4.18 Chassis

Item Part Number
1 75041
2 75128
3 74694
5 75127
6 MW10
7 MS110-20
8 75132
9
10
11 MS108-16
12 MW8
13
14 MS2106-12
15 75140
16
17
18 75131
19 MS110-25
20 MW10
21
40
Description
Anti-vibration mount
End plug
Base
Plinth
Washer 10mm
M10 x 20 hex screw
Cooler bracket
?
?
M8 x 16 hex head screw
Washer 8mm
Starter (for clarity only, refer to Fig.5.3 and Fig.19)
M6 x 12 Poz pan hd screw
Access plate
?
?
Motor baffle
M10 x 25 hx hd screw
Washer 10mm
Motor (for clarity only, refer to Drive End section)
Parts List 4
Quantity
Kit
All 04 05
4
4
1
1
4
4
1
2
2
4
4
2
1
2
2
1
4
4
ST 16049-00A
07
