Summary of Contents for Eizo CuratOR LX1910
- Page 1 Instructions for Use 1MP 19" LCD Monitor Important Please read the safety information and all information delivered with the product carefully to familiarize yourself with safe and effective usage.
-
Page 2: Legal Information
Use of EIZO products WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech- nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems. -
Page 3: Table Of Contents
Adapting brightness and contrast ............. 21 7 Operation......................... 23 Operator controls .................... 23 Lock or unlock OSD menu.................. 24 Overview of the OSD menu .................. 25 “Image” menu ...................... 26 “Geometry” menu.................... 28 "Power Manager" menu.................. 30 "Monitor settings" menu.................. 31 CuratOR LX1910 Instructions for Use, 08/2022... - Page 4 12.4 China RoHS (Restriction of Hazardous Substances) .......... 51 12.5 Declaration of compliance with India RoHS............ 53 12.6 Environmental protection .................. 53 12.7 Warranty ......................... 53 12.8 Repairs ........................ 53 12.9 Additional devices.................... 53 12.10 Contact ........................ 53 12.11 Trademarks...................... 54 Index .......................... 55 CuratOR LX1910 Instructions for Use, 08/2022...
-
Page 5: Introduction
1.2 Intended use Intended purpose The CuratOR LX1910 is intended for the display of still images and moving images from various commercially available devices commonly used in a medical environment, in partic- ular radiology. The monitor is optimized for the reproduction of grayscale X-ray images. The monitor is not suitable for mammography. -
Page 6: User Groups
Cleaning staff "Cleaning staff" refers to personnel responsible for cleaning medical devices. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 7: Safety Information
2 Safety information 2.1 General safety instructions Correct and safe operation of EIZO devices assume professional transport, storage, installa- tion, and connection, as well as careful operation and service. The devices may only be used for applications for which they are intended. - Page 8 Only use power cables approved for China. These power cables are identified by the labels "CCC" or "CQC". Observe the country-specific regulations Observe all regulations of the country in which the device is used. CuratOR LX1910 Instructions for Use, 08/2022...
- Page 9 If the device is brought into a room with a higher or rising temperature, condensed water will form in and on the device. Do not switch on the device until the condensed water has evaporated. Other- wise, the device could be damaged. CuratOR LX1910 Instructions for Use, 08/2022...
- Page 10 Note that monitors can fail as a result of aging, and that image properties such as brightness, con- trast,and color value can change. Do not touch the monitor screen Due to mechanical pressure or electrostatic discharges, touching the screen can result in brief distur- bances to the image. CuratOR LX1910 Instructions for Use, 08/2022...
-
Page 11: Product-Specific Safety Instructions
Note Image quality To maintain constant image quality, EIZO recommends cleaning the monitor on a regular basis and checking image properties in accordance with all applicable local regulations. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 12: Description
Keep the packaging material for subsequent transport of the device. Device The CuratOR LX1910 is a 1MP 19" LCD Monitor for installation in a ceiling or wall mount, or for installation in a stand. The CuratOR LX1910-S version has a stand. Otherwise, the ver- sions are identical. -
Page 13: Features
Description 3.2 Features 3.2 Features The CuratOR LX1910 has the following features that permit a wide range of applications: Perfect picture reproduction thanks to LCD technology The use of LCD technology eliminates picture geometry distortions and color spots. The monitor delivers flicker-free images even at low border rates (60 Hz). The monitor thus meets the strictest ergonomic requirements. -
Page 14: Setup And Installation
• Protect the monitor from dust, for example through appropriate construction measures at the installation site. • During transport, use the original packaging or service packaging. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 15: Installing The Monitor
Mounts must be tested and approved by the manufacturer for the weight to be sup- ported. • An installed stand must be sufficiently stable to withstand tilting of up to 10° without top- pling the monitor. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 16: Connecting
Device settings may only be adjusted by service personnel. NOTICE Disconnecting from line power Always set the power switch to "Off" before disconnecting the device from power. Other- wise the device could be destroyed. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 17: Device Connectors
The device is disconnected from line power by turning off the power switch. • Make sure that the main switch is easily accessible. Main switch Signal inputs Grounding Type plate Fig.: Rear view CuratOR LX1910 CuratOR LX1910 Instructions for Use, 08/2022... -
Page 18: Connection Panel
5.3 Connecting the signal cable CAUTION Connector Connectors may only be plugged in or removed by Service when the device is switched off. Prerequisite The monitor has to be installed in the ceiling suspension, wall mount, or stand. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 19: Connecting The Power Cable
The monitor has to be installed in the ceiling suspension, wall mount, or stand. Procedure 1. Connect the appliance plug to the monitor power connector. 2. The power cable can be secured using a cable grip. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 20: Commissioning
This section describes how to adapt the monitor to operate with an analog video source. The procedure is divided into the following steps: • Adjust the position, phase and frequency. • Adapt brightness and contrast. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 21: Adjusting The Position, Phase, And Frequency
The brightness and contrast must be adjusted for the respective graphics card in the system on site due to different output levels. Note The exact brightness and contrast settings are only possible with a photometer. Perform the following steps unless a specific procedure is specified for the system. CuratOR LX1910 Instructions for Use, 08/2022... - Page 22 ð This is the optimum contrast value. 8. Exit the OSD to save the values. ð You have set the brightness and contrast for optimized display of the 5% and 95% squares of the SMPTE test pattern. CuratOR LX1910 Instructions for Use, 08/2022...
