Introduction
Introduction
This publication contains parts lists and service information please read it carefully before you attempt to service or carryout adjustments on
the compressor.
This service manual should be used in conjunction with the user handbook.
Note: If you need any specialist help or service, please contact your distributor or CompAir UK Hydrovane quoting the MODEL TYPE and
SERIAL NUMBER.
Product development
CompAir UK Hydrovane adopt a policy of continual product Improvement. The information in this handbook, whilst fully up to date when
issued, may be subject to change without notice.
Quality standards
CompAir UK Hydrovane Quality Management Systems are approved to BS EN / ISO 9002.
CompAir UK Hydrovane Limited
Claybrook Drive
Washford Industrial Estate
Redditch
Worcestershire
B98 ODS
England.
Model range
This handbook relates to 50 Hz compressors, model types: Classic 05/07 and Airlogic 05/07
Terminology:-
(AN INVENSYS COMPANY)
This part/service manual refers to compressors with serial numbers:
705-002056-9907 onwards
707-003932-9905 onwards
7
=
7 Series
05 & 07
=
kW
Airlogic
=
Self contained boxed unit
E-mail:
Sales@Hydrovane.co.uk
Telephone:
Redditch
Fax:
Rediditch
05/07 Combi
Parts List and Service
Manual
English
ST 15923-00
(01527) 525522
(01527) 521140
Iss A 10/99

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Classic 05 and is the answer not in the manual?

Questions and answers

Summary of Contents for CompAir Classic 05

  • Page 1 This service manual should be used in conjunction with the user handbook. Note: If you need any specialist help or service, please contact your distributor or CompAir UK Hydrovane quoting the MODEL TYPE and SERIAL NUMBER. Product development CompAir UK Hydrovane adopt a policy of continual product Improvement.
  • Page 2: Introduction

    Failure to maintain the compressor correctly, or modifying it without advising that work is being carried out. prior approval from CompAir UK Hydrovane, may also create a hazardous condition. This will also invalidate the warranty. Do not undertake any work until the compressor and receiver if fitted, have been relieved of all pressure.
  • Page 3 Introduction GENERAL HEALTH AND SAFETY PRECAUTIONS (continued) Eye Contact - *Mildly irritating. Flush with copious amounts of When Operating the Compressor warm water. Seek medical advice if necessary. When in automatic mode the compressor will re-start without Aspiration - If there is any suspicion of aspiration into the warning.
  • Page 4 CompAir Hydrovane Introduction Servicing requirements Note: The following preventive maintenance charts cover all Hydrovane compressors using Hydrovane Fluid Force oils. The work to be carried out must be done on or before the hours shown for this action. Read health and safety precautions before starting any work.
  • Page 5 Introduction Preventative Maintenance Schedule Fluid Force Clear Every Every Every Every Every Maintenance Actions and Manual Every Every Install 1000 2000 6000 12000 24000 Reference Week Check RSU temperature Check starter contactors Check motor insulation resistance Clean air/oil radiator external Clean external dirt from motor Clean cabinet air filter Clean solenoids...
  • Page 6 CompAir Hydrovane Introduction Service schedule: Fluid Force 2000 (2000 Hour oil change) The bulk oil temperature must not exceed 90°c (Fluid Force 2000) or 100°c (Fluid Force HPO). If the oil is working above this temperature, the oil life will be reduced.
  • Page 7 Introduction Preventative Maintenance Schedule Fluid Force 2000/HPO Every Every Every Every Every Maintenance Actions and Manual Every Every Install 1000 2000 6000 12000 24000 Reference Week Clean external dirt from compressor Clean non-return filter Clean air filter Grease motor bearings (if applicable) Change Fluid Force 2000 oil Change oil filter Change air filter...
  • Page 8 CompAir Hydrovane Introduction Service schedule: Fluid Force HPO (4000 Hour oil change) The bulk oil temperature must not exceed 90°c. If the oil is working above this temperature, the oil life will be reduced. Note: When changing recommended oil types it is advisable to flush the compressor.
  • Page 9 Introduction Preventative Maintenance Schedule Fluid Force HPO Every Every Every Every Every Every Maintenance Actions and Manual Every Every Install 1000 2000 4000 8000 12000 24000 Reference Week Clean external dirt from compressor Clean oil return filter Clean air filter Grease motor bearings (if applicable) Change Fluid Force HPO oil Change oil filter...
  • Page 10 CompAir Hydrovane Introduction Service Kits Only use genuine CompAir UK Hydrovane parts and approved oils. Oils must not be mixed. Service kits contents Item Part Number Quantity Description Chapter Location KM71 - Maintenance Kit 50273 Air filter 9842 ‘O’ Ring 0053/1 P.T.F.E.
  • Page 11 Introduction Item Part Number Quantity Description Chapter Location 9607 Bonded Seal 9609 Bonded Seal 2K, 2L 9616 Bonded Seal 9619 Bonded Seal 9624 Bonded Seal 9751 ‘O’ Ring 9754 ‘O’ Ring 9810 ‘O’ Ring 9900 ‘O’ Ring 2E, 2L 52109 ‘O’...
  • Page 12 CompAir Hydrovane Introduction Key to symbols used Torque Setting Nm. 22mm Spanner Required (mm) A/F Silco Silco Allen key Required (mm) Grease Required (Specification) Loctite Required and Specification Number Service Tools Required and Part Reference 105 S Lubricate With Sump Oil...
  • Page 13 Introduction Service Tools required 1.5 Wide undercut to base 1.5 Wide undercut to base of thread of thread 36.0 Nozzle orifice Model 120° C.F.M Dia ‘A’ 60° 3.52mm 29.0 2.69mm 23.6 4.03mm 38.0 Dia 'A' Ream Dia 'A' Ream 12.0 Tol :- ±...
  • Page 14 CompAir Hydrovane Introduction Material Material Mild Steel Mild Steel Service Tools (S34) Page 14...
  • Page 15 Parts List and Service Manual Contents Chapter Page Routine Servicing ........... . . 1 ..17 Air-end.
  • Page 16 CompAir Hydrovane Limited This page is intentionally left blank Page 16...
  • Page 17: Table Of Contents

