- Page 1 INSTRUCTIONS DLP PROJECTOR LX-NZ30 B5A-4412-01...
-
Page 2: Table Of Contents
Table of contents Safety precautions....3 Maintenance......33 Important safety instructions Care of the projector ....33 Light source information ... 34 ..........4 Getting to know the light source hour Overview ....... 8 ............34 Extending light source life....34 Shipping contents...... -
Page 3: Safety Precautions
• Consult the dealer or an experienced radio/TV technician for help. Supplier's Declaration of Conformity Model Number: LX-NZ30BG, LX-NZ30WG Trade Name: JVC Responsible party: JVCKENWOOD USA Corporation Address: 1440 Corporate Drive, Irving, TX 75038 Telephone Number: 678-449-8879 This device complies with Part 15 of the FCC Rules. -
Page 4: Important Safety Instructions
Dear Customer, This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of JVCKENWOOD Corporation is: JVCKENWOOD Deutschland GmbH Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, GERMANY Information for Users on Disposal of Old Equipment and Batteries [European Union only] These symbols indicate that equipment with these symbols should not be disposed of as general household waste. - Page 5 8. Do not place liquids near or on the projector. Liquids spilled into the projector will void your warranty. If the projector does become wet, disconnect it from the power outlet and contact to have the projector repaired. 9. Do not look straight into the projector lens during operation. It may harm your sight. RG2 IEC 62471-5:2015 10.
- Page 6 Moisture condensation Never operate the projector immediately after moving it from a cold location to a hot location. When the projector is exposed to such a change in temperature, moisture may condense on the crucial internal parts. To prevent the projector from possible damage, do not use the projector for at least 2 hours when there is a sudden change in temperature.
- Page 7 CLASS 1 LASER PRODUCT LASER CAUTION LABEL • This product complies with EN60825-1: 2014+A11:2021. • This product complies with EN50689:2021. • This product is designed to project images on a wall or screen. WARNING Do not look into the lens while in use. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
-
Page 8: Overview
Overview Shipping contents Carefully unpack and verify that you have the items below. Some of the items may not be available depending on your region of purchase. Please check with your place of purchase. Some of the accessories may vary from region to region. Projector Remote control and batteries Quick start guide... -
Page 9: Projector Exterior View
Projector exterior view Front and upper side view 1. Vent (heated air exhaust) 2. Front IR remote sensor 3. Zoom ring Adjusts the size of the projected image. 4. Projection lens 5. Control panel (See "Control panel" for details.) 6. Lens shift knob (Left/Right) Adjusts the horizontal position of the projected image. -
Page 10: Controls And Functions
Controls and functions Control panel 8. POWER indicator light POWER Lights up or flashes when the projector is Toggles the projector between standby under operation. mode and on. 9. Keystone keys ( 2. Top IR remote sensor Launches the Keystone window when the 3. -
Page 11: Remote Control
Remote control 8. OK Activates the selected On-Screen Display (OSD) menu item. 9. MENU Displays the menu, or hides the menu if it is displayed. 10. BRIGHTNESS Displays the setting bar for brightness adjustment. POWER Toggles the projector between standby mode and on. - Page 12 Installing/replacing the remote control battery 1. To open the battery cover, turn the remote control over to view its back, press on the finger grip on the cover and slide it up in the direction of the arrow as illustrated. 2.
-
Page 13: Installation
Installation Choosing a location Before choosing an installation location for your projector, take the following factors into consideration: • Size and position of your screen • Electrical outlet location • Location and distance between the projector and the rest of your equipment You can install your projector in the following ways. -
Page 14: Obtaining A Preferred Projected Image Size
Obtaining a preferred projected image size The distance from the projector lens to the screen, the zoom setting, and the video format each factors in the projected image size. To shift the lens, turn the knobs on the projector to shift the projection lens in any direction within the allowable range depending on your desired image position Front projection... - Page 15 Size of the projected Screen size Projection distance (E) image (F) Offset Offset Offset (A) (C, D) Shortest Longest Diagonal Height Width (Wide) (Tele) Inch Inch Inch Inch Inch Inch Inch Inch 131 332 177 80.9 205 30.1 139 354 189 86.3 219 32.1 148 376 201...
