SPECIFICATIONS
2002 Matsushita Electric Works Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
1. SCHEMATIC DIAGRAM
SPECIFICATIONS
Power source
Power consumption
Motor voltage
Charging time
Shaves per charge
Measurement
Weight
Supplied accessory
ORDER NO. SD0203E40C2
Wet/Dry Rechargeable Shaver
AC100-240V, 50-60Hz
(Automatic voltage conversion)
90mA
2.4V DC
1-hour
14 times (3minutes shave)
(H) 14.0 X (W) 6.0 X (D) 3.5 cm
230g, 0.51lbs
Soft case
1
ES8026-E2