    Routine Servicing Chapter 1 Contents Section Page Introduction ............A ..19 Checking Operation of the Compressor .
  • Page 18: Checking Operation Of The Compressor

    CompAir Hydrovane Limited Routine Servicing Check pressure in Compressor air-end A Introduction Check compressor air-end pressure using compressor pressure WARNING ! gauge. If the correct size of compressor has been installed the gauge should read: READ HEALTH AND SAFETY PRECAUTIONS BEFORE YOU START ANY SERVICE WORK.
  • Page 19: Oil Top-Up Procedure

    Routine Servicing Oil Top-up procedure (Fig 1.1) • Wait until the air-end vent down cycle is complete. • Open test valve to vent pressure from the air aftercooler and associated pipework. • Check that the air-end pressure gauge reads zero. •...
  • Page 20: Oil Draining Procedure

    CompAir Hydrovane Limited Routine Servicing Oil draining procedure (Fig 1.3) • Wait until air-end vent down cycle is complete. • Open test valve to vent pressure from air aftercooler and associated pipework. • Check that compressor air-end pressure gauge reads xero.
  • Page 21 Air-end Chapter 2 Contents Section Page Air Intake Arrangement ..........A ..22 Changing air filter .
  • Page 22: Air Intake Arrangement

    CompAir Hydrovane Air Intake Arrangement Quantity Item Part Number Description MN1708 M8 Philidas Locknut 57738 Fibre washer KM71 57737 Filter cover 50273 Air filter KM71 57735 Filter support bolt 73421 M8 x 40 stud 57739 Fibre washer KM71 58183 Servo valve access plug...
  • Page 23 Air Intake Arrangement 13mm Silco Silco 19mm 24mm Figure 2A - Air Intake Arrangement Page 23...
  • Page 24: Unloader/Inlet Valve

    CompAir Hydrovane Unloader/Inlet Valve Quantity Item Part Number Description 3653 Unloader valve assembly MCI-22 Circlip 22mm (internal) 71062 Shim 52502 Spring support 9402 Spring unloader valve 3656 Philidas nut M5 Washer M5 0195/1 Piston unloader valve 9754 ‘O’ Ring KT71...
  • Page 25 Unloader/Inlet Valve 17mm Silco Silco 17mm 17mm Silco Silco Figure 2B - Unloader/Inlet Valve Page 25...
  • Page 26: Servo Valve