-
Page 23: Operation
Operation LED The OSD keys and the operation LED are located on the front of the monitor. The operation LED illuminates when power is supplied to the device and the power switch is turned on. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 24: Lock Or Unlock Osd Menu
Lock the OSD menu • In the OSD menu “Monitor Settings” under “OSD settings”, set the “OSD keylock” func- tion to “On”. The OSD menu then becomes locked once power to the monitor is cycled. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 25: Overview Of The Osd Menu
• All signal inputs may be connected simultaneously. You can use the OSD menu to change monitor settings or display information about the monitor. The following sections present the menus and available settings. Fig.: Overview of the OSD menu CuratOR LX1910 Instructions for Use, 08/2022... -
Page 26: Image" Menu
Change the values for the red, green, or blue proportion of the set color tempera- Blue 0–255 ture. Default: 255 each Note: The value can only be set if "LUT" is not set to "No Correction". CuratOR LX1910 Instructions for Use, 08/2022... - Page 27 Reset the image parameter to the de- fault settings All settings made in the “Image” menu, ex- cept for “color temperature”, are reset to the defaults. The monitor settings and set- tings of the AD converter remain in place. CuratOR LX1910 Instructions for Use, 08/2022...
-
Page 28: Geometry" Menu
You have to determine the most suitable sharp- pixels”. ness setting visually. “Analog Adjustment” menu Note The “Analog Adjustment” menu is only displayed if an analog image source is connected to the DVI-I input. CuratOR LX1910 Instructions for Use, 08/2022... - Page 29 (with the identical monitor and graphics card settings). Reset ADC Reset analog settings If you perform this function, the brightness and contrast values will be reset to the values after the final adjust- ment. CuratOR LX1910 Instructions for Use, 08/2022...
-
Page 30: Power Manager" Menu
Depending on the PC and the graphics card used, the input signal may go undetected and the monitor may not Default: Off be able to exit Power Save mode. Set this function to “On” if this occurs. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 31: Monitor Settings" Menu
Set border color Note: Can only be set if the image size is set to “One to one” in the “Geometry” menu. If the displayed image has a border, its grayscale can be set here. CuratOR LX1910 Instructions for Use, 08/2022... - Page 32 Default: Active input “Active input” will enable communication via the selected input. Reset Reset firmware to standard values The settings in the OSD menu “Image” and the AD converter remain in place. Default: No CuratOR LX1910 Instructions for Use, 08/2022...
-
Page 33: Information" Menu
Serial number • Power on time (h) • Backlight on time (h) • Input signal (resolution and signal frequency) • Mode (for analog signals only) • Temperature in the monitor [°C] • Firmware version CuratOR LX1910 Instructions for Use, 08/2022... -
Page 34: Cleaning And Check Settings
Commercial detergent 1 vol.% detergent substances ® Aldehyde Melsitt , 10 vol. % Desinfecting agents Morning Mist (1:64) ® SURFANIOS Premium, 0.25% ® Taski Sprint DS 5001 0.5% 0.5% Chlorhexidine in 70% isopropyl alcohol CuratOR LX1910 Instructions for Use, 08/2022... -
Page 35: Prohibited Cleaning Agents And Disinfectants
The picture quality of the monitor changes due to aging of the LCD unit and the backlight. • Check the monitor settings at regular intervals in accordance with the local guidelines. • Correct the settings if necessary. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 36: Troubleshooting
Switch to "Monochrome (G)" has a strong green shading mitting a green signal in the OSD menu. Miscellaneous Loose plug • Connect the loose plug and secure it. Defective cable • Replace the defective cable. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 37: Technical Specifications
Multi-standard technology Video modes with resolutions less than 1280 x 1024 can be expanded to the TFT resolution, and thus utilize the full display area. Timing recognition H frequency, V frequency, number of horizontal lines. CuratOR LX1910 Instructions for Use, 08/2022... -
Page 38: Inputs/Outputs
4.3 ± 0.5 kg (CuratOR LX1910) 6.1 ± 0.5 kg (CuratOR LX1910-S) Dimensions (W x H x D) in mm 405 x 334 x 61 (CuratOR LX1910) 405 x (407 ~ 507) x 204 (CuratOR LX1910-S) CuratOR LX1910 Instructions for Use, 08/2022... -
Page 39: Climatic Conditions
Safety standards • IEC/EN 60601-1 • CAN/CSA - C22.2. No. 60601-1 • UL60601-1 • GB 4943.1, fuse T3.15A 250V Protection class Protection class I Degree of protection according to DIN 40050 IP20 Medical device classification (EU) Class 1 CuratOR LX1910 Instructions for Use, 08/2022... -
Page 40: Supported Timing
74.25 WXGA 1280 x 768 47.8 79.5 WXGA+ 1280 x 800 49.7 83.5 SXGA- 1280 x 960 SXGA+ 1400 x 1050 65.3 121.75 UXGA 1600 x 1200 162.0 HD1080 1920 x 1080 67.5 148.5 CuratOR LX1910 Instructions for Use, 08/2022... - Page 41 1280 x 1024 66.43 Non-interlaced 1280 x 1024 67.5 116.1 Non-interlaced 1280 x 1024 77.46 131.06 Non-interlaced 1280 x 1024 76.7 Non-interlaced 1280 x 1024 81.13 Non-interlaced 1280 x 1024 78.13 135.009 Non-interlaced *reduced image quality CuratOR LX1910 Instructions for Use, 08/2022...
