe die Schritte befolgt, kann aber die rumanische Sprache **** verwenden,da der Hersteller sie aktivieren muss.Der Code ist WQ8-DS900BT2232

0

Related Manuals for Autel MaxiCOM MK900-BT

Summary of Contents for Autel MaxiCOM MK900-BT

  • Page 1 Autel will not be liable for any direct, special, incidental, or indirect damages, or for any economic consequential damages (including the loss of profits) as a result of using this product.
  • Page 2 The safety messages herein cover situations Autel is aware of at the time of publication. Autel cannot know, evaluate or advise you as to all of the possible hazards. You must be certain that any condition or service procedure encountered does not jeopardize...
  • Page 3 DANGER When an engine is operating, keep the service area WELL VENTILATED or attach a building exhaust removal system to the engine exhaust system. Engines produce carbon monoxide, an odorless, poisonous gas that causes slower reaction time and can lead to serious personal injury or loss of life. SAFETY WARNINGS ...

  • Page 4: Table Of Contents

    CONTENTS 1 USING THIS MANUAL ..................... 1 ..................... 1 ONVENTIONS 1.1.1 Bold Text ...................... 1 1.1.2 Notes and Important Messages ..............1 1.1.3 Hyperlinks ..................... 1 1.1.4 Illustrations ....................2 1.1.5 Procedures ....................2 2 GENERAL INTRODUCTION .................... 3 COM MK900-BT T ................
  • Page 5 ..................20 EHICLE DENTIFICATION 4.3.1 Auto Detect ....................20 4.3.2 Manual Input ....................22 4.3.3 Scan VIN/License ..................23 4.3.4 Automatic Selection ..................25 4.3.5 Manual Selection ..................26 ....................... 26 AVIGATION 4.4.1 Diagnostic Screen Layout ................26 4.4.2 Screen Messages ..................29 4.4.3 Making Selections ..................
  • Page 6 (DPF) S ............56 IESEL ARTICLE ILTER ERVICE (IMMO) S ................57 MMOBILIZER ERVICE 6 DATA MANAGER ......................59 ....................60 EHICLE ISTORY 6.1.1 Historical Test Record ................61 ................... 62 ORKSHOP NFORMATION ......................63 USTOMER ....................... 64 MAGE ....................65 LOUD EPORT PDF F...
  • Page 7 12.6 FAQ ......................... 94 13 OEM AUTHORIZATION ....................95 14 REMOTE DESKTOP ..................... 96 15 MAXIVIDEO ........................98 16 QUICK LINK ......................... 99 17 AUTEL USER CENTER ....................100 18 MAINTENANCE AND SERVICE................. 102 18.1 ................102 AINTENANCE NSTRUCTIONS 18.2 .................
  • Page 8 18.3 ................... 103 BOUT ATTERY SAGE 18.4 ..................104 ERVICE ROCEDURES 18.4.1 Technical Support ..................104 18.4.2 Repair Service ..................106 18.4.3 Other Services ..................106 19 COMPLIANCE INFORMATION .................. 107 20 WARRANTY ....................... 110 viii...

  • Page 9: Using This Manual

    Using This Manual This manual contains device usage instructions. Some illustrations shown in this manual may make reference to modules and optional equipment that are not included in your system. Contact your sales representative for availability of other modules and optional tools or accessories. 1.1 Conventions The following conventions are used: 1.1.1 Bold Text...

  • Page 10: Illustrations

    1.1.4 Illustrations Illustrations used in this manual are samples; the actual testing screen may vary for each vehicle being tested. Observe the menu titles and on-screen instructions to make correct option selection. 1.1.5 Procedures An arrow icon indicates a procedure. Example: ...

  • Page 11: General Introduction

    DTCs for all available modules of the majority of the makes and models on the market, the MaxiCOM MK900-BT is your ideal auto diagnostics and service tool, providing you with superior functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), BMS (Battery Management System), and DPF (Diesel Particulate Filter).
  • Page 12 8.0” LCD Touchscreen Ambient Light Sensor — detects ambient brightness. Power LED — indicates battery level & charging or system status. The power LED displays green, yellow or red depending on power level and operating state. A. Green  Illuminates green when the tablet is charging and the battery level is above 90%.

  • Page 13: Power Sources

    Rear Camera Camera Flash Figure 2-3 Tablet Top View USB Type-C Charging Port Mini SD Card Slot USB Port 10. Power/Lock Button — turns the device on/off with long press, or locks the screen with short press. 2.1.2 Power Sources The tablet can receive power from any of the following sources: ...
  • Page 14 Item Description Memory 4 GB RAM & 64 GB ROM Display 8-inch LCD screen with 1280 x 800 resolution Rear Camera 8 MP  Type-C USB  USB 2.0 Connectivity  Wi-Fi  Bluetooth  Mini SD card (supports up to 64 GB) Sensor Ambient light sensor for brightness auto changing ...