    CompAir Hydrovane Servo Valve Quantity Item Part Number Description 32505 Servo valve assembly (7 bar models) 32624 Servo valve assembly (8 and 10 bar) MG706-30 Grub screw M6 x 30 MN106 Lock nut M6 57577 Servo end cap 52499 Spring carrier...
  • Page 27 Servo Valve 22mm 10mm Figure 2C - Servo Valve Page 27...
  • Page 28: Safety Valve

    CompAir Hydrovane Vacuum Relief Valve and Safety Valve Quantity Item Part Number Description 32536 Vacuum relief valve assembly MG706-40 Grub screw M6 x 40 MN106 Lock nut M6 W4-1 Sealing ring KM71 57794 Vacuum relief valve cap MN106 Nut M6...
  • Page 29 Vacuum Relief Valve and Safety Valve 24mm 10mm Silco Silco Figure 2D - Vacuum Relief Valve and Safety Valve Page 29...
  • Page 30: Rotor Stator Unit - Dismantling

    CompAir Hydrovane Rotor Stator Unit - Dismantling Quantity Item Part Number Description 32549 Intake end cover assembly 32748 Intake end cover assembly 59425-01 Taper plug brass 1/8 BSP 0782 Bearing MG1706-6 Grub-screw tuflock M6 x 6 57747 Stator nut M12...
  • Page 31 Rotor Stator Unit - Dismantling Figure 2E - Rotor Stator Unit - Dismantling Page 31...
  • Page 32 CompAir Hydrovane Rotor Stator Unit - Dismantling Quantity Item Part Number Description 32557-01 Stator assembly 32557-02 Stator assembly 32557-03 Stator assembly 32559-03 Stator assembly 57584-01 Stator 57585-03 Stator 57584-03 Stator 57584-02 Stator HD75120-E5 Drive rivet 5/16 x No.6 58018-02 Gasket 0.04mm A/R...
  • Page 33 Rotor Stator Unit - Dismantling Figure 2E - Rotor Stator Unit - Dismantling Page 33...
  • Page 34 CompAir Hydrovane Rotor Stator Unit - Dismantling Quantity Item Part Number Description 58018-04 Gasket 0.08mm A/R 59302-03 Gasket 0.05mm A/R 59302-04 Gasket 0.08mm A/R 57027 Tension pin FS702-3 Screw 4BA x 3/8 AGS203-B Spring washer 56586 Valve support 56302 Valve support...
  • Page 35 Rotor Stator Unit - Dismantling Figure 2E - Rotor Stator Unit - Dismantling Page 35...
  • Page 36: Oil Chamber Arrangement

    CompAir Hydrovane Oil Chamber Arrangement Quantity Item Part Number Description 34398 Oil chamber assembly 71495 Oil chamber 0782 Bearing 59425-03 Taper plug brass 3/8 BSP 9613 Bonded seal KM71 57996 Drain plug 3/8 BSP 59425-01 Taper plug brass 1/8 BSP...
  • Page 37 Oil Chamber Arrangement Figure 2F - Oil Chamber Arrangement Page 37...
  • Page 38: Oil Filter

    CompAir Hydrovane Oil Chamber Arrangement Quantity Item Part Number Description 0941/1 Oil filter 9619 Bonded seal KT71 0066 Filler plug 9613 Bonded seal KM71 74061 Thermistor probe - std 71812 Thermistor probe - electronic 50350 Eye bolt 59425-03 Plug 74003...
  • Page 39 Oil Chamber Arrangement Figure 2F - Oil Chamber Arrangement Page 39...
  • Page 40: Minimum Pressure Valve And Oil Separator

    CompAir Hydrovane Minimum Pressure Valve and Oil Separator Quantity Item Part Number Description MCI-30 Circlip internal 33413 Minimum pressure valve assembly 50225 Male stud elbow 1/4 BSPT-6mm 58470 Adjuster plug 57742 M.P.V body 9758 O ring KM71 9717 O ring...
  • Page 41 Minimum Pressure Valve and Oil Separator Figure 2G - Minimum Pressure Valve and Oil Separator Page 41...
  • Page 42: Separator

    CompAir Hydrovane Minimum Pressure Valve and Oil Separator Quantity Item Part Number Description MS706-20 Socket head screw MWG6 Spring washer 32506 Separator cap assembly 59425-03 Taper plug brass 3/8 BSP 71162 Nameplate 71163 Nameplate 72427 Nameplate 56391 Pressure gauge MS2105-10...
  • Page 43 Minimum Pressure Valve and Oil Separator Figure 2G - Minimum Pressure Valve and Oil Separator Page 43...
  • Page 44: Bell Housing

