Page 1
TENTATIVE P E C I L E ET-WBC100/ET-PKC300B Wall Mount Bracket Specifications Range of Horizontal swing angle ±5° adjustment Vertical tilt angle ±5° Horizontal tilt angle ±5° Vertical slide amount Image size between 2.03 m [80 in] and 2.29 m [90 in]: -10 mm –...
Page 2
I L E ET-WBC100/ET-PKC300B Wall Mount Bracket Structural components (ET-WBC100) This is a wall mount bracket (Model No.: ET-WBC100) for installing the projector to a wall. Parts name Form (number of parts) Applications This wall mount bracket is installed to the wall to support the entire product.
Page 3
Structural components (ET-PKC300B) This projector mount bracket (Model No.: ET-PKC300B) is included in wall mount bracket (Model No.: ET-WBC100.) This is a projector mount bracket (Model No.: ET-PKC300B) used to replace the projector mount bracket of an existing wall mount bracket.
Page 4
TENTATIVE P E C I L E ET-WBC100/ET-PKC300B Wall Mount Bracket Dimensions (Unit : mm [inch]) Vertical slide Factory default position Factory default position Forward/backward slide 519 [20 7/16] 511 [20 1/8] Horizontal slide 491 [19 11/32] As of February 2023...
Page 5
TENTATIVE P E C I L E ET-WBC100/ET-PKC300B Wall Mount Bracket The illustration shows the ET-WBC100 mounted on PT-CMZ50. (Unit : mm [inch]) 198.5-288.5 [7 13/16-11 23/64] 491 [19 21/64] 449 [17 43/64] 47.5 [1 7/8] 247.5 [9 3/4] 495 [19 31/64]...
Page 6
TENTATIVE P E C I L E ET-WBC100/ET-PKC300B Wall Mount Bracket Dimension of screw holes used for securing the wall mount bracket. (Unit : mm [inch]) 418 [16 29/64] 209 [8 15/64] 47.5 [1 7/8] 131.5 [5 11/64] 68.5 [2 45/64] 25.5 [1]...
Page 7
TENTATIVE P E C I L E ET-WBC100/ET-PKC300B Wall Mount Bracket The dimensional relationship between the screen and projector is shown below. Determine the installation position on the wall based on the “Dimensional relationship diagram” and the “Dimensional relationship”. The projected image size can be adjusted by changing the distance between the screen and the projector.
TENTATIVE P E C I L E ET-WBC100/ET-PKC300B Wall Mount Bracket Dimensional relationship To use a projected image size not listed in the tables, check the projected image size SD (m) and calculate the value using the formulas provided in “Formulas for calculating dimensions”.
Page 9
TENTATIVE P E C I L E ET-WBC100/ET-PKC300B Wall Mount Bracket Formulas for calculating dimensions To use a projected image size not listed in “Dimensional relationship”, check the projected image size SD (m) and use the respective formula to calculate the value.
Page 13
PT-CMZ50 introduction February 2023 Ver2.0 Panasonic Connect Media Entertainment Business Division 1. Thi s presentation is for product i ntroduction purposes only. Pl ease refer to s pec file, webpage or l eaflet for detailed information. 2. Una uthorized reproduction i s prohibited.
Page 19
System Daylight View OFF System Daylight View ON competitive model Panasonic WUXGA model compared to a competitive model with Full HD-equivalent resolution achieved via shifting technology. 1 When [PICTURE MODE] is set to [DYNAMIC] and [LIGHT POWER] is set to [NORMAL]. Measurement, measuring conditions, and method of notation are all compliant with ISO/IEC 21118: 2020 international standards.
Page 32
Comparison with Other Products (Wall-Mount Bracket) Internal Use Only Tentative ⚫ Panasonic’s lightweight wall-mount bracket reduces installation effort Brand Panasonic EPSON Maxell Model number ET-WBC100 ELPLB62 HAS-WM06 Appearance Base bracket 491-519 x 210 -245 x 395-665 mm 550 x 280 x 523 - 906 mm...
Page 33
Internal Use Only Tentative ⚫ EPSON’s wall mount has more parts and is tricky to assemble with 13 bolts ⚫ Panasonic’s ET-WBC100 has fewer parts and requires four bolts to assemble Note: See P.8 for details on assembling ET-WBC100. Fasten 13 bolts...