  • Page 15: Maxivci V150

    Item Description Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6, DoIP, CAN FD 2.2 MaxiVCI V150 MaxiVCI V150 is a small vehicle communication interface (VCI) that connects to the tablet and vehicle’s data link connector (DLC) for vehicle data transmission. 2.2.1 Function Description Figure 2-4 MaxiVCI V150 Views Vehicle Data Connector (16-Pin) —...

  • Page 16: Power Source

    Color Description Flashes solid blue when the device is successfully Flashing connected via Bluetooth and is communicating with the Blue vehicle. Red and Lights solid red and blue (Connected via Bluetooth) or solid red and green (not connected) when there is Blue/Red something abnormal.

  • Page 17: Other Accessories

    2.3 Other Accessories USB Type-C Cable (for charging) External Power Adapter Together with the USB Type-C cable, connects the tablet to the external DC power port for power supply.

  • Page 18: Getting Started

    Getting Started Ensure the tablet is sufficiently charged or is connected to an external power supply (see Power Sources on page 5). NOTE The images and illustrations depicted in this manual may differ slightly from those in the most recent product. 3.1 Powering Up Long press the Power/Lock button on the top-right side of the tablet to power on the unit.

  • Page 19: Application Buttons

    NOTE The tablet screen is locked by default when first powered on. We recommend you lock the screen to protect the information in the system and conserve the power. The touchscreen navigation is menu-driven, enabling quick access to functions and features by tapping on the buttons on the screen.
  • Page 20 MaxiViewer vehicles of Autel diagnostic tools. See MaxiViewer page 91 for details. Launches the Support platform which synchronizes Autel’s on-line service base station with the MaxiCOM Support tablet. See Support on page 92 for details. Unlocks the gateway ECU (CGW) for some vehicles to...

  • Page 21: Locator And Navigation Buttons

    3.1.2 Locator and Navigation Buttons Operations of the navigation buttons at the bottom of the screen are described in the table below: Table 3-2 Locator and Navigation Buttons Button Name Description Indicates which screen you are on. Swipe the screen left or Locator right to view the previous or next screen.

  • Page 22: System Status Icons

    Button Name Description Diagnostics Returns to the Diagnostics screen. Shortcut Service Returns to the Service screen. Shortcut  To use the camera Tap the Camera icon. The camera screen displays. Focus the image to be captured in the viewfinder. Tap the Camera icon on the right side of the screen. The viewfinder now shows the captured picture and auto-saves the taken photo.

  • Page 23: Reboot System

    3.2.1 Reboot System In case of a system crash, long press the Power/Lock button and tap the Restart option to restart the system.

  • Page 24: Diagnostics

    Diagnostics The Diagnostics application can retrieve ECU information, read & erase DTCs, and view live data. The Diagnostics application can access the electronic control unit (ECU) for various vehicle control systems, including engine, transmission, antilock brake system (ABS), and airbag system (SRS). 4.1 Establishing Vehicle Communication Prior to performing the Diagnostics function, ensure the tablet is connected to the test vehicle through the MaxiVCI V150.

  • Page 25: No Communication Message

    time and providing higher efficiency. The working range for Bluetooth communication is about 33 feet (about 10 m), enabling remote vehicle diagnostics. Refer to VCI Bluetooth Pairing on page 77 for details. 4.1.3 No Communication Message A. If the tablet is not connected to the MaxiVCI V150 correctly, an “Error” message may display.

  • Page 26: Getting Started

    4.2 Getting Started Ensure a communication link is established between the test vehicle and the tablet via the MaxiVCI V150. 4.2.1 Vehicle Menu Layout When the tablet is properly connected to the vehicle, the platform is ready to start vehicle diagnosis. Tap the Diagnostics application button on the MaxiCOM Job Menu to access the Vehicle Menu.
  • Page 27 Table 4-1 Top Toolbar Buttons Button Name Description Home Returns to the MaxiCOM Job Menu. Provides a fast way to identify the test vehicle. Vehicle Identification on page 20 for details. Displays all the vehicle manufacturers. Adds your preferred vehicle manufacturers into Favorites favorites.