    CompAir Hydrovane Bell Housing Quantity Item Part Number Description 71111 Bell housing 71987 Bell Housing RO10000-331 Grommet MST12-60B Stud M12 UFST8-16B Stud ½” x 2” MW12 Washer M12 MWG12 Spring washer M12 MN112 Nut M12 UFN 108 Nut ½” UNF...
  • Page 45 Bell Housing 19mm 27mm Figure 2H - Bell Housing Page 45...
  • Page 46: Drive Coupling Arrangement

    CompAir Hydrovane Drive Coupling Arrangement Quantity Item Part Number Description 57802 Key 94mm diameter 9810 ‘O’ Ring KT71 34222 Oil seal housing assembly (replacement) KT71 72351 Drive coupling compressor (cooler plate) 72350 Drive coupling compressor (panel cooler) 73570 Drive coupling comp (toroidal cooler)
  • Page 47 Drive Coupling Arrangement 30mm Silco Silco 'X' -2mm Coupling Setting Distance Figure 2J - Drive Coupling Arrangement Page 47...
  • Page 48: Intake End Cover - Removal

    CompAir Hydrovane Intake End Cover - Removal Quantity Item Part Number Description 57747 Stator nut M12 9609 Bonded seal 1/4 KT71 Refer to Health and Safety section before carrying out any service work. Intake end cover removal • Stand drive end of compressor oil chamber on a raised platform.
  • Page 49 Intake End Cover - Removal 19mm Figure 2K - Intake End Cover - Removel Page 49...
  • Page 50: Assembling The Rotor Stator Unit

    CompAir Hydrovane Assembling the Rotor Stator Unit Quantity Item Part Number Description 57746 Stator stud M12 9609 Bonded seal 57747 Nut M12 58017-02 Shim 0.04 mm 58017-03 Shim 0.05 mm KT71 58017-04 Shim 0.08 mm KT71 59370-03 Shim 0.05 mm...
  • Page 51 Assembling the Rotor Stator Unit 19mm Figure 2L - Assembling the Rotor Stator Unit Page 51...
  • Page 52: Assembling The Rotor Stator Unit - Continued

    CompAir Hydrovane Assembling the Rotor Stator Unit ... Continued Quantity Item Part Number Description 33831-01 Intake end cover assembly 33831-02 Intake end cover assembly 58039 Intake end cover 59425-04 Taper plug brass 1/2 BSP (non-servo) MG1706-6 Grub screw tuflock M6 x 6...
  • Page 53 Assembling the Rotor Stator Unit ... Continued Figure 2L - Assembling the Rotor Stator Unit ... Continued Page 53...
  • Page 54: Oil Separator Assembly

    CompAir Hydrovane Oil Separator Assembly Quantity Item Part Number Description MS706-20 Socket head screw MWG6 Spring washer 34400 Separator cap assembly 74012 59425-03 Taper plug brass 3/8” BSP 74158 Nameplate - Classic 71163 Nameplate 56391 Pressure gauge KT71 MS2105-10 Pan head screw M5x10...
  • Page 55 Oil Separator Assembly 2.5mm Silco Silco Figure 2M - Oil Separator Assembly Page 55...
  • Page 56: Minimum Pressure Valve Assembly

    CompAir Hydrovane Minimum Pressure Valve Assembly Quantity Item Part Number Description MCI-30 Circlip internal 33413 Minimum pressure valve assembly 73283 Elbow 58470 Adjuster plug 57742 M.P.V. Body 9758 O Ring KM71 9717 O Ring KM71 9711 O Ring KM71 57842 M.P.V.
  • Page 57 Minimum Pressure Valve Assembly Figure 2N - Minimum Pressure Valve Assembly Page 57...
  • Page 58: Panels

    CompAir Hydrovane Panels Quantity Item Part Number Description 73900 Starter Hinge 73981 Cooler Duct 74062 Starter Cover 74089 Front Trim Panel 74096 Starter Cover Bracket 74133 Cabinet Filter Bracket 73894 Rear Panel 73895 End Panel 73896 Top Panel 74008 Air Intake Baffle...
  • Page 59 Panels Figure 2P - Panels Page 59...
  • Page 60: Dryer