-
Page 42: Dimension Drawings
Dimension drawings 11.1 View from front, top, and side (with stand) 11 Dimension drawings All dimensions in mm 11.1 View from front, top, and side (with stand) CuratOR LX1910 Instructions for Use, 08/2022... -
Page 43: Rear View
Dimension drawings 11.2 Rear view 11.2 Rear view CuratOR LX1910 Instructions for Use, 08/2022... -
Page 44: Appendix
Marking according to ACPEIP (China-RoHS). Symbol for degree of protection according to DIN EN 60529. "On" symbol (voltage) "Off" symbol (voltage) Symbol "Comply with the instructions for use". UK Responsible Person Swiss authorized representative (CH-REP) CuratOR LX1910 Instructions for Use, 08/2022... -
Page 45: Information On Electromagnetic Compatibility (Emc)
IEC/EN 60601-1-2. Electromagnetic radiation The CuratOR LX1910 is intended for use in the electromagnetic environments noted below. Customers and users of the CuratOR LX1910 have to ensure that the device is used in such an envi- ronment. Radiation test Conformity... - Page 46 The CuratOR LX1910 was tested with the following compliance levels in accordance with the test re- quirements for professional healthcare facilities, as established in IEC/EN 6061-1-2. Customers and users of the CuratOR LX1910 have to ensure that the monitor is used in such an en- vironment.
- Page 47 12.2 Information on electromagnetic compatibility (EMC) Electromagnetic interference immunity The CuratOR LX1910 was tested with the following compliance levels in accordance with the test re- quirements for professional healthcare facilities, as established in IEC/EN 6061-1-2. Customers and users of the monitor have to ensure that the monitor is used in such an environment.
- Page 48 Recommended minimum distance between portable or mobile RF communications devices and the CuratOR LX1910 The CuratOR LX1910 is intended for use in an electromagnetic environment in which interference due to electromagnetic radiation is controlled. For other portable and mobile RF communication de- vices (transmitters), the recommended minimum distance between the portable and mobile RF com- munication devices (transmitters) and the monitor applies as listed below.
- Page 49 Recommended minimum distance between portable or mobile RF communications devices and the CuratOR LX1910 The CuratOR LX1910 is intended for use in an electromagnetic environment in which interference due to electromagnetic radiation is controlled. The customer or user of the monitor can help prevent electromagnetic interference by maintaining the recommended minimum distance between portable and mobile RF communications devices (transmitters) and the monitor.
-
Page 50: Fcc Declaration Of Conformity
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. •... -
Page 51: China Rohs (Restriction Of Hazardous Substances)
EFUP shall be done in accordance with the Product Maintenance Procedures. This product must not be disposed of as unsorted municipal waste, and must be col- lected separately and handled properly after decommissioning. CuratOR LX1910 Instructions for Use, 08/2022... - Page 52 Applications of hazardous substances in this medical device are required to achieve its intended clinical uses, and/or to provide better protection to human beings and/or to environment, due to lack of reasonably (economically or technically) available substitutes. 产品中有害物质的名称及含量 Table of hazardous substances’ name and concentration. CuratOR LX1910 Instructions for Use, 08/2022...
-
Page 53: Declaration Of Compliance With India Rohs
12.5 Declaration of compliance with India RoHS 12.5 Declaration of compliance with India RoHS We, EIZO Corporation, hereby declare and guarantee that this product has been designed and manufactured in compliance with the E-Waste management rule 2016 which prohibit the inclusion of the following substances except for the exemptions listed in schedule II. -
Page 54: Trademarks
ENERGY STAR is a registered trademark of the United States Environmental Protection Agency in the United States and other countries. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, Radi- Force, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corpora- tion in Japan and other countries. -
Page 55: Index
Sharpness 28 Shielding measures 16 Switch on 20 Environment 14 Technical specifications 37 Features 13 Troubleshooting 36 General safety instructions 7 User 6 Grounding 16 Ventilation 14 Image position 21 Warranty 53 Keys 24 CuratOR LX1910 Instructions for Use, 08/2022... - Page 56 Carl-Benz-Straße 3, 76761 Rülzheim, Germany Moosacherstrasse 6, Au, CH-8820 Wädenswil, Switzerland 1 Queens Square, Ascot Business Park, Lyndhurst Road, Ascot, Berkshire, SL5 9FE, UK Instructions for Use, 08/2022 CuratOR LX1910 Copyright © 2022 EIZO GmbH. All rights reserved. 1085755-002...