  • Page 28: Vehicle Identification

    4.3 Vehicle Identification The MaxiCOM diagnostics system supports five methods for vehicle identification: Auto Detect Manual Input Scan VIN/License Automatic Selection Manual Selection 4.3.1 Auto Detect The MaxiCOM diagnostics system features the latest VIN-based Auto Detect function to identify vehicles and scan all the diagnosable ECUs and run diagnostics on the selected system.
  • Page 29 Figure 4-3 Auto Detect Screen Tap Yes to confirm the vehicle profile, or tap No if the information is incorrect. Figure 4-4 Vehicle Profile Screen The tool establishes communication with the vehicle and reads the control unit information. Choose Auto Scan to scan all the test vehicles’ available systems or tap Control Unit to access a specific system to diagnose.

  • Page 30: Manual Input

    Figure 4-5 Diagnostic Menu Screen 4.3.2 Manual Input For vehicles not supporting the Auto Detect function, you may manually enter the VIN.  To perform Manual Input Tap the Diagnostics application button from the MaxiCOM Job Menu. The Vehicle Menu displays. Tap the VID button on the top toolbar to open the dropdown list.

  • Page 31: Scan Vin/License

    Figure 4-6 Manual Input Screen Tap OK. Once the vehicle is identified, the Vehicle Diagnostics screen displays. at the top-right of the dialog box to exit Manual Input. 4.3.3 Scan VIN/License MaxiCOM diagnostic tablet also supports Scan VIN/License function. Enabling this function will automatically turn on the camera.
  • Page 32 Figure 4-7 Scan VIN/License 1 Select one of the three options and position the tablet to align the VIN, or license number, or the barcode within the scanning window. The scan result will display in the dialog box of the Recognition Result screen. Tap OK to confirm the result, and then the vehicle information confirmation screen will display on the tablet.

  • Page 33: Automatic Selection

    Figure 4-9 Enter VIN Screen 4.3.4 Automatic Selection The vehicle VIN can also be automatically acquired after a vehicle manufacturer is selected. Figure 4-10 Selection Screen  To perform Automatic Selection Tap the Diagnostics application button from the MaxiCOM Job Menu. The Vehicle Menu displays.

  • Page 34: Manual Selection

    Tap Automatic Selection and the VIN information will be acquired automatically. Follow the on-screen instructions to complete the operation and advance to the Diagnostic Menu screen. 4.3.5 Manual Selection When the VIN is not automatically retrievable through the vehicle's ECU, or when the VIN is unknown, you can select the vehicle manually.
  • Page 35 59 for details. Records the communication data and information of the test vehicle. When encountering Data an error during testing and diagnosing, use this Logging function to contact Autel's technical staff for solutions. See Data Logging on page 93 for details.
  • Page 36  To print data in Diagnostics Tap the Diagnostics application button from the MaxiCOM Job Menu. The Print button on the Diagnostic Toolbar is available throughout the whole Diagnostics operations. Tap Print. A drop-down menu will be displayed: Print This Page — prints a screenshot of the current screen. ...

  • Page 37: Screen Messages

    4.4.2 Screen Messages Screen messages will appear when additional input is needed before proceeding. There are three main types of on-screen messages: Confirmation, Warning, and Error. 4.4.2.1 Confirmation Messages Confirmation messages inform you when you are about to perform an action that cannot be reversed or when an action has been initiated and confirmation is needed to continue.

  • Page 38: Auto Scan

    4.5.1 Auto Scan The Auto Scan function performs a comprehensive scanning over all the ECUs in the vehicle to locate systems faults and retrieve DTCs. An example of Auto Scan interface is pictured as below: Figure 4-12 Auto Scan Screen Navigation Bar Main Section Function Buttons...

  • Page 39: Control Unit

    to access this system. Column 4 — tap to enter the related system to view the detailed information and perform further diagnosis or testing. 4.5.1.3 Function Buttons The table below provides a brief description of the Function Buttons: Table 4-3 Function Buttons in Auto Scan Name Description Report...

  • Page 40: Diagnostic Functions

    4.6 Diagnostic Functions Figure 4-13 Function Menu Screen The Diagnostic Functions are listed on the Function Menu screen. The Function Menu options vary slightly for different vehicles, which may include: ECU Information — provides the retrieved ECU information in detail. An ...

  • Page 41: Ecu Information

    4.6.1 ECU Information This function retrieves and displays the specific information for the tested control unit, including unit type, version numbers, and other specifications. Figure 4-14 ECU Information Screen Diagnostics Toolbar Buttons — see Table 4-2 Diagnostics Toolbar Buttons on page 27 for detailed descriptions of the operations for each button.
  • Page 42 Figure 4-15 Trouble Codes Screen Diagnostics Toolbar Buttons — see Table 4-2 Diagnostics Toolbar Buttons on page 27 for detailed descriptions of the operations for each button. Main Section Column 1 — displays the retrieved codes from the vehicle.  Column 2 —...