    CompAir Hydrovane Dryer Quantity Item Part Number Description 1068 Tubing nut 1069 Tubing sleeve 1911 Stud elbow c/w nuts 34447 By-pass kit comprising:- 72956 Stud elbow ½ - 20 mm 74150 Ball valve 3-way 74151 Pipe, dryer to by-pass 74152...
  • Page 61 Dryer Figure 2Q - Dryer Page 61...
  • Page 62: Oil Cooler;Base

    CompAir Hydrovane Oil Cooler;Base Quantity Item Part Number Description 1911 Stud elbow c/w nuts 53549 Stud coupling ½ BSP 70832 Door seal 0.7 m 71129 Stud elbow 71130 Tee ½ x 15 mm 71131 Blanking plug 71432 Cooler 73901 Oil feed pipe...
  • Page 63 Oil Cooler;Base Figure 2R - Oil Cooler;Base Page 63...
  • Page 64: Ventdown Assemblies

    CompAir Hydrovane Ventdown Assemblies Quantity Item Part Number Description D.O.L STANDARD CONTROL 73220 Solenoid valve 110 V N.O. 73215 Elbow, push-in, R 1/8 “ - 6 mm 73283 Elbow, push-in, R 1/4 “ - 6 mm 73282 Tee, push-in, 6 mm...
  • Page 65 Ventdown Assemblies Figure 2S - Ventdown Assemblies Page 65...
  • Page 66: Air-End Part Modifications