-
Page 16: Connection
Connection When connecting a signal source to the projector, be sure to: 1. Turn all equipment off before making any connections. 2. Use the correct signal cables for each source. 3. Make sure the cables are firmly inserted. In the connection illustrations shown below, cables are not included with the projector (see "Shipping contents"). -
Page 17: Operation
Operation Starting up the projector 1. Plug the power cable into the projector and a power outlet. Turn on the power outlet switch (where fitted). The POWER indicator light on the projector flashes green after power has been applied. Please use the supplied power cable to avoid possible dangers such as electric shock and fire. -
Page 18: Selecting An Input Source
Selecting an input source The projector can be connected to multiple equipment at the same time. However, it only displays one full screen at a time. When starting up, the projector automatically searches for the available signals. If you want the projector to always automatically search for the signals: •... -
Page 19: Fine-Tuning The Image Size And Clarity
Fine-tuning the image size and clarity To adjust the projected picture size, turn the To sharpen the picture, rotate the focus ring zoom ring on the projector. on the projector. Correcting keystone Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection. -
Page 20: Adjusting 4 Corners
Adjusting 4 corners You can manually adjust four corners of the image by setting the horizontal and vertical values. 1. Go to DISPLAY menu, select Corner Adj. and press OK. 2. Press to select one corner and press OK. 3. Select 45° or 90° angle adjustment and press OK. 4. -
Page 21: Menu Functions
Menu Functions About the OSD Menus To access the OSD menu, press MENU. Using the OSD menu Main menu icon main menu PICTURE Highlight Picture Mode Natural Brightness Status Contrast Color Temperature 6500K Sub-menu Advanced Press MENU e-shift to go back to Reset Picture Mode the previous window or to... -
Page 22: Picture Menu
PICTURE menu Submenu Functions and Descriptions Selects a preset picture mode to suit your operating environment and input signal picture type. The preset picture modes are described as below: • Natural: With well-balanced color saturation and contrast with a low brightness level, this is most suitable for video images. - Page 23 Submenu Functions and Descriptions • Sharpness Makes the picture look sharper or softer. The higher the value, the sharper the picture becomes. The lower the value, the softer the picture becomes. • Gamma Gamma refers to the relationship between input source and picture brightness. •...
-
Page 24: Basic Menu
The default is On. Allows you to select which logo screen displays during projector start-up. You Splash Screen can choose JVC logo screen, Blue screen, or Black screen. Background Sets the background color for the projector. -
Page 25: Advanced Menu
ADVANCED menu Submenu Functions and Descriptions • Color Space Sets the Color Space to Auto, RGB, or YCbCr. Input Settings • Input Level Sets the Input Level to Auto, Enhanced, or Normal. • LAN Settings Press OK to enter LAN Control Settings menu. In LAN Settings, select between DHCP ON and Static IP. -
Page 26: System Menu
If you forget the password, seek help from the local JVC service center. You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector. - Page 27 Submenu Functions and Descriptions With the control keys on the projector locked, you can prevent your projector settings from being changed accidentally (by children, for example). When you select On to enable this function, no control keys on the projector will function, except POWER.