  • Page 43: Live Data

     To erase codes Tap Erase Codes from the Trouble Codes screen. A warning message displays to inform you of data clearing when this function is applied.  Tap Yes to continue. A Confirmation screen displays when the operation is successfully done. ...
  • Page 44 Main Section Name Column — displays the parameter names.  Check Box — tap the check box on the left side of the parameter name to make item selection. Tap the check box again to deselect the item. Drop-down Button — tap the drop-down button on the right side of the parameter name to open a sub menu, providing data display mode options.
  • Page 45 NOTE Status parameters, such as a switch reading like ON, OFF, ACTIVE, and ABORT, can only be displayed in Text Mode. Value parameters, such as a sensor reading, can be displayed in both text and graph modes.  Waveform Graph Mode — displays the parameters in waveform graphs. In this mode, five control buttons will display on the right side of the parameter item, allowing you to manipulate the display status.
  • Page 46 three scales available for the Y axis: x1, x2, and x4. Edit Button — tap to open an edit window, in which you can set the waveform  color and line thickness displayed for the selected parameter. Zoom-out Button — tap to exit full screen display. ...
  • Page 47 Figure 4-20 Trigger Settings Screen Two buttons and two input boxes are available in the Trigger Settings screen. Trigger — switches the trigger on or off. The trigger is ON by default. Buzzer Alarm — switches the alarm on or off. The alarm function makes a beeping sound as an alert when the data reading reaches the preset minimum or maximum point.
  • Page 48 C. Function Buttons The operations of the available Function Buttons on the Live Data screen are described below: Cancel All — tap this button to cancel all selected parameters. Up to 50 parameters can be selected at one time. Show Selected/Show All — tap this button to switch between the two options: one displays the selected parameters, the other displays all the available items.
  • Page 49 and save the setting, and return to the Live Data screen, or tap Cancel to exit without saving. Clear Data — tap this button to clear all cached live data. Freeze — displays the retrieved data in freeze mode. Previous Frame — moves to the previous frame of frozen data. ...

  • Page 50: Active Test

    4.6.4 Active Test The Active Test function is used to access vehicle-specific subsystem and component tests. Available tests vary by vehicle. During an active test, the tablet sends commands to the ECU to activate the actuators. This test determines the integrity of the system or part by reading ECU data, or by monitoring the operation of the actuators.
  • Page 51 Figure 4-22 Special Function Screen 1 Select a function to display detailed information and the execution screen. Figure 4-23 Special Function Screen 2 List Tab Page: Column 1 — displays the description of the function being performed or the live ...

  • Page 52: Generic Obdii Operations

    4.7 Generic OBDII Operations This option presents a quick way to check for DTCs, isolate the cause of an illuminated malfunction indicator lamp (MIL), check monitor status prior to emissions certification testing, verify repairs, and perform a number of other services that are emissions-related.

  • Page 53: Function Descriptions

    Figure 4-24 OBDII Diagnostic Menu Select a function to continue.  DTC & FFD  I/M Readiness  Live Data  Sensor Monitor  On-Board Monitor  Component Test  Vehicle Information  Vehicle Status NOTE The supported functions may vary by vehicles. 4.7.2 Function Descriptions This section describes the various functions of each diagnostic option: 4.7.2.1...
  • Page 54 Figure 4-25 DTC & FFD Screen  Current Codes Current codes are the current emissions-related DTCs from the ECU of the vehicle. OBDII/EOBD codes have a priority according to their emission severity, with higher priority codes overwriting lower priority codes. The priority of the code determines the illumination of the MIL and the codes erase procedure.
  • Page 55  Erase Codes This option is used to clear all emissions-related diagnostics data including DTCs, freeze frame data, and specific manufacturer-enhanced data from the vehicle ECU. This option resets the I/M Readiness Monitor Status for all vehicle monitors to “Not Ready”...

  • Page 56: Diagnostic Reports

    4.7.2.6 Component Test This function enables dual-directional control of the ECM so that the diagnostic tool is able to transmit control commands to operate the vehicle systems. This function is useful in determining how well the ECU responds to a command. 4.7.2.7 Vehicle Information The option displays the vehicle identification number (VIN), the calibration identification,...