    CompAir Hydrovane Air-end Part Modifications Air-end Part Modifications Serial No. Prefix Compressor(s) New Part(s) Old Part(s) Service Bulletin Page 66...
  • Page 67 Starter Assemblies Chapter 3 Contents Section Page 400V 50Hz Electronic Control Starter ........3A ..400V 50Hz D.O.L.
  • Page 68 CompAir Hydrovane 01/02 Three Phase (PUTS) Starter Quantity Item Part Number Description Starter Assembly No. 34367 74097 Contactor 74035 Thermal overload 74022 Terminal 74023 Earth terminal 74024 Terminal, double stack 74036 Transformer 56132 Fuse 1A 74027 Fuse 1.6A 74038 Emergency stop button...
  • Page 69 01/02 Three Phase (PUTS) Starter Figure 3A - 400V, 50Hz Electronic Control Starter Page 69...
  • Page 70 CompAir Hydrovane 01 Single Phase (PUTS) Starter Quantity Item Part Number Description Starter Assembly No. 34368 74098 Contactor 74024 Terminal, double stack 74025 End section 74036 Transformer 56132 Fuse 1A 59344 OTC board 56122 Timer 53494 Timer base 74067 Knob...
  • Page 71 01 Single Phase (PUTS) Starter Figure 3B - 400V, 50Hz D.O.L. and 380/440V 60Hz Standard Page 71...
  • Page 72 CompAir Hydrovane 02 Single Phase (PUTS) Starter Quantity Item Part Number Description Starter Assembly No. 34390 74029 Contactor 74020 Thermal overload 7.5/5.5kW (460V) 74021 Thermal overload 5.5kW (208-230V) 74030 Thermal overload 7.5kW (208-230V) 74022 Terminal 74023 Earth terminal 74024 Terminal, double stack...
  • Page 73 02 Single Phase (PUTS) Starter Figure 3C - 208-230V, 60Hz D.O.L. Electronic Starter Page 73...
  • Page 74 CompAir Hydrovane Starter Assembly Part Modifications Quantity Item Part Number Description Starter Assembly No. 34403 74097 Contactor 74039 Auxilary contact block 74063 Auxilary contact block 56378 Timer (Star/Delta) 74064 Circuit breaker 56122 Timer 53494 Timer base 59344 OTC board 74024...
  • Page 75 Starter Assembly Part Modifications Figure 3D - 400V, 50Hz and 380/440V, 60Hz Standard Control Starter Page 75...
  • Page 76 CompAir Hydrovane 400V 50Hz and 380/440V 60Hz Standard Control Starter Quantity Item Part Number Description Starter Assembly No. 34409 74029 Contactor 110V 60Hz 74024 Terminal, double stack 74025 End section 74026 Transformer 56132 Fuse 1A 59344 OTC board 56122 Timer...
  • Page 77 400V 50Hz and 380/440V 60Hz Standard Control Starter Figure 3E - 400V, 50Hz and 380/440V, 60Hz Standard Control Starter Page 77...
  • Page 78 CompAir Hydrovane 230V 50/60Hz Standard Control Starter Quantity Item Part Number Description Starter Assembly No. 34423 74112 Contactor 74063 Auxilary contact block 74113 Auxilary contact block 56378 Timer (Star/Delta) 74064 Circuit breaker 56122 Timer 53494 Timer base 59344 OTC board...
  • Page 79 230V 50/60Hz Standard Control Starter Figure 3F - 230V, 50/60Hz Standard Control Starter Page 79...
  • Page 80 CompAir Hydrovane 230V 50/60Hz D.O.L. Standard Control Starter Quantity Item Part Number Description Starter Assembly No. 34424 74029 Contactor 74024 Terminal, double stack 74025 End section 74026 Transformer 56132 Fuse 1A 59344 OTC board 56122 Timer 53494 Timer base 74067...
  • Page 81 230V 50/60Hz D.O.L. Standard Control Starter Figure 3G - 230V, 50/60Hz D.O.L. Standard Control Starter Page 81...
  • Page 82 CompAir Hydrovane Starter Assembly Part Modifications Starter Assembly Parts Modifications Serial No. Prefix Compressor(s) Ref. New Part(s) Old Part(s) Service Bulletin Page 82...
  • Page 83 Labels Chapter 4 Contents Section Page Labels ............. 4A ..Labels Parts Modifications .
  • Page 84 CompAir Hydrovane Labels Quantity Item Part Number Description 74160 Airend kit Refer to Health and Safety section before carrying out any service work. Page 84...
  • Page 85 Labels Figure 4A - Labels Page 85...
  • Page 86 CompAir Hydrovane Labels Parts Modifications Label Parts Modifications Serial No. Prefix Compressor(s) Ref. New Part(s) Old Part(s) Service Bulletin Page 86...
  • Page 87 Adjustments and Testing Chapter 5 Contents Section Page Introduction ............A ..88 Pressure Switch Adjustment .
  • Page 88 Adjustment procedures shown must only be carried out by authorised persons fully trained and competent in the maintenance of CompAir UK Hydrovane compressors. If you are not able to carry out the work safely, contact your CompAir UK Hydrovane distributor. B - Pressure Switch Adjustment (Fig. 5.1) •...
  • Page 89 Adjustments and Testing E - Oil Temperature • Introduce a small amount of oil and a thermometer into the thermometer pocket. • Allow compressor to run for 30 minutes in order to attain its normal working temperature. • ° Average running temperature should be 88 C approx.
  • Page 90 CompAir Hydrovane Adjustments and Testing This page is intentionally left blank Page 90...
  • Page 91 Fault Finding Chapter 6 Contents Page System Pressure Low ..........A ..92 Low or No Air Delivered by Compressor .
  • Page 92: System Pressure Low

    READ HEALTH AND SAFETY PRECAUTIONS BEFORE YOU START ANY SERVICE WORK. Servicing of the compressor must only be carried-out by authorised persons fully trained and competent in the maintenance of CompAir UK Hydrovane compressors. They must fully understand and adopt correct and safe working practices. 05/07 Troubleshooting chart...
  • Page 93: High Temperature

    Fault Finding Cause Cause Cause Ref Symptom Diagnosis Action (Level 1) (Level 2) (Level 3) Read pressure gauge. If 1 Oil return Separator Replace separator and bar, remove separator cap restrictors flooded with oil return restrictors and bottle and examine. blocked Compressor will run very Rotor blades...
  • Page 94: Oil Mist From Air Intake When Stopping And/Or Rapid Venting

    CompAir Hydrovane Fault Finding Cause Cause Cause Ref Symptom Diagnosis Action (Level 1) (Level 2) (Level 3) If separator element are Remove separator cap broken, Replace separator and bottle and examine element, oil return separator. restrictors, clean oil filter and change oil...
  • Page 95: Slow/No Ventdown

    Fault Finding Cause Cause Cause Ref Symptom Diagnosis Action (Level 1) (Level 2) (Level 3) Leaking bearing cap Replace end cap gasket gasket Leaking Replace unloader valve unloader valve seat Read pressure gauge in Faulty safety test point and check Worn spring Replace safety valve valve...
