Technical specifications

10.3 Inputs/Outputs

10.3 Inputs/Outputs
DVI 1
DVI 2
DisplayPort 1
HDMI connection (DVI 3)
4-pin mini-DIN socket (serial connection)
2 x USB (downstream)
2 x USB (upstream)
2 x DC 5 V/max. 1 A

10.4 Mechanical design

Housing components
Ventilation openings
Protection class
Connector panel
Weight (without stand)
Dimensions (W x H x D) in mm
(without stand)

10.5 Climatic conditions

Operation
Temperature range
Temperature gradient
Air pressure
Transport and storage (packed)
Temperature range
Temperature gradient
Humidity
Air pressure
40
• 1 x dual link DVI-I socket (analog pins are not
used) - 2560 x 1600 at 60 Hz
• Service and communication over DDC chan-
nel of DVI socket
1 x single link DVI-I socket (analog pins are not
used) - 1920 x 1200 at 60 Hz
1 x DisplayPort – max. 2560 x 1600 at 60 Hz
1 x HDMI socket (transmits a DVI signal) – max.
1280 x 1024 at 60 Hz
For connecting a photometer
For connecting external USB devices
For communicating with the PC and for service
purposes
For connecting external devices
Metal and plastic
In rear panel
IP20 according to EN 60529
On rear panel, under cover
RadiForce LX300W: 15.5 kg +/- 1 kg
RadiForce LX300W-P: 18.5 kg +/- 1 kg
RadiForce LX300W-S: 19.5 kg +/- 1 kg
701.5 x 472.6 x 107.4
+5 °C to +40 °C Ambient temperature
Max. 5°C/h, without condensation
700 ... 1060 hPa
-20°C ... +60°C ambient temperature
Max. 5°C/h, without condensation
10 ... 90%, non-condensing, at 25°C
200 ... 1060 hPa
Instructions for Use, 07/2019
RadiForce LX300W