  • Page 57: Diagnostics Report Saving, Viewing, And Sharing

    NOTE The post-scan function can be performed repeatedly. After exiting the vehicle, you only need to tap the vehicle button from the Vehicle Menu screen to reconnect again, then enter the same maintenance order number in the pop-up box and follow the steps to rescan.
  • Page 58 Figure 4-27 Historical Test Screen Tap Get Report. Enter the license plate and current mileage. Tap Save.  Via the functions on the Diagnostics Toolbar The diagnostic report can also be viewed from such diagnostics functions screen including Auto scan, Trouble codes, Live data, and Active test. There are two ways to view the saved reports: ...
  • Page 59 Figure 4-28 Trouble Codes Screen 4.8.2.2 Diagnostics Report Viewing All the saved reports can be viewed in the Data Manager application.  Tap Data Manager > Vehicle History. Select a specific vehicle history record and then tap View PDF in the upper-right corner to view the report. ...
  • Page 60 Figure 4-29 Report List 1 Tap the on the lower-right corner of the report. NOTE Note that if the report displays , it means the report has been uploaded to the cloud successfully, and you can share the report with others; if the report displays , it means the report has failed to upload to the cloud, but will try to automatically upload to the cloud when entering the Report again.

  • Page 61: Exiting Diagnostics

    4.9 Exiting Diagnostics The Diagnostics application remains open as long as there is an active communication with the vehicle. You must exit the diagnostics operation to stop all communications with the vehicle before closing the Diagnostics application. NOTE Damage to the vehicle electronic control module (ECM) may occur if the communication is disrupted.

  • Page 62: Service

    Service The Service application is specially designed to provide quick access to the vehicle systems for various scheduled service and maintenance tasks. The typical service operation screen is a series of menu-driven executive commands. Follow on-screen instructions to select appropriate execution options, enter correct values or data, and perform necessary actions.

  • Page 63: Epb Safety

    Ensure that the EPB control system is reactivated after the maintenance work has been completed. NOTE Autel accepts no responsibility for any accident or injury arising from the maintenance of the Electric Parking Brake system. 5.3 Tire Pressure Monitoring System (TPMS) Service This function allows you to quickly look up the tire sensor IDs from the vehicle’s ECU, as...

  • Page 64: Steering Angle Sensor (Sas) Service

    Accident repairs where damage to the steering angle sensor, SAS assembly, or any part of the steering system may have occurred. NOTE Autel accepts no responsibility for any accident or injury arising from servicing the SAS system. When interpreting DTCs retrieved from the vehicle, always follow the manufacturer’s recommendation for repair.

  • Page 65: Immobilizer (Immo) Service

    driven more with higher load and speed. In order for regeneration to take place, a prolonged high exhaust temperature must be obtained. In the event of the car being driven in such a way that regeneration is not possible, i.e., frequent short journeys, a diagnostic trouble code will eventually be registered in addition to the DPF light and “Check Engine”...
  • Page 66 frequency identification between a transponder in the ignition key and a radio frequency reader in the steering column. When the key is placed in the ignition, the transponder sends a signal with a unique identification code to the reader, which relays it to a receiver in the vehicle's computer control module.

  • Page 67: Data Manager

    Data Manager The Data Manager application allows you to store, print, and review the saved files, manage the workshop information, and customer information records, and keep test vehicle records. Selecting the Data Manager application opens the file system menu. There are nine main functions available.

  • Page 68: Vehicle History

    Button Name Description Tap to view the local reports on your tablet. If the report is successfully Cloud Report uploaded to cloud, you can also share the report with others. Tap to review the reports stored as PDF format. Review Data Tap to review the recorded data.

  • Page 69: Historical Test Record

    Figure 6-2 Vehicle History Screen Top Toolbar Buttons — displays navigation and application controls. Main Section — displays all the vehicle history records.  To activate a test session for the recorded vehicle Tap the Data Manager application on the MaxiCOM Job Menu. Select Vehicle History to open the screen.

  • Page 70: Workshop Information

    Figure 6-3 Historical Test Record Sheet  To edit the Historical Test record Tap Data Manager on the MaxiCOM Job Menu. Select Vehicle History. Select the specific vehicle history record thumbnail from the main section. The Historical Test record will appear. Tap Edit (the pen icon) to start editing.

  • Page 71: Customer

    Figure 6-4 Workshop Information Sheet  To edit the Workshop Information sheet Tap the Data Manager application on the MaxiCOM Job Menu. Select Workshop Information. Tap on each field to input the appropriate information. Tap Done to save the updated workshop information sheet, or tap Cancel to exit without saving.

