Panasonic ES8046-A3 Service Manual

Ac/rechargeable shaver
Hide thumbs

Advertisement

Quick Links

Download this manual
SPECIFICATIONS
Power source
Power consumption
Motor voltage
Charging time
Shaves per charge
Measurement
Weight
Supplied accessories
CONTENTS
ES8046-A3
ES8047-A3
AC 100-240V, 50-60Hz (Automatic voltage conversion)
Approx. 7W ( at AC drive)
3.6V DC
1 Hour
14 times (3 minutes shave)
(H)15.3 x (W)6.2 x (D)4.6 cm
180g
Soft case
Cleaning brush
Charging stand
Page
2
3
5
© 2005 Matsushita Electric Works, Ltd. All rights
reserved. Unauthorized copying and distribution is a
violation of law.
ORDER NO. SD0506A39C3
AC/Rechargeable Shaver
Page
7
9

Advertisement

loading

Related Manuals for Panasonic ES8046-A3

Summary of Contents for Panasonic ES8046-A3

  • Page 1: Table Of Contents

    ORDER NO. SD0506A39C3 AC/Rechargeable Shaver ES8046-A3 ES8047-A3 SPECIFICATIONS Power source AC 100-240V, 50-60Hz (Automatic voltage conversion) Power consumption Approx. 7W ( at AC drive) Motor voltage 3.6V DC Charging time 1 Hour Shaves per charge 14 times (3 minutes shave) Measurement (H)15.3 x (W)6.2 x (D)4.6 cm...

  • Page 2: Schematic Diagram

    ES8046-A3 / ES8047-A3 1 SCHEMATIC DIAGRAM 1.1. ES8046 1.2. ES8047...

  • Page 3: Disassembly Instructions

    ES8046-A3 / ES8047-A3 2 DISASSEMBLY INSTRUCTIONS Follow the procedure below to disassemble the main unit. 1. Remove the cap, the outer foil with foil frame and the 4. Remove the both side of housing clips. inner blade. Loosen four screws and remove housing B.
  • Page 4 ES8046-A3 / ES8047-A3 6. Remove trimmer and trimmer handle. 9. Take out the battery from the chassis. 10. Unsolder the lead wires from the module. 7. Move gently the linear motor assembly down and unhook it and remove the float springs from housing A.

  • Page 5: Assembly Instructions

    ES8046-A3 / ES8047-A3 3 ASSEMBLY INSTRUCTIONS NOTE: When reassembling, replace the new waterproof rubber. Make sure whether there is NO foreign substance sticking around a part covered with waterproof seal. 1. Solder the lead wires with the module. NOTE: 4. In case of trimmer is removed;...
  • Page 6 ES8046-A3 / ES8047-A3 7. Tighten the four screws and set the housing clip. 9. Set the bottom cover tighten with a screw. 8. Attach the rear panel with the position "LOCK". 10. Set the trimmer driving bar and the slit blade driving bar.

  • Page 7: Troubleshooting Guide

    ES8046-A3 / ES8047-A3 4 TROUBLESHOOTING GUIDE...
  • Page 8 ES8046-A3 / ES8047-A3...

  • Page 9: Exploded View & Replacement Parts List

    ES8046-A3 / ES8047-A3 5 EXPLODED VIEW & REPLACEMENT PARTS LIST 5.1. ES8046 EXPLODED VIEW...
  • Page 10 ES8046-A3 / ES8047-A3 5.2. ES8046 REPLACEMENT PARTS LIST NOTE: *A=available as an optional accessory *B=only available as set *C=available individually Ref. No. Part No. Part Name & Description Remarks Per Unit WES8046X7158 PROTECTIVE CAP WES9085E OUTER FOIL WES9064EP INNER BLADE...
  • Page 11 ES8046-A3 / ES8047-A3 5.3. ES8047 EXPLODED VIEW...
  • Page 12 ES8046-A3 / ES8047-A3 5.4. ES8047 REPLACEMENT PARTS LIST NOTE: *A=available as an optional accessory *B=only available as set *C=available individually Ref. No. Part No. Part Name & Description Remarks Per Unit WES8046X7158 PROTECTIVE CAP WES9085E OUTER FOIL WES9064EP INNER BLADE...
