Server software:
The imagePRESS Server software. Runs on Linux operating system.
Document conventions
NOTE:
The NOTE format highlights important messages and additional information.
WARNING:
The WARNING icon indicates a warning concerning operations which, if not performed correctly, may lead to death or
injury. To use the imagePRESS Server safely, always pay attention to WARNING icons and messages.
CAUTION:
The CAUTION icon indicates a caution concerning operations which, if not performed correctly, may lead to injury. To use
the imagePRESS Server safely, always pay attention to CAUTION icons and messages.
IMPORTANT:
The IMPORTANT indicates operational requirements and restrictions. To operate the imagePRESS Server correctly and
avoid damage to the imagePRESS Server or other property, always pay attention to IMPORTANT letter and messages.

How the imagePRESS Server operates

When a customer prints, the motherboard and printer interface board process image data. The printer interface board is a custom
board and allows the imagePRESS Server to communicate with the printer. The CPU controls the transfer of image data to and
from the motherboard and runs the PostScript interpreter. DIMM holds image data during printing.
The interpreter rasterizes the page description file and compresses the image pattern into memory using compression technology.
The interpreter outputs the compressed raster data through the image frame buffer memory to the printer interface board. The
raster data is sent to the printer, which then renders the image on paper at maximum speed.

Before you service the imagePRESS Server

Before you service the imagePRESS Server, it is strongly recommended that you make sure that you have the required tools
(see "Tools you will need" on page
Also, keep in mind that the most common cause of a hardware problem is a faulty or loose connection. Before you replace an
expensive component, check internal and external connections (see
codest" on page 17).

Tools you will need

To install or service the imagePRESS Server, you will need the following tools and parts:
• ESD wrist grounding strap and antistatic mat
• Flathead screwdriver
• #0, #1, and #2 Phillips head screwdrivers
• Needlenose pliers
• imagePRESS Server documentation, including the customer media pack and any related service bulletins
IMPORTANT:
Avoid touching magnetic tools to storage device such as hard disk drives. Contact between magnetic tools and magnetic
storage device may result in data corruption.
3) and carefully review all precautions (see "Precautions" on page
"imagePRESS Server connector panel and LED diagnostic
3
1. Introduction
4).