  • Page 72: Image

     To edit a customer account Tap Data Manager on the MaxiCOM Job Menu. Select Customer. Select a customer account by tapping the corresponding name card. A Customer Information record displays. Tap Edit on the Top Toolbar to start editing. Tap on the input field to edit information, and enter the updated information.

  • Page 73: Cloud Report

    Table 6-2 Toolbar Buttons in Image Screen Button Name Description Returns to the previous screen. Back Tap to search the image by entering Search its stored time. Tap to display the editing toolbar to Edit select, delete, print, or email the image(s).

  • Page 74: Pdf Files

    6.6 PDF Files The PDF section stores and displays all PDF files of saved data. After entering the PDF database, select a PDF file to view the stored information. This section uses the standard Adobe Reader application for file viewing and editing. Please refer to the associated Adobe Reader manual for more detailed instructions.

  • Page 75: Uninstall Apps

    6.9 Uninstall Apps This section allows you to manage the software applications installed on the MaxiCOM diagnostics system. Selecting this section opens a managing screen, on which you can check all available vehicle diagnostic applications. Select the vehicle software you want to delete by tapping on the vehicle manufacturer icon, the selected item will display a blue mark at the upper-right corner.

  • Page 76: Settings

    Settings Access the Settings menu to adjust default settings and view information about the MaxiCOM system. The following options are available for the MaxiCOM system settings:  Unit  Language  Printing Settings  Report Settings  Push Notifications  Auto Update ...

  • Page 77: Printing Settings

    To install the PC Link driver program Download the Maxi PC Suite software from www.autel.com > Support > Downloads > Autel Update Tools, and install it to your windows-based computer. Double click on Setup.exe item. Select the installation language and the wizard will load momentarily.

  • Page 78: Report Settings

    NOTE Make sure the tablet is connected to the same network with your computer, either via Wi-Fi or LAN, before printing. Make sure the computer installed with the Printing Services program is connected to a printer.  To perform printing through the PC Run the PC Link program on the PC.

  • Page 79: Push Notifications

    7.5 Push Notifications This option allows you to manage notifications. The Notification Preferences option is turned on by default and cannot be turned off by users so that certain system notifications such as system security warnings won't be blocked.  To manage other notifications Tap the Settings application on the MaxiCOM Job Menu.

  • Page 80: Vehicle List

    In order to protect the rights and interests of both software developers and users, some legal terms and statement information are listed here. Please carefully read them before using the Autel software. 7.9 System Settings This function provides you with direct access to the Android system settings interface,...

  • Page 81: Update

    Member Center — tap to enter the Member Center screen.  Refresh — refreshes the available updates.  Information Bar — displays your Autel ID, MaxiCOM device model information, subscription validity period and other related information. Tap Renew to extend subscription. Main Section — displays the available updates.

  • Page 82: Update Procedures

    NOTE Make sure the tablet is registered before activating the Update application. See Autel User Center on page 100 for details. Tap the Update application button from the MaxiCOM Job Menu; or tap the update notification message when received. The Update screen displays.

  • Page 83: Member Center

    8.2 Member Center The Member Center section provides settings related to account management, rights collection, and event participation. Figure 8-3 Member Center Screen...

  • Page 84: Vci Manager

    VCI Manager This application pairs the tablet with the MaxiVCI V150, checks the communication status and update the VCI firmware. Figure 9-1 VCI Manager Screen Connection Mode — there are four connection modes available for selection. The connection status is displayed alongside. VCI BT —...

  • Page 85: Vci Bluetooth Pairing

    9.1 VCI Bluetooth Pairing The MaxiVCI V150 needs to be connected to a vehicle, so that it is powered during the synchronization procedure. Ensure the tablet has sufficient battery power or is connected to an external power supply.  To pair the MaxiVCI V150 with the tablet Power on the tablet.

  • Page 86: Vci Update

    Toggle the Bluetooth ON. Tap Scan at the top-right corner of the screen. The device will start to search for available units to pair with. Depending on the type of battery tester, the device name may appear as "Maxi-" suffixed with the battery tester’s serial number. Select the appropriate device for pairing.

  • Page 87: Battery Test

    Battery Test The Battery Test application allows user to perform in-vehicle battery test and out-of-vehicle battery test functions when the BT506 battery tester is connected to the MaxiCOM tablet and a battery. The BT506 battery tester enables technicians to view the health status of the vehicle's battery and electrical system.

  • Page 88: Maxibas Bt506 Battery Tester

    10.1 MaxiBAS BT506 Battery Tester 10.1.1 Function Description Figure 10-2 MaxiBAS BT506 Tester Power Button Status LED Power LED USB Port Battery Clamp Cable Table 10-1 LED Description Color Description The tester is communicating via USB Flashing Green cable. The tester is communicating via Status LED Flashing Blue Bluetooth.