-
Page 28: Display Menu
DISPLAY menu Submenu Functions and Descriptions In the following illustrations, the black portions are inactive areas and the white portions are active areas. • Auto Scales a picture proportionally to fit the projector's native resolution in its horizontal or vertical width. This makes the most use of the screen and 15:9 picture maintains the aspect ratio of a picture. -
Page 29: Power Management Menu
Submenu Functions and Descriptions This function aims at correcting the geometric distortion of the projector’s images when they are projected onto an uneven surface such as a cylinder, a spherical shape, etc. • Enable When this function is enabled, the following functions will not be available: Keystone, Corner Adj.. -
Page 30: Information Menu
Submenu Functions and Descriptions There is one 12V trigger that works according to your needs for installation scenarios. Two selections are available: • Off: If this is selected, the projector will not send electronic signal out 12V Trigger when it is turned on. •... -
Page 31: Osd Menu Structure
Reset Picture Mode Reset/Cancel Pattern Off/On Disable/5 min/10 min/15 min/ Blank Timer 20 min/25 min/30 min BASIC Message Off/On Splash Screen Black/Blue/JVC Background Color Green/Black/Blue Color Space Auto/RGB/YCbCr Input Settings Input Level Auto/Enhanced LAN Settings Projector IP Address Subnet Mask... - Page 32 Main menu Submenu Options Language Projector Mode Front/Rear/Front Ceiling/Rear Ceiling Always On/5 sec/10 sec/15 sec/20 sec/25 Menu Display Time sec/30 sec Menu Settings Center/Top-Left/Top-Right/ Menu Position Bottom-Right/Bottom-Left SYSTEM High Altitude Mode Off/On Auto Input Search Off/On Change Password Password Power On Lock Off/On Panel Key Lock Off/On...
-
Page 33: Maintenance
Maintenance Care of the projector Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface. Before cleaning any part of the projector, turn it off using the proper shutdown procedure (see "Shutting down the projector"), unplug the power cable, and let it cool down completely. •... -
Page 34: Light Source Information
Light source information Getting to know the light source hour When the projector is in operation, the duration (in hours) of light source usage is automatically calculated by the built-in timer. To obtain the light source hour information: 1. Press MENU. ADVANCED >... -
Page 35: Indicators
Indicators There are 3 indicators which show the status of the projector. Check the following information about the indicator lights. If there is anything wrong, turn the projector off and contact your dealer. Light Status & Description Power events Green Stand-by mode Flashing Powering up... -
Page 36: Troubleshooting
Troubleshooting Problem Cause Remedy Plug the power cable into the AC inlet on the rear of the projector, and plug the There is no power from the power power cable into to the power outlet. If the cable. The projector does power outlet has a switch, make sure that not turn on. -
Page 37: Specifications
Specifications Projector specifications All specifications are subject to change without notice. Optical Input terminals Resolution Video signal input 1920 x 1080 SD/HDTV signal input 3840 x 2160 with e-shift Digital - HDMI x 2 Display system Digital - USB x 1 Single-chip DLP system Digital - DisplayPort x 1... -
Page 38: Dimensions
Dimensions 405 mm x 341 mm x 146 mm (15 7/8" x 13 1/2" x 5 3/4") (W x D x H) Unit: mm (inches) 405 (15 7/8") 100.8 (3 31/32") 31/32") Ceiling mount screws: M4 Length = 8 mm 3/64") Maintenance... -
Page 39: Timing Chart
Timing chart Supported timing for DisplayPort, HDMI (HDCP) and USB input Vertical Horizontal Pixel Format Resolution Frequency Frequency Frequency (Hz) (KHz) (MHz) VGA_60 59.940 31.469 25.175 640 x 480 VGA_72 72.809 37.861 31.500 VGA_75 75.000 37.500 31.500 SVGA_60 60.317 37.879 40.000 SVGA_72 72.188... - Page 40 1280 x 960_60 60.000 60.000 1280 x 960 1280 x 960_85 85.002 85.938 148.500 1360 x 768 1360 x 768_60 60.015 47.712 85.500 WXGA+_60 55.469 88.75 (Reduce Blanking) 1440 x 900 WXGA+_60 59.887 55.935 106.500 1400 x 1050 SXGA+_60 59.978 65.317 121.750 1600 x 1200...
- Page 41 Vertical Horizontal Pixel Frequency Timing Resolution Frequency (Hz) Frequency (KHz) (MHz) 480p 720 x 480 59.94 31.47 576p 720 x 576 31.25 720/50p 1280 x 720 37.5 74.25 720/60p 1280 x 720 45.00 74.25 1080/24p 1920 x 1080 74.25 1080/50i 1920 x 1080 28.13 74.25...
-
Page 42: Warranty And Copyright Information
Warranty and copyright information Warranty warrants this product against any defects in material and workmanship, under normal usage and storage. Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, ’s only obligation and your exclusive remedy shall be replacement of any defective parts (labor included).
