1. Enter the following command:
$ sudo lspci -vd 10ee:
2. If the card is successfully installed and found by the operating system, you will see a message
similar to the following. Note that for each card, there will be two physical functions found:
one for management and one for user. See
details.
65:00.0 Processing accelerators: Xilinx Corporation Device 5004
Subsystem: Xilinx Corporation Device 000e
Flags: bus master, fast devsel, latency 0, NUMA node 0
Memory at 380072000000 (64-bit, prefetchable) [size=32M]
Memory at 380074040000 (64-bit, prefetchable) [size=256K]
Capabilities: [40] Power Management version 3
Capabilities: [60] MSI-X: Enable+ Count=32 Masked-
Capabilities: [70] Express Endpoint, MSI 00
Capabilities: [100] Advanced Error Reporting
Capabilities: [1c0] #19
Capabilities: [400] Access Control Services
Capabilities: [410] #15
Capabilities: [480] Vendor Specific Information: ID=0020 Rev=0
Len=010 <?>
Kernel driver in use: xclmgmt
Kernel modules: xclmgmt
65:00.1 Processing accelerators: Xilinx Corporation Device 5005
Subsystem: Xilinx Corporation Device 000e
Flags: bus master, fast devsel, latency 0, IRQ 64, NUMA node 0
Memory at 380070000000 (64-bit, prefetchable) [size=32M]
Memory at 380074000000 (64-bit, prefetchable) [size=256K]
Memory at 380060000000 (64-bit, prefetchable) [size=256M]
Capabilities: [40] Power Management version 3
Capabilities: [60] MSI-X: Enable+ Count=32 Masked-
Capabilities: [70] Express Endpoint, MSI 00
Capabilities: [100] Advanced Error Reporting
Capabilities: [400] Access Control Services
Capabilities: [410] #15
Capabilities: [480] Vendor Specific Information: ID=0020 Rev=0
Len=010 <?>
Kernel driver in use: xocl
Kernel modules: xocl
Confirm Firmware Installation for DFX-1RP
Platforms
When a card has successfully been installed and the firmware has been updated, both entries for
Platform and SC version installed on the card and the system must match. If they do not
match, the system will be unable to correctly run applications on your card.
UG1301 (v2.2) August 19, 2022
Getting Started with Alveo Accelerator Cards
Chapter 5: Card Bring-Up and Validation