Page 35
Also Attachable to EPSON Wall-Mount Bracket Internal Use Only Tentative Optional Panasonic ET-PKC300 base bracket enables attachment to EPSON wall-mount bracket EPSON wall-mount bracket EPSON base bracket ET-PKC300B Dimensions 470 mm x 13 mm x 370 mm (W x H x D)
Page 36
20,000 hours • Flexible, Versatile, and Easy to Install CMZ50 installs flexibly on ceiling or wall using optional mounts including ET-WBC100, a lightweight wall-mount system that ships partially preassembled for easy installation. Image adjustment is easily...
Page 37
Microsoft Corporation in the United States and/or other countries. SOLID SHINE and PressIT are trademarks of Panasonic Holdings Corporation. All other trademarks are the All information included here is valid as of January 2023.
Page 42
Panasonic Connect PT-CMZ50_CAD_EN_tentative.dxf This slide was originally a dxf file and could not be converted into PDF. You can find the original file in the .ZIP that was downloaded. If you’re viewing this in Adobe Reader, this file can be opened automatically by clicking here.
TENTATIVE P E C I L E PT-CMZ50 LCD Projector Specifications Main unit Power supply AC 100 V-240 V, 50 Hz/60 Hz Power consumption Maximum power consumption 350 W (3.7-1.6 A) (375 VA) (TBD) On-mode power [NORMAL] 320 W (100-240 V), 310 W (200-240 V) (TBD) * Operating Temperature: 25 ˚C (77 ˚F), consumption [ECO]...
TENTATIVE P E C I L E PT-CMZ50 LCD Projector Terminals AUDIO OUT M3 stereo mini-jack x 1 0 V [rms] to 2.0 V [rms] variable, output Impedance 2.2 k ohms and less SERIAL IN D-sub 9-pin (female) x 1 for computer control (RS-232C compliant) RJ-45 x 1 for network control, 10Base-T, 100Base-TX...
TY-WPS1 (basic set) Wireless Presentation System PressIT Note: visit https://panasonic.net/cns/prodisplays/pressit/for more information. Weights and dimensions shown are approximate. Specifications subject to change without notice. 1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped.
TENTATIVE P E C I L E PT-CMZ50 LCD Projector Terminals COMPUTER IN USB (VIEWER/WIRELESS DC OUT 5V 2A) LAN/DIGITAL LINK HDMI IN 1 AUDIO IN HDMI IN 2 AUDIO OUT HDMI OUT SERIAL IN Dimensions unit : mm [inch] NOTE: This illustration is not drawn to scale.
Page 51
TENTATIVE P E C I L E PT-CMZ50 LCD Projector Projected image and throw distance Install the projector referring to the projected image size and projection distance. Image size and image position can be adjusted in accordance with the screen size and screen position. Note •...
TENTATIVE P E C I L E PT-CMZ50 LCD Projector Projection distance A ±5 % error in listed projection distances may occur. When [SCREEN ADJUSTMENT] is used, distance is corrected to become smaller than the specified image size. Screen aspect ratio 16:10 Unit: meters Digital Zoom Extender Throw ratio...
Page 53
TENTATIVE P E C I L E PT-CMZ50 LCD Projector Screen aspect ratio 16:9 Unit: meters Digital Zoom Extender Throw ratio 0.234:1 0.234-0.287:1 Distance between Longest Projection distance Projection distance Projection distance Diagonal (SD) projector and screen projection distance (L1) (L2) (L2) (L1)
Page 54
TENTATIVE P E C I L E PT-CMZ50 LCD Projector Screen aspect ratio 4:3 Unit: meters Digital Zoom Extender Throw ratio 0.279:1 0.279-0.342:1 Distance between Longest Projection distance Projection distance Projection distance Diagonal (SD) projector and screen projection distance (L1) (L2) (L2) (L1)
Page 55
TENTATIVE P E C I L E PT-CMZ50 LCD Projector Formula for calculating the projection distance To use a projected image size not listed in this manual, check the projected image size SD (m) and use the respective formula to calculate the value. The unit of all the formulae is m.
Page 56
TENTATIVE P E C I L E PT-CMZ50 LCD Projector Installable angle Install the projector at an angle within the range shown below. FULL 360-degree projection 360° 360° 360° 360° vertically 360° horizontally 360° tilted (combination of vertical and horizontal) Notes on projector placement and operation 1.
TENTATIVE P E C I L E PT-CMZ50 LCD Projector List of compatible signals The following table specifies the type of signals compatible with the projector. This projector supports the signal with ✓ in the compatible signal column. Scanning freq. compatible signal Resolution Dot clock freq.
