- Page 1 DN8245V-70 Quick Start 01 (WIND,Greece) Issue Date 2022-01-06 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: Table Of Contents
DN8245V-70 Quick Start 01 (WIND,Greece) Contents Contents 1 Placing the Device........................1 2 Connecting Cables........................3 3 Indicator Description......................5 4 Ports and Buttons........................7 5 FAQs............................9 Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd. -
Page 4: Placing The Device
Quick Start 01 (WIND,Greece) 1 Placing the Device Placing the Device Do not install the DN8245V-70 outdoors or in an outdoor cabinet. Keep 10 cm clearance on all sides to ensure adequate ventilation. Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd. - Page 5 DN8245V-70 Quick Start 01 (WIND,Greece) 1 Placing the Device It is recommended that the computer and DN8245V-70 be put far away from electric appliances that generate strong magnetic or electric fields, such as microwave ovens. Mark the positions of two holes used for mounting the DN8245V-70, and ensure that the two holes have the same spacing as the two mounting holes.
-
Page 6: Connecting Cables
1 Telephone jack on the 2 Telephone 3 Splitter wall 4 Desktop computer 5 STB 6 USB device 7 Power adapter 8 Laptop computer a Line port b Telephone port c Modem port Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd. - Page 7 ● The DN8245V-70 supports two upstream connection modes: DSL and Ethernet. Select one upstream transmission mode at a time. ● Some accessories are not delivered with the DN8245V-70. Prepare them by yourself. Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd.
-
Page 8: Indicator Description
Internet in router mode. (Blinks 4 times per second.) ● The DSL home gateway is connected to the Internet in router mode, and data is being transmitted. (Blinks twice per second.) Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd. - Page 9 ● The DSL home gateway is registered with an SIP server, and data is being transmitted. (Blinks 4 times per second.) No VoIP service, or no VoIP WAN configuration exists. Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd.
-
Page 10: Ports And Buttons
Adaptive to the LAN port or WAN port: Connects to the gateway as a WAN port, or connects to devices that provides Internet access, such as a modem or switch, as a LAN port. Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd. - Page 11 5s to turn off the wireless function. ● When the wireless function is disabled, tap the button to turn on the wireless function. On/Off Powers the DSL home gateway on or off. Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd.
-
Page 12: Faqs
DN8245V-70 Quick Start 01 (WIND,Greece) 5 FAQs FAQs How do I log in to the DN8245V-70 web page? ● Wireless login Connect your mobile phone, pad, or PC to the Wi-Fi network of the DN8245V-70. Enter the IP address in the address bar of a browser and press Enter. On the displayed login page, enter the account and password. - Page 13 Quick Start 01 (WIND,Greece) 5 FAQs ● Wired login Use a network cable to connect the DN8245V-70 to your PC. NO TE The preceding cable connection diagram and login pages are only for reference, and those of the actual product prevail.
- Page 14 DN8245V-70). Click Log In. NO TE ● Before you log in to the DN8245V-70 web page, ensure that the computer used for the login is connected to the DN8245V-70 and has been configured to automatically obtain an IP address or assigned with a static IP address.
- Page 15 On the web page, click Fast Setting (not for the first login). The Fast Setting page is displayed. On the Wi-Fi configuration page, and click Hide. What can I do if I cannot connect to the Wi-Fi network? Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd.
- Page 16 What can I do if I cannot find my own Wi-Fi signals? How can I hide the Wi-Fi name? Log in to the DN8245V-70 web page using your mobile phone, pad, or PC. For details, see "How do I log in to the DN8245V-70 web page?"...
- Page 17 How do I restore the DN8245V-70 to factory setting? Press and hold the Reset button for more than 6s to restore the DN8245V-70 to factory settings. Exercise caution when performing this operation. Otherwise, the device may fail to access the Internet.