  • Page 89: Power Sources

    Color Description The tester is powered on and the Solid Green battery is sufficiently charged. The tester is charging. (Turns solid Flashing Green green when battery is fully charged.) Power LED Solid Red The device is in boot mode. The battery level is low. Please Flashing Red charge.

  • Page 90: Technical Specifications

    10.2.3 Technical Specifications Table 10-2 Technical specifications Item Description  USB 2.0, Type C Connectivity  Bluetooth 4.2 Input Voltage 5 V DC Working Current < 150 mA at 12 V DC Internal Battery 3.7 V/800 mAh Lithium-ion Polymer battery CCA Range 100 to 2000 A Voltage Range...

  • Page 91: Connect The Battery Tester

    10.3.2 Connect the Battery Tester  To pair with the MaxiCOM tablet Turn on both the MaxiCOM tablet and the BT506 battery tester. Ensure that the units are sufficiently charged before you begin. Enable Bluetooth on the tablet by tapping VCI Manager > BAS BT. Toggle the Bluetooth ON.

  • Page 92: In-Vehicle Test

    10.4 In-vehicle Test The In-vehicle Test is used for testing batteries that are installed in a vehicle. An in-vehicle test includes the Battery Test, Starter Test, and Generator Test. These tests help determine the health of the battery, the starter, and the generator. IMPORTANT A disclaimer will appear when first accessing any function on the Home screen.

  • Page 93: Battery Test

    Table 10-3 Top Toolbar Buttons Button Name Description The value on the icon indicates the real-time Battery voltage of the tested battery. In the battery test, Connection the button will turn green if the battery is good. Otherwise, it will turn red. Next Tap to proceed.
  • Page 94 Figure 10-7 Battery Test Results Screen The battery test results include a color-coded results summary, a list of test data, and repair tips. Possible in-vehicle test results are as follows: Table 10-4 Test Results Result Repair Tip Good Battery Battery is good. Good &...

  • Page 95: Starter Test

    10.4.2 Starter Test Follow the on-screen instructions to complete the test. Start the engine and let it idle. The test results will appear as follows: Figure 10-8 Starter Test Result Screen Table 10-5 Starter Test Results Result Description Cranking Normal The starter is good.
  • Page 96 Figure 10-9 Generator Test Results Screen Table 10-6 Generator Test Results Result Description Charging Normal The generator is functioning normally.  The belt linking the starter and the generator is loose; Output Too Low  The cable linking the starter and battery is loose or corroded.

  • Page 97: Out-Of-Vehicle Test

    10.5 Out-of-vehicle Test Out-of-vehicle Test is used to test the condition of batteries that are not connected to a vehicle. This function aims to check the health status of the battery only. 10.5.1 Test Procedure  To start the out-of-vehicle test Connect the tester clamps to the battery terminals.

  • Page 98: Test Results

    Figure 10-11 Out-of-vehicle Test Results Screen 10.5.2 Test Results Table 10-7 Out-of-vehicle Test Results Result Description Good Battery Battery meets required standards. Battery is good, but low on charge. Fully charge the Good & Recharge battery. Check for causes of low charge. Charge &...

  • Page 99: Maxiviewer

    MaxiViewer The MaxiViewer allows you to search the functions supported by our tools and the software version information. There are two ways of searching, either by searching the tool and the vehicle or searching the functions.  To Search by the vehicle Tap the MaxiViewer application on the MaxiCOM Job Menu.

  • Page 100: Support

    12.1 Product Registration In order to get access to the Support platform and obtain update and other services from Autel, you are required to register the MaxiCOM tablet the first time you use it. See Autel User Center on page 100 for detailed information.

  • Page 101: My Account

    User Information — displays detailed information of your registered online Autel  account, such as your Autel ID, name, address, and other contact information. Device Information — displays the registered product information, including the  product serial number, registration time, expired time, and warranty period.

  • Page 102: Training

    12.5 Training The Training section provides quick links to Autel’s online video library. Select a video channel by language to see all available online tutorial videos on topics such as product usage techniques and vehicle diagnostics practice. 12.6 FAQ The FAQ section provides comprehensive references for all questions frequently asked and answered about the use of Autel's online member account, shopping, and payment procedures.

