Card Validation - Xilinx Alveo U200 Getting Started

Flashable partitions installed in system
Platform
SC Version
Platform UUID
If the SC version does not match under Flashable partitions running on FPGA and
Flashable partitions installed in system, the SC will need to be flashed. See
versions do not match

Card Validation

Card installation can be validated using the xbutil validate command. This command
performs various tests and checks on the card including PCIe link status, SC version status,
memory and bandwidth tests and auxiliary power connection where applicable. Full command
details can be found in
or may require the function to be enabled (i.e., Peer-2-Peer).
Use the following command to run the card validation test:
$ /opt/xilinx/xrt/bin/xbutil validate --device <user BDF> --verbose
where user BDF is the card to be validated. See
BDF value.
IMPORTANT! Prior to running an application on DFX-2RP platform, it is necessary to first program the
shell partition on the card or the application will fail to detect the shell and will not run. See
Programming the Shell Partition for DFX-2RP Platforms
If the card was installed and validated successfully, a message similar to the following will be
displayed. Review the Validation Summary section at the end of the output and confirm the
device validated successfully. See
support.
Starting validation for 1 devices
Validate Device
Platform
SC Version
Platform ID
----------------------------------------------------------------------------
---
Test 1 [0000:02:00.1]
Description
Test Status
----------------------------------------------------------------------------
---
Test 2 [0000:02:00.1]
Description
Test Status
UG1301 (v2.2) August 19, 2022
Getting Started with Alveo Accelerator Cards
: xilinx_u250_gen3x16_base_3
: 4.6.11
: 48810C9D-1786-0EF5-3E9E-529E8B14CE39
to update the SC version on the card.
xbutil documentation. Depending on the card tested, not all tests are valid
Card Validation
: [0000:02:00.1]
: xilinx_u200_gen3x16_xdma_base_1
: 4.6.11
: 0x0
: Aux connection
: Check if auxiliary power is connected
: [PASSED]
: PCIE link
: Check if PCIE link is active
: [PASSED]
Chapter 5: Card Bring-Up and Validation
Displaying Card BDF Values
for details.
within the Alveo Card Debug Guide