  • Page 103: Oem Authorization

    OEM Authorization The OEM Authorization application allows you to unlock the gateway ECU (CGW) for some vehicles to perform advanced diagnostics tests. NOTE Make sure the tablet is connected to the Internet before launching the OEM Authorization application.  To unlock the gateway ECU (CGW) Connect the MaxiCOM tablet to the vehicle through the MaxiVCI V150.

  • Page 104: Remote Desktop

    The Remote Desktop application launches the TeamViewer QuickSupport program, which is a simple, fast, and secure remote-control interface. You can use the application to receive remote support from Autel’s support center, colleagues or friends, by allowing them to control your MaxiCOM tablet on their PC via the TeamViewer software.
  • Page 105 downloading TeamViewer program (full version) online (see http://www.teamviewer.com), and then launch the software. Provide your ID to your partner and wait for him/her to send you a remote-control request. A prompt will appear asking you to allow remote control on your device. Tap Allow to accept, or tap Deny to reject.

  • Page 106: Maxivideo

    MaxiVideo The MaxiVideo application configures the MaxiCOM tablet to operate as a digital video scope by simply connecting the tablet to a MaxiVideo Digital Inspection Camera. This function allows you to examine difficult-to-reach areas normally hidden from sight, with the ability to record digital still images and videos, which offers you an economical solution to inspect machinery, facilities, and infrastructure in a safe and quick way.

  • Page 107: Quick Link

    Quick Link The Quick Link application provides you with convenient access to Autel’s official website and many other well-known sites in automotive service industry to provide technical help, knowledge bases, forums, and training and expertise consultations. Figure 16-1 Quick Link Screen ...

  • Page 108: Autel User Center

    Figure 17-1 Autel User Center Screen If you already have an Autel ID, you can log in with your phone number and verification code, or tap Log In with Password to log in with your Autel ID and password. If you don't have an Autle ID yet, tap Register to create an Autel ID.
  • Page 109 If you have an Autel account, sign in with your account ID and password and skip to step 7. If you are a new member to Autel, click the Register button to create your Autel Enter the required personal information in the input fields.

  • Page 110: Maintenance And Service

    Maintenance and Service To ensure that the MaxiCOM diagnostic tablet performs at its optimum level, we advise that the product maintenance instructions covered in this section is read and followed. 18.1 Maintenance Instructions The following shows how to maintain your devices, together with precautions to take. ...

  • Page 111: Troubleshooting Checklist

    Your device may have not been connected to the charger properly. Check the connector. NOTE If your problems persist, please contact Autel’s technical support personnel or your local selling agent. 18.3 About Battery Usage Your tablet is powered by a built-in Lithium-ion Polymer battery. This means that, unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your tablet’s autonomy due to the “battery memory effect”...

  • Page 112: Service Procedures

    This section introduces information for technical support, repair service, and application for replacement or optional parts. 18.4.1 Technical Support If you have any question or problem on product operations, please contact us. Autel China Headquarters  Phone: +86 (0755) 8614-7779 (Monday-Friday, 9AM-6PM Beijing Time) ...
  • Page 113 Email: imea-support@autel.com  Address: 906-17, Preatoni Tower (Cluster L), Jumeirah Lakes Tower, DMCC, Dubai, UAE  Web: www.autel.com Autel Latin America Mexico:  Phone: +52 33 1001 7880 (Spanish in Mexico)  Email: latsupport@autel.com  Address: Avenida Americas 1905, 6B, Colonia Aldrete, Guadalajara, Jalisco,...

  • Page 114: Repair Service

    18.4.2 Repair Service If it becomes necessary to return your device for repair, please contact us first and then download the repair service form from www.autel.com, and fill it in. The following information must be included:  Contact name ...

  • Page 115: Compliance Information

    Compliance Information FCC Compliance FCC ID: WQ8-DS900BT2232 This device complies with Part 15 of the FCC rules and Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 116 -- Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IC WARNING -English: This device complies with Industry Canada’s licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause...
  • Page 117 RoHS COMPLIANCE This device is declared to be in compliance with the European RoHS Directive 2011/65/EU. CE COMPLIANCE This product is declared to conform to the essential requirements of the following directives and carries the CE mark accordingly: Radio Equipment Directive 2014/53/E...

  • Page 118: Warranty

    Warranty Limited One Year Warranty Autel Intelligent Technology Corp., Ltd. (the Company) warrants to the original retail purchaser of this MaxiCOM diagnostics device that should this product or any part thereof during normal usage and conditions, be proven defective in material or...
  • Page 119 IMPORTANT All contents of the product may be deleted during the process of repair. You should create a back-up copy of any contents of your product before delivering the product for warranty service.

Table of Contents

Save PDF
